ASRock B365-Pro4 LGA 1151 ATX Motherboard

ASRock B365-Pro4 LGA 1151 ATX Motherboard
  • ASRock B365-Pro4 LGA 1151 ATX Motherboard
  • ASRock B365-Pro4 LGA 1151 ATX Motherboard
  • ASRock B365-Pro4 LGA 1151 ATX Motherboard
  • ASRock B365-Pro4 LGA 1151 ATX Motherboard
  • ASRock B365-Pro4 LGA 1151 ATX Motherboard
$159.0
RRP:$179.0    Save $20.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    ASRock B365-Pro4 LGA 1151 ATX Motherboard
  • Model Number:
    B365-PRO4
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    ASRock B365-Pro4 LGA 1151 ATX Motherboard


    • Supports 9th and 8th Gen Intel® Core™ processors (Socket 1151)

    • Supports DDR4 2666

    • 2 PCIe 3.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key E for WiFi

    • AMD Quad CrossFireX™

    • Graphics Output Options: HDMI, DVI-D, D-Sub

    • 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps

    • 6 SATA3, 2 Ultra M.2 (1 x PCIe Gen3 x4 & SATA3, 1 x PCIe Gen3 x4)

    • 8 USB 3.1 Gen1 (2 Front, 5 Rear, 1 Type-C)

    • Intel® Gigabit LAN


    ASRock B365-Pro4 LGA 1151 ATX Motherboard

    ASRock B365-Pro4 LGA 1151 ATX Motherboard


    Specifications


    UNIQUE FEATURE

    ASRock Super Alloy
      - Premium 50A Power Choke
      - Sapphire Black PCB
      - High Density Glass Fabric PCB
      ASRock Intel® 4-Layer   Memory POOL (Planes on Outer Layers) Technology
      ASRock Steel Slot
      ASRock Full Coverage M.2 Heatsink
      ASRock Ultra M.2 (PCIe Gen3   x4 & SATA3)
      ASRock Full Spike Protection (for   all USB, Audio, LAN Ports)
      ASRock Live Update & APP Shop

    CPU

    - Supports 9th and 8th Gen Intel® Core™ Processors (Socket 1151)
      - Supports CPU up to 95W
      - Digi Power design
      - 8 Power Phase design
      - Supports Intel® Turbo Boost 2.0 Technology

    CHIPSET

    - Intel® B365


    - Supports 9th and 8th Gen Intel® Core™ Processors (Socket 1151)
      - Supports CPU up to 95W
      - Digi Power design
      - 8 Power Phase design
      - Supports Intel® Turbo Boost 2.0 Technology

    MEMORY

    - Dual Channel DDR4 Memory Technology
      - 4 x DDR4 DIMM Slots
      - Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
      - Supports ECC UDIMM memory modules (operate in non-ECC mode)
      - Max. capacity of system memory: 128GB*
      - Supports Intel® Extreme Memory Profile (XMP) 2.0
      - 15μ Gold Contact in DIMM Slots

    *Due to the operating system limitation, the   actual memory size may be less than 4GB for the reservation for system usage   under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no   such limitation.

    BIOS

    - 128Mb AMI UEFI Legal BIOS with multilingual   GUI support
      - ACPI 6.0 Compliant wake up events
      - SMBIOS 2.7 Support
      - CPU, GT, DRAM, PCH 1.0V, VCCST Voltage Multi-adjustment

    GRAPHICS

    * Intel® UHD Graphics Built-in Visuals and the VGA   outputs can be supported only with processors which are GPU integrated.
      - Supports Intel® UHD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and   MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® UHD Graphics
      - DirectX 12
      - HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9   8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
      - Three graphics output options: D-Sub, DVI-D and HDMI
      - Supports Triple Monitor
      - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
      - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
      - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
      - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate   Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
      - Supports HDCP 2.2 with DVI-D and HDMI 1.4 Ports
      - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port



    AUDIO

    - 7.1 CH HD Audio with Content Protection   (Realtek ALC892 Audio Codec)*
      - Premium Blu-ray Audio support
      - Supports Surge Protection
      - ELNA Audio Caps

    *To configure 7.1 CH HD Audio, it is required   to use an HD front panel audio module and enable the multi-channel audio   feature through the audio driver.



    LAN

    - Gigabit LAN 10/100/1000 Mb/s
      - Giga PHY Intel® I219V
      - Supports Wake-On-LAN
      - Supports Lightning/ESD Protection
      - Supports Energy Efficient Ethernet 802.3az
      - Supports PXE

    SLOTS

    - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3:   single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3))*
      - 2 x PCI Express 3.0 x1 Slots (Flexible PCIe)
      - Supports AMD Quad CrossFireX™ and CrossFireX™
      - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module



    *Supports NVMe SSD as boot disks

    STORAGE

    - 6 x SATA3 6.0 Gb/s Connectors, support RAID   (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 17), NCQ, AHCI and   Hot Plug*
      - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2   SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**
      - 1 x Ultra M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110   M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**



    *If M2_1 is occupied by a SATA-type M.2   device, SATA3_0 will be disabled.

    **Supports Intel® Optane™ Technology

    Supports NVMe SSD as boot disks

    Supports ASRock U.2 Kit

    CONNECTOR

    - 1 x COM Port Header

    - 1 x TPM Header

    - 1 x Power LED and Speaker Header

    - 2 x RGB LED Headers*

    - 1 x Addressable LED Header**

    - 1 x CPU Fan Connector (4-pin)***

    - 1 x CPU/Water Pump Fan Connector (4-pin)   (Smart Fan Speed Control)****

    - 3 x Chassis/Water Pump Fan Connectors   (4-pin) (Smart Fan Speed Control)*****

    - 1 x 24 pin ATX Power Connector

    - 1 x 8 pin 12V Power Connector

    - 1 x Front Panel Audio Connector

    - 1 x Thunderbolt™ AIC Connector (5-pin)

    - 2 x USB 2.0 Headers (Support 3 USB 2.0   ports) (Supports ESD Protection)

    - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1   Gen1 ports) (Supports ESD Protection)



    REAR PANEL I/O

    - 1 x PS/2 Mouse/Keyboard Port
      - 1 x D-Sub Port
      - 1 x DVI-D Port
      - 1 x HDMI Port
      - 2 x USB 2.0 Ports (Supports ESD Protection)
      - 1 x USB 3.1 Gen1 Type-C Port (Supports ESD Protection)
      - 5 x USB 3.1 Gen1 Ports (Supports ESD Protection)
      - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
      - HD Audio Jacks: Line in / Front Speaker / Microphone

    SOFTWARE AND UEFI

    Software
      - ASRock A-Tuning
      - ASRock Polychrome SYNC
      - ASRock XFast LAN
      UEFI
      - ASRock EZ Mode
      - ASRock Full HD UEFI
      - ASRock My Favorites in UEFI
      - ASRock Instant Flash
      - ASRock Internet Flash



    *These utilities can be downloaded from   ASRock Live Update & APP Shop.

    SUPPORT CD

    - Drivers, Utilities, AntiVirus Software   (Trial Version), Google Chrome Browser and Toolbar

    ACCESSORIES

    - Quick Installation Guide, Support CD, I/O   Shield
      - 2 x SATA Data Cables
      - 3 x Screws for M.2 Sockets
      - 1 x Standoff for M.2 Socket

    HARDWARE MONITOR

    - Temperature Sensing: CPU, CPU/Water Pump,   Chassis/Water Pump Fans
      - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
      - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU,   CPU/Water Pump, Chassis/Water Pump Fans
      - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans
      - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V,   VCCSA, VCCST

    FORM FACTOR

    - ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm   x 22.9 cm
      - Solid Capacitor design

    OS

    - Microsoft® Windows® 10 64-bit

    CERTIFICATIONS

    - FCC, CE
      - ErP/EuP ready (ErP/EuP ready power supply is required)

    The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

    The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
