ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard

ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard
  • ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard
  • ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard
  • ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard
$285.0
RRP:$299.0    Save $14.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard
  • Model Number:
    Z390-PHANTOM-GAMING-6
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard


    • Supports 9th and 8th Gen Intel® Core™ processors (Socket 1151)

    • Phantom Gaming 2.5 Gigabit LAN, Intel® Gigabit LAN

    • Digital PWM, 12 Power Phase

    • Supports DDR4 4300+(OC) MHz

    • 3 PCIe 3.0 x16, 3 PCIe 3.0 x1, 1 M.2 (Key E) For WiFi

    • NVIDIA® Quad SLI™, AMD 3-Way CrossFireX™

    • Graphics Output Options : HDMI, D-Sub, DisplayPort

    • 7.1 CH HD Audio (Realtek ALC1220 Audio Codec)

    • Supports Creative Sound Blaster Cinema 5

    • 8 SATA3, 2 Ultra M.2 (PCIe Gen3 x4 & SATA3)

    • 2 USB 3.1 Gen2 10Gb/s (1 Type-A + 1 Type-C)

    • 9 USB 3.1 Gen1 (1 Front Type-C, 4 Front Type-A, 4 Rear)

    • Polychrome RGB SYNC


    *This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.


    ASRock Z390 Phantom Gaming 6 ATX LGA1151 Motherboard



    Specifications



    GAMING ARMOR

    Power

    - Hi-Density Power Connectors (24 pin, 8 pin and 4 pin)

    Memory

    - 15μ Gold Contact in DIMM Slots

    VGA Card

    - 15μ Gold Contact in VGA PCIe Slot (PCIE2)

    Internet

    - Phantom Gaming 2.5G LAN

    Cooling

    - XXL Aluminum Alloy Heatsink

    - Heat Pipe Design

    Audio

    - Creative Sound Blaster™ Cinema 5


    UNIQUE FEATURE

    ASRock USB 3.1 Gen2

    - ASRock USB 3.1 Gen2 Type-A Port (10 Gb/s)

    - ASRock USB 3.1 Gen2 Type-C Port (10 Gb/s)

    ASRock Super Alloy

    - XXL Aluminum Alloy Heatsink

    - Premium 60A Power Choke

    - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke)

    - Dual-Stack MOSFET (DSM)

    - Combo Caps (Nichicon 12K Black Caps)

    - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)

    - I/O Armor

    - Matte Black PCB

    - High Density Glass Fabric PCB

    ASRock Phantom Gaming 2.5G LAN

    ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology

    ASRock Steel Slots

    ASRock Full Coverage M.2 Heatsink

    ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)

    ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

    ASRock Live Update & APP Shop


    CPU

    - Supports 9th and 8th Gen Intel® Core™ Processors (Socket 1151)

    - Digi Power design

    - 12 Power Phase design

    - Supports Intel® Turbo Boost 2.0 Technology

    - Supports Intel® K-Series unlocked CPUs

    - Supports ASRock BCLK Full-range Overclocking

    - Supports ASRock Hyper BCLK Engine II


    CHIPSET- Intel® Z390
    MEMORY


    - Dual Channel DDR4 Memory Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 4300+(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) / 2933(OC) / 2800(OC) / 2666/2400/2133 non-ECC, un-buffered memory

    - Supports ECC UDIMM memory modules (operate in non-ECC mode)

    - Max. capacity of system memory: 64GB*

    - Supports Intel® Extreme Memory Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM Slots


    *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.


    BIOS


    - 2 x 128Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS)

    - Supports Secure Backup UEFI Technology

    - ACPI 6.0 Compliant wake up events

    - SMBIOS 2.7 Support

    - CPU Core/Cache, GT, DRAM, PCH 1.0V, VCCIO, VCCST, VCCSA, VCCPLL, CPU Internal PLL, GT PLL, Ring PLL, System Agent PLL, Memory Controller PLL Voltage Multi-adjustment


    GRAPHICS

    - Supports Intel® UHD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® UHD Graphics

    - DirectX 12

    - HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)

    - Three graphics output options: D-Sub, HDMI and DisplayPort 1.2

    - Supports Triple Monitor

    - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz

    - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz

    - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

    - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)

    - Supports HDCP 2.2 with HDMI 1.4 and DisplayPort 1.2 Ports

    - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 and DisplayPort 1.2 Ports


    *Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.


    AUDIO

    - 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - Nichicon Fine Gold Series Audio Caps

    - 120dB SNR DAC with Differential Amplifier

    - NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets)

    - Pure Power-In

    - Direct Drive Technology

    - PCB Isolate Shielding

    - Impedance Sensing on Rear Out port

    - Individual PCB Layers for R/L Audio Channel

    - RGB LED

    - Gold Audio Jacks

    - 15μ Gold Audio Connector

    - Supports Creative Sound Blaster™ Cinema 5


    LAN

    1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125AG)

    - Supports Phantom Gaming LAN Software

    - Smart Auto Adjust Bandwidth Control

    - Visual User Friendly UI

    - Visual Network Usage Statistics

    - Optimized Default Setting for Game, Browser, and Streaming Modes

    - User Customized Priority Control

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE

    1 x Gigabit LAN 10/100/1000 Mb/s (Intel® I219V)

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE


    SLOTS


    - 3 x PCI Express 3.0 x16 Slots (PCIE2/PCIE4/PCIE6: single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4); triple at x8 (PCIE2) / x8 (PCIE4) / x4 (PCIE6))*

    - 3 x PCI Express 3.0 x1 Slots (Flexible PCIe)

    - Supports AMD Quad CrossFireX™, 3-Way CrossFireX™ and CrossFireX™

    - Supports NVIDIA® Quad SLI™ and SLI™

    - Supports NVIDIA® NVLink™ with dual NVIDIA® GeForce RTX series graphics cards**

    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module and Intel® CNVi (Integrated WiFi/BT)

    - 15μ Gold Contact in VGA PCIe Slot (PCIE2)


    *Supports NVMe SSD as boot disks


    **NVIDIA® NVLink™ Bridge does not come with the package. Please purchase it from NVIDIA® if necessary.


    STORAGE


    - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 16), NCQ, AHCI and Hot Plug*

    - 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug

    - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

    - 1 x Ultra M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**


    *M2_1, SATA3_0 and SATA3_1 share lanes. If either one of them is in use, the others will be disabled.

    M2_2, SATA3_4 and SATA3_5 share lanes. If either one of them is in use, the others will be disabled.


    **Supports Intel® Optane™ Technology

    Supports NVMe SSD as boot disks

    Supports ASRock U.2 Kit


    CONNECTOR

    - 1 x COM Port Header

    - 1 x TPM Header

    - 1 x Power LED and Speaker Header

    - 2 x RGB LED Headers*

    - 1 x Addressable LED Header**

    - 1 x CPU Fan Connector (4-pin)***

    - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****

    - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****

    - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)

    - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)

    - 1 x 4 pin 12V Power Connector (Hi-Density Power Connector)

    - 1 x Front Panel Audio Connector (15μ Gold Audio Connector)

    - 1 x Thunderbolt™ AIC Connector (5-pin)

    - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Intel® Z390) (Supports ESD Protection)

    - 2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection)

    - 1 x Front Panel Type C USB 3.1 Gen1 Header (Intel® Z390) (Supports ESD Protection)

    - 1 x Performance Mode / Easy OC Header

    - 1 x Dr. Debug with LED

    - 1 x Power Button with LED

    - 1 x Reset Button with LED


    *Support in total up to 12V/3A, 36W LED Strip


    **Supports in total up to 5V/3A, 15W LED Strip


    ***The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.


    ****The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.


    *****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.

    CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.


    REAR PANEL I/O

    - 1 x Antenna Ports

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x D-Sub Port

    - 1 x HDMI Port

    - 1 x DisplayPort 1.2

    - 1 x Optical SPDIF Out Port

    - 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports ESD Protection)

    - 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports ESD Protection)

    - 4 x USB 3.1 Gen1 Ports (Intel® Z390) (Supports ESD Protection)

    - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)


    SOFTWARE AND UEFI

    Software

    - ASRock Phantom Gaming Tuning

    - ASRock Phantom Gaming LAN Software

    - ASRock Polychrome RGB

    - ASRock Key Master

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer


    *These utilities can be downloaded from ASRock Live Update & APP Shop.


    SUPPORT CD- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
    ACCESSORIES

    - Quick Installation Guide, Support CD, I/O Shield

    - 4 x SATA Data Cables

    - 1 x ASRock SLI_HB_Bridge_2S Card

    - 3 x Screws for M.2 Sockets


    HARDWARE MONITOR

    - Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V, VCCSA, VCCST, VCCIO


    FORM FACTOR

    - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm


    OS

    - Microsoft® Windows® 10 64-bit

    CERTIFICATIONS- FCC, CE
    - ErP/EuP ready (ErP/EuP ready power supply is required)
