ASRock X570 Phantom Gaming X AM4 ATX Motherboard

ASRock X570 Phantom Gaming X AM4 ATX Motherboard
  • ASRock X570 Phantom Gaming X AM4 ATX Motherboard
  • ASRock X570 Phantom Gaming X AM4 ATX Motherboard
  • ASRock X570 Phantom Gaming X AM4 ATX Motherboard
  • ASRock X570 Phantom Gaming X AM4 ATX Motherboard
  • ASRock X570 Phantom Gaming X AM4 ATX Motherboard
$495.0
RRP:$599.0    Save $104.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-2 Days excluding Weekends



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Bundle Up and Save!

Bonus Mousepad

Original Price:$545.0

Bundle Price:$499.0

You Save:$46.0

Bundle Up and Save!

  • Original Price:$545.0
  • Bundle Price:$499.0
  • You Save:$46.0

Specifications

  • Product Name:
    ASRock X570 Phantom Gaming X AM4 ATX Motherboard
  • Model Number:
    X570-PHANTOM-GAMING-X
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    ASRock X570 Phantom Gaming X AM4 ATX Motherboard


    • Supports AMD AM4 Socket Ryzen™ 2000 and 3000 Series processors

    • Intel® Wi-Fi 6 802.11ax (2.4Gbps) + BT 5.0

    • Phantom Gaming 2.5 Gigabit LAN, Intel® Gigabit LAN

    • Supports DDR4 4666+ (OC)

    • 3 PCIe 4.0 x16, 2 PCIe 4.0 x1

    • NVIDIA® NVLink™, Quad SLI™, AMD 3-Way CrossFireX™

    • 7.1 CH HD Audio (Realtek ALC1220 Audio Codec)

    • Supports Creative Sound Blaster Cinema 5

    • 8 SATA3, 2 Hyper M.2 (PCIe Gen4 x4 & SATA3), 1 Hyper M.2 (PCIe Gen4 x4)

    • 3 USB 3.2 Gen2 (Rear Type A+C, Front Type-C), 8 USB 3.2 Gen1 (2 Front, 6 Rear)

    • ASRock Polychrome SYNC


    ASRock X570 Phantom Gaming X AM4 ATX Motherboard

    ASRock X570 Phantom Gaming X AM4 ATX Motherboard

    ASRock X570 Phantom Gaming X AM4 ATX Motherboard


    Specifications


    GAMING ARMOUR

    Power

    - Hi-Density Power Connectors (24 pin, 8 pin   and 4 pin)

    Memory

    - 15? Gold Contact in DIMM Slots

    VGA Card

    - 15? Gold Contact in VGA PCIe Slot (PCIE1)

    Internet

    - Phantom Gaming 2.5G LAN

    - Intel® LAN

    Cooling

    - XXL Aluminum Alloy Heatsink

    - Heat Pipe Design

    Audio

    - Creative Sound Blaster™ Cinema 5

    UNIQUE FEATURE

    ASRock USB 3.2 Gen2

    - ASRock Front Panel Type C USB 3.2 Gen2   Header (10 Gb/s)

    - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)

    - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s)

    ASRock Super Alloy

    - XXL Aluminum Alloy Heatsink

    - Premium 60A Power Choke

    - 50A Dr.MOS

    - Premium Memory Alloy Choke (Reduces 70%   core loss compared to iron powder choke)

    - Combo Caps (Nichicon 12K Black Caps)

    - Nichicon 12K Black Caps (100% Japan made   high quality conductive polymer capacitors)

    - I/O Armor

    - Matte Black PCB

    - High Density Glass Fabric PCB

    - 2oz Copper PCB

    ASRock Phantom Gaming 2.5G LAN

    Intel® 802.11ax WiFi

    ASRock Steel Slot Gen4

    ASRock Full Coverage M.2 Heatsink

    ASRock Hyper M.2 (PCIe Gen4x4 & SATA3)

    ASRock Ultra USB Power

    ASRock Full Spike Protection (for all USB,   Audio, LAN Ports)

    ASRock Live Update & APP Shop

    CPU

    - Supports AMD AM4 socket Ryzen™ 2000 and   3000 series processors

    - Intersil Digital PWM

    - 14 Power Phase design

    - Capable of providing extra 300W for CPU

    - Supports ASRock Hyper BCLK Engine II

    CHIPSET

    - AMD Premium X570

    MEMORY

    - Dual Channel DDR4 Memory Technology

    - 4 x DDR4 DIMM Slots

    - AMD Ryzen series CPUs (Matisse) support   DDR4 4666+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) /   3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered   memory*

    - AMD Ryzen series CPUs (Pinnacle Ridge)   support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 ECC   & non-ECC, un-buffered memory*

    - AMD Ryzen series CPUs (Picasso) support   DDR4 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 non-ECC, un-buffered   memory*

    - Max. capacity of system memory: 128GB*

    - 15? Gold Contact in DIMM Slots

    *For Ryzen Series CPUs (Picasso), ECC is only   supported with PRO CPUs.

    Ryzen Series CPUs (Matisse):

    ASRock X570 Phantom Gaming X AM4 ATX Motherboard

    Ryzen Series CPUs (Pinnacle Ridge):

    ASRock X570 Phantom Gaming X AM4 ATX Motherboard

    Ryzen Series CPUs (Picasso):

    ASRock X570 Phantom Gaming X AM4 ATX Motherboard

    SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM   module label x=1 or 2

    DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM   module label

    **Due to the operating system limitation, the   actual memory size may be less than 4GB for the reservation for system usage   under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no   such limitation.

    BIOS

    - 256Mb AMI UEFI Legal BIOS with GUI support

    - Supports "Plug and Play"

    - ACPI 5.1 compliance wake up events

    - Supports jumperfree

    - SMBIOS 2.3 support

    - CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM   VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP, Voltage Multi-adjustment

    GRAPHICS

    - Integrated AMD Radeon™ Vega Series   Graphics in Ryzen Series APU*

    - DirectX 12, Pixel Shader 5.0

    - Shared memory default 2GB. Max Shared   memory supports up to 16GB.**

    - Supports HDMI 2.0 with max. resolution up   to 4K x 2K (4096x2160) @ 60Hz

    - Supports Auto Lip Sync, Deep Color   (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant   HDMI monitor is required)

    - Supports HDR (High Dynamic Range) with   HDMI 2.0

    - Supports HDCP 2.2 with HDMI 2.0 Port

    - Supports 4K Ultra HD (UHD) playback with   HDMI 2.0 Port

    - Supports Microsoft® PlayReady

    *Actual support may vary by CPU

    **The Max shared memory 16GB requires 32GB   system memory installed.

    AUDIO

    - 7.1 CH HD Audio with Content Protection   (Realtek ALC1220 Audio Codec)

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - Nichicon Fine Gold Series Audio Caps

    - NE5532 Premium Headset Amplifier for Front   Panel Audio Connector (Supports up to 600 Ohm headsets)

    - Pure Power-In

    - Direct Drive Technology

    - PCB Isolate Shielding

    - Impedance Sensing on Rear Out port

    - Individual PCB Layers for R/L Audio Channel

    - Gold Audio Jacks

    - 15? Gold Audio Connector

    - Supports Creative Sound Blaster™ Cinema 5

    LAN

    1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s   (Dragon RTL8125AG):

    - Supports Phantom Gaming LAN Software

    - Smart Auto Adjust Bandwidth Control

    - Visual User Friendly UI

    - Visual Network Usage Statistics

    - Optimized Default Setting for Game,   Browser, and Streaming Modes

    - User Customized Priority Control

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE 1 x Intel® Gigabit LAN   10/100/1000 Mb/s (1 x Intel® I211AT):

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE

    WIRELESS LAN

    - Intel® 802.11ax WiFi Module

    - Supports IEEE 802.11a/b/g/n/ax

    - Supports Dual-Band (2.4/5 GHz)

    - Supports WiFi6 802.11ax (2.4Gbps)

    - 2 antennas to support 2 (Transmit) x 2   (Receive) diversity technology

    - Supports Bluetooth 5.0 + High speed class   II

    - Supports MU-MIMO

    SLOTS

    AMD Ryzen series CPUs (Matisse)

    - 3 x PCI Express 4.0 x16 Slots   (PCIE1/PCIE3/PCIE5: single at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3);   triple at x8 (PCIE1) / x8 (PCIE3) / x4 (PCIE5))*

    AMD Ryzen series CPUs (Pinnacle Ridge)

    - 3 x PCI Express x16 Slots   (PCIE1/PCIE3/PCIE5: single at Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) /   Gen3x8 (PCIE3); triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen4x4 (PCIE5))*

    AMD Ryzen series CPUs (Raven Ridge) (Picasso)

    - 1 x PCI Express 3.0 x16 Slot (single at x8   (PCIE1))*

    - 1 x PCI Express 4.0 x16 Slot (single at x4   (PCIE5))*

    - 2 x PCI Express 4.0 x1 Slots

    - Supports AMD Quad CrossFireX™, 3-Way   CrossFireX™ and CrossFireX™

    - Supports NVIDIA® Quad SLI™ and SLI™**

    - Supports NVIDIA® NVLink™ with dual NVIDIA®   GeForce RTX series graphics cards**

    - 1 x Vertical M.2 Socket (Key E) with the   bundled WiFi-802.11ax module (on the rear I/O)

    - 15? Gold Contact in VGA PCIe Slot (PCIE1)

    *Supports NVMe SSD as boot disks

    **NVIDIA® NVLink™ Bridge does not come with   the package. Please purchase it from NVIDIA® if necessary.

    This feature is only supported with Ryzen   Series CPUs (Pinnacle Ridge).

    STORAGE

    - 8 x SATA3 6.0 Gb/s Connectors, support RAID   (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

    - 1 x Hyper M.2 Socket (M2_1), supports M Key   type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up   to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge   and Picasso)*

    - 1 x Hyper M.2 Socket (M2_2), supports M Key   type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s)*

    - 1 x Hyper M.2 Socket (M2_3), supports M Key   type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express   module up to Gen4x4 (64 Gb/s)*

    *If M2_3 is occupied, PCIE5 slot will be   disabled

    Supports NVMe SSD as boot disks

    Supports ASRock U.2 Kit

    CONNECTOR

    - 1 x SPI TPM Header

    - 1 x Power LED and Speaker Header

    - 1 x AMD Fan LED Header*

    - 1 x RGB LED Header**

    - 1 x Addressable LED Header***

    - 1 x CPU Fan Connector (4-pin)****

    - 1 x CPU/Water Pump Fan Connector (4-pin)   (Smart Fan Speed Control)*****

    - 4 x Chassis/Water Pump Fan Connectors   (4-pin) (Smart Fan Speed Control)******

    - 1 x 24 pin ATX Power Connector (Hi-Density   Power Connector)

    - 1 x 8 pin 12V Power Connector (Hi-Density   Power Connector)

    - 1 x 4 pin 12V Power Connector (Hi-Density   Power Connector)

    - 1 x Front Panel Audio Connector (15? Gold   Audio Connector)

    - 1 x AMD LED Fan USB Header

    - 1 x Thunderbolt™ AIC Connector (5-pin)   (Supports ASRock Thunderbolt™ AIC Card only)

    - 2 x USB 2.0 Headers (Support 4 USB 2.0   ports) (Supports ESD Protection)

    - 1 x USB 3.2 Gen1 Header (Supports 2 USB   3.2 Gen1 ports) (Supports ESD Protection)

    - 1 x Front Panel Type C USB 3.2 Gen2 Header   (Supports ESD Protection)

    - 1 x Dr. Debug with LED

    - 1 x Power Button with LED

    - 1 x Reset Button with LED

    - 1 x Clear CMOS Button

    *The AMD Fan LED Header is compatible with a   regular RGB LED stripe.

    **Supports in total up to 12V/3A, 36W LED   Strip

    ***Supports in total up to 5V/3A, 15W LED   Strip

    ****The CPU Fan Connector supports the CPU   fan of maximum 1A (12W) fan power.

    *****The CPU/Water Pump Fan supports the   water cooler fan of maximum 2A (24W) fan power.

    ******The Chassis/Water Pump Fan supports   the water cooler fan of maximum 2A (24W) fan power.

    CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and   CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.

    REAR PANEL I/O

    - 2 x Antenna Ports

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x HDMI Port

    - 1 x Optical SPDIF Out Port

    - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)   (Supports ESD Protection)

    - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)   (Supports ESD Protection)

    - 6 x USB 3.2 Gen1 Ports (Supports ESD   Protection)*

    - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED   and SPEED LED)

    - 1 x Clear CMOS Button

    - 1 x BIOS Flashback Button

    - HD Audio Jacks: Rear Speaker / Central /   Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)

    *Ultra USB Power is supported on USB3_5_6   ports.

    ACPI wake-up function is not supported on   USB3_5_6ports.

    SOFTWARE AND UEFI

    Software

    - ASRock Phantom Gaming LAN Software

    - ASRock Polychrome SYNC

    - ASRock XFast LAN

    UEFI

    - ASRock Full HD UEFI

    - ASRock Instant Flash

    - ASRock Easy RAID Installer

    *These utilities can be downloaded from   ASRock Live Update & APP Shop.

    SUPPORT CD

    - Drivers, Utilities, AntiVirus Software   (Trial Version), Google Chrome Browser and Toolbar

    ACCESSORIES

    - Quick Installation Guide, Support CD

    - 4 x SATA Data Cables

    - 1 x ASRock SLI_HB_Bridge_2S Card

    - 1 x ASRock WiFi 2.4/5 GHz Antenna

    - 1 x ASRock Screwdriver

    - 3 x Screws for M.2 Sockets

    - 2 x Standoffs for M.2 Sockets

    HARDWARE MONITOR

    - Temperature Sensing: CPU, CPU/Water Pump,   Chassis, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, CPU/Water Pump,   Chassis, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan speed by   CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU, CPU/Water   Pump, Chassis, Chassis/Water Pump Fans

    - Voltage monitoring: +12V, +5V, +3.3V, CPU   Vcore, CPU VDDCR_SOC, DRAM, VPPM, PREM VDDCR_SOC, +1.8V, VDDP

    FORM FACTOR

    - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm   x 24.4 cm

    - 2oz Copper PCB

    OS

    - Microsoft® Windows® 10 64-bit

    CERTIFICATIONS

    - FCC, CE

    - ErP/EuP ready (ErP/EuP ready power supply   is required)

    The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed. The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
