Features - Full black coating with metal mesh appearance
- eSPORTS look front bezel
- Bottom-placed PSU design for easy installation
- Supports high-end graphic cards
- Rear 120mm silent fan with blue LED
- Built-in latest USB3.0 SuperSpeed connector
HDD Air Cooling System
1. Front (intake) : 120 x 120 x 25 mm fan (Optional)
CPU Air Cooling System
2. Top (exhaust) : 120 x 120 x 25 mm fan x 2 (Optional)
3. Rear (exhaust) : 120 x 120 x 25 mm Blue LED Fan (1000rpm,16dBA)
VGA Air Cooling System
4. Side (intake) : 120 x 120 x 25 mm fan (Optional)
5. Bottom (intake) : 120 x 120 x 25 mm fan (Optional)
|
| Model |
VO100A1W2N |
| Case Type |
Mid Tower |
| Dimension (H x W x D) |
429 x 197 x 495 mm (16.9 x 7.7 x 19.5 inch) |
| Net Weight |
4.5Kg / 9.9lb |
| Side Panel |
Transparent Window |
| Color |
Exterior & Interior : Black |
| Material |
SECC |
| Cooling System |
Front (intake) : Optional 120 x 120 x 25 mm fan x 1 Rear (exhaust) : 120 x 120 x 25 mm Blue LED fan (1000rpm,16dBA) Top (exhaust) : Optional 120 x 120 x 25 mm fan x 2 Side (intake) : Optional 120 x 120 x 25 mm fan Bottom (intake) : Optional 120 x 120 x 25 mm fan |
| Drive Bays |
- Accessible:4 x 5.25’’, 1 x 3.5’’ - Hidden:5 x 3.5’’, 1 x 2.5’’ |
| Expansion Slots |
7 |
| Motherboards |
9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| I/O Port |
USB 3.0 x 1, USB 2.0 x 1, HD Audio x 1 |
| PSU |
Standard PS2 PSU |
| LCS Upgradable |
Supports 1/2”、3/8”、1/4” water tube |
| Other |
CPU cooler height limitation: 155mm VGA length limitation: 320mm |
| Note |
* Specifications are subject to change without notice.
* The product picture(s) is only for your reference, it may differ from the actual product. |
