ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard

ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard
  • ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard
  • ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard
  • ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard
$179.0
RRP:$269.0    Save $90.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard
  • Model Number:
    Z390-PHANTOM-G4
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard


    • Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz

    • 10 Power Phase Design

    • Supports DDR4 4300MHz+ (OC)

    • 2 PCIe 3.0 x16, 3 PCIe 3.0 x1, 1 M.2 Key E for WiFi

    • AMD Quad CrossFireX™ and CrossFireX™

    • Graphics Output Options: HDMI, DVI-D, D-Sub

    • 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps

    • 6 SATA3, 2 Ultra M.2 (PCIe Gen3 x4 & SATA3)

    • 2 USB 3.1 Gen2 (Rear Type-A+C), 6 USB 3.1 Gen1 (4 Front, 2 Rear)

    • Intel® Gigabit LAN

    • Polychrome RGB SYNC


    *This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.



    ASRock Z390 Phantom Gaming 4 ATX LGA1151 Motherboard


    Specifications



    GAMING ARMOR

    Memory

    - 15μ Gold Contact in DIMM Slots

    Internet

    - Intel® LAN


    UNIQUE FEATURE

    ASRock USB 3.1 Gen2

    - ASRock USB 3.1 Gen2 Type-A Port (10 Gb/s)

    - ASRock USB 3.1 Gen2 Type-C Port (10 Gb/s)

    ASRock Super Alloy

    - Premium 50A Power Choke

    - Sapphire Black PCB

    - High Density Glass Fabric PCB

    ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology

    ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)

    ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

    ASRock Live Update & APP Shop


    CPU

    - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz

    - Digi Power design

    - 10 Power Phase design

    - Supports Intel® Turbo Boost 2.0 Technology

    - Supports Intel® K-Series unlocked CPUs

    - Supports ASRock BCLK Full-range Overclocking


    CHIPSET- Intel® Z390
    MEMORY

    - Dual Channel DDR4 Memory Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 4300+(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) / 2933(OC) / 2800(OC) / 2666 / 2400 / 2133 non-ECC, un-buffered memory

    - Supports ECC UDIMM memory modules (operate in non-ECC mode)

    - Max. capacity of system memory: 64GB*

    - Supports Intel® Extreme Memory Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM Slots


    *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.


    BIOS

    - 128Mb AMI UEFI Legal BIOS with multilingual GUI support

    - ACPI 6.0 Compliant wake up events

    - SMBIOS 2.7 Support

    - DRAM, PCH 1.0V, VCCIO, VCCST, VCCSA, VPPM Voltage Multi-adjustment


    GRAPHICS

    - Supports Intel® UHD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® UHD Graphics

    - DirectX 12

    - HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)

    - Three graphics output options: D-Sub, DVI-D and HDMI

    - Supports Triple Monitor

    - Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 30Hz

    - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz

    - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

    - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)

    - Supports HDCP 2.2 with HDMI 1.4 and DisplayPort 1.2 Ports

    - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 and DisplayPort 1.2 Ports


    *Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.


    AUDIO

    - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - ELNA Audio Caps


    *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.


    LAN

    - Gigabit LAN 10/100/1000 Mb/s

    - Giga PHY Intel® I219V

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE


    SLOTS


    - 2 x PCI Express 3.0 x16 Slots (PCIE2/PCIE4: single at x16 (PCIE2); dual at x16 (PCIE2) / x4 (PCIE4))

    - 3 x PCI Express 3.0 x1 Slots (Flexible PCIe)

    - Supports AMD Quad CrossFireX™ and CrossFireX™

    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module and Intel® CNVi (Integrated WiFi/BT)


    *Supports NVMe SSD as boot disks


    STORAGE

    - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 16), NCQ, AHCI and Hot Plug*

    - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

    - 1 x Ultra M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**


    *If M2_1 is occupied by a SATA-type M.2 device, SATA3_5 will be disabled.

    If M2_2 is occupied by a SATA-type M.2 device, SATA3_1 will be disabled.

    If M2_2 is occupied by a PCIe-type M.2 device, SATA3_0 will be disabled.


    ***Supports Intel® Optane™ Technology

    Supports NVMe SSD as boot disks

    Supports ASRock U.2 Kit


    CONNECTOR

    - 1 x COM Port Header

    - 1 x TPM Header

    - 1 x Power LED and Speaker Header

    - 2 x RGB LED Headers*

    - 1 x Addressable LED Header**

    - 1 x CPU Fan Connector (4-pin)***

    - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****

    - 1 x 24 pin ATX Power Connector

    - 1 x 8 pin 12V Power Connector

    - 1 x Front Panel Audio Connector

    - 1 x Thunderbolt™ AIC Connector (5-pin)

    - 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD Protection)

    - 2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (Supports ESD Protection)

    - 1 x Performance Mode / Easy OC Header


    *Support in total up to 12V/3A, 36W LED Strip


    **Supports in total up to 5V/3A, 15W LED Strip


    ***The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.


    ****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.

    CHA_FAN1/WP, CHA_FAN2/WP and CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.


    REAR PANEL I/O

    -

    - 1 x Antenna Ports

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x D-Sub Port

    - 1 x DVI-D Port

    - 1 x HDMI Port

    - 2 x USB 2.0 Ports (Supports ESD Protection)

    - 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection)

    - 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection)

    - 2 x USB 3.1 Gen1 Ports (Supports ESD Protection)

    - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Line in / Front Speaker / Microphone


    SOFTWARE AND UEFI

    Software

    - ASRock Phantom Gaming Tuning

    - ASRock Polychrome RGB

    - ASRock Key Master

    - ASRock XFast LAN

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer


    *These utilities can be downloaded from ASRock Live Update & APP Shop.


    SUPPORT CD- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
    ACCESSORIES

    - Quick Installation Guide, Support CD, I/O Shield

    - 2 x SATA Data Cables

    - 3 x Screws for M.2 Sockets


    HARDWARE MONITOR

    - Temperature Sensing: CPU, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans

    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V, VCCSA, VCCST


    FORM FACTOR

    - ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm

    - Solid Capacitor design


    OS

    - Microsoft® Windows® 10 64-bit

    CERTIFICATIONS- FCC, CE
    - ErP/EuP ready (ErP/EuP ready power supply is required)
