ASRock Z390-Steel-Legend LGA1151 Motherboard

ASRock Z390-Steel-Legend LGA1151 Motherboard
  • ASRock Z390-Steel-Legend LGA1151 Motherboard
  • ASRock Z390-Steel-Legend LGA1151 Motherboard
  • ASRock Z390-Steel-Legend LGA1151 Motherboard
  • ASRock Z390-Steel-Legend LGA1151 Motherboard
  • ASRock Z390-Steel-Legend LGA1151 Motherboard
$259.0
RRP:$279.0    Save $20.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    ASRock Z390-Steel-Legend LGA1151 Motherboard
  • Model Number:
    Z390-STEEL-LEGEND
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    ASRock Z390-Steel-Legend LGA1151 Motherboard


    • Supports 9th and 8th Gen Intel® Core™ processors (Socket 1151)

    • Supports DDR4 4266MHz+ (OC)

    • 2 PCIe 3.0 x16, 3 PCIe 3.0 x1, 1 M.2 Key E for WiFi

    • AMD Quad CrossFireX™ and CrossFireX™

    • Graphics Output: DisplayPort, HDMI

    • 7.1 CH HD Audio (Realtek ALC1200 Audio Codec), Nichicon Fine Gold Series Audio Caps

    • 6 SATA3, 2 Ultra M.2 (PCIe Gen3 x4 & SATA3)

    • 2 USB 3.2 Gen2 (Rear Type A+C)

    • 6 USB 3.2 Gen1 (4 Front, 2 Rear)

    • Intel® Gigabit LAN

    • Polychrome RGB SYNC


    ASRock Z390-Steel-Legend LGA1151 Motherboard


    Specifications


    UNIQUE FEATURE

    ASRock USB 3.2 Gen2

    - ASRock USB 3.2 Gen2 Type-A   Port (10 Gb/s)

    - ASRock USB 3.2 Gen2 Type-C   Port (10 Gb/s)

    ASRock Super Alloy

    - XXL Aluminum Alloy   Heatsink

    - Premium 60A Power Choke

    - Nichicon 12K Black Caps   (100% Japan made high quality conductive polymer capacitors)

    - Shaped PCB Design

    - Matte Black PCB

    - High Density Glass Fabric   PCB

    ASRock Intel® 4-Layer Memory   POOL (Planes on Outer Layers) Technology

    ASRock Steel Slot

    ASRock Full Coverage M.2   Heatsink

    ASRock Ultra M.2 (PCIe Gen3   x4 & SATA3) ASRock POST Status Checker (PSC)

    ASRock Full Spike Protection   (for all USB, Audio, LAN Ports)

    ASRock Live Update & APP   Shop

    CPU

    - Supports 9th and 8th Gen   Intel® Core™ Processors (Socket 1151)

    - Digi Power design

    - 8 Power Phase design

    - Supports Intel® Turbo   Boost 2.0 Technology

    - Supports Intel® K-Series   unlocked CPUs

    - Supports ASRock BCLK   Full-range Overclocking

    CHIPSET

    - Intel® Z390

    MEMORY

    - Dual Channel DDR4 Memory   Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 4266+(OC) /   4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) /   2933(OC) / 2800(OC) / 2666 / 2400 / 2133 non-ECC, un-buffered memory

    - Supports ECC UDIMM memory   modules (operate in non-ECC mode)

    - Max. capacity of system   memory: 128GB*

    - Supports Intel® Extreme   Memory Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM   Slots

    *Due to the operating system   limitation, the actual memory size may be less than 4GB for the reservation   for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit   CPU, there is no such limitation.

    BIOS

    - 128Mb AMI UEFI Legal BIOS   with multilingual GUI support

    - ACPI 6.0 Compliant wake up   events

    - SMBIOS 2.7 Support

    - DRAM, PCH 1.0V, VCCIO,   VCCST, VCCSA, VPPM Voltage Multi-adjustment

    GRAPHICS

    - Supports Intel® UHD   Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and   MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology,   Intel® Insider™, Intel® UHD Graphics

    - DirectX 12

    - HWA Encode/Decode:   AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit   (Decode only), MPEG2, MJPEG, VC-1

    - Dual graphics output:   Support HDMI and DisplayPort 1.2 ports by independent display controllers

    - Supports HDMI 1.4 with   max. resolution up to 4K x 2K (4096x2160) @ 30Hz

    - Supports DisplayPort 1.2   with max. resolution up to 4K x 2K (4096x2304) @ 60Hz

    - Supports Auto Lip Sync,   Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port   (Compliant HDMI monitor is required)

    - Supports HDCP 2.2 with   HDMI 1.4 and DisplayPort 1.2 Ports

    - Supports 4K Ultra HD (UHD)   playback with HDMI 1.4 and DisplayPort 1.2 Ports

    *Intel® UHD Graphics   Built-in Visuals and the VGA outputs can be supported only with processors   which are GPU integrated.

    AUDIO

    - 7.1 CH HD Audio with   Content Protection (Realtek ALC1200 Audio Codec)

    - Premium Blu-ray Audio   support

    - Supports Surge Protection

    - Nichicon Fine Gold Series   Audio Caps

    - 110dB SNR DAC with   Differential Amplifier

    - PCB Isolate Shielding

    - Individual PCB Layers for   R/L Audio Channel

    - Gold Audio Jacks

    LAN

    - Gigabit LAN 10/100/1000   Mb/s

    - Giga PHY Intel® I219V

    - Supports Wake-On-LAN

    - Supports Lightning/ESD   Protection

    - Supports Energy Efficient   Ethernet 802.3az

    - Supports PXE

    SLOTS

    - 2 x PCI Express 3.0 x16   Slots (PCIE1/PCIE4: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE4))*

    - 3 x PCI Express 3.0 x1   Slots (Flexible PCIe)

    - Supports AMD Quad   CrossFireX™ and CrossFireX™

    - 1 x M.2 Socket (Key E),   supports type 2230 WiFi/BT module and Intel® CNVi (Integrated WiFi/BT)

    *Supports NVMe SSD as boot   disks

    STORAGE

    - 6 x SATA3 6.0 Gb/s   Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid   Storage Technology 16), NCQ, AHCI and Hot Plug*

    - 1 x Ultra M.2 Socket   (M2_1), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s   module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

    - 1 x Ultra M.2 Socket   (M2_2), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and   M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

    *If M2_1 is occupied by a   SATA-type M.2 device, SATA3_1 will be disabled.

    If M2_2 is occupied by a   SATA-type M.2 device, SATA3_5 will be disabled.

    If M2_1 is occupied by a   PCIE-type M.2 device, SATA3_0 will be disabled.

    **Supports Intel® Optane™   Technology

    Supports NVMe SSD as boot   disks

    Supports ASRock U.2 Kit

    CONNECTOR

    - 1 x COM Port Header

    - 1 x SPI TPM Header

    - 1 x Power LED and Speaker   Header

    - 2 x RGB LED Headers*

    - 1 x Addressable LED   Header**

    - 1 x CPU Fan Connector   (4-pin)***

    - 1 x CPU/Water Pump Fan   Connector (4-pin) (Smart Fan Speed Control)****

    - 3 x Chassis/Water Pump Fan   Connectors (4-pin) (Smart Fan Speed Control)*****

    - 1 x 24 pin ATX Power   Connector

    - 1 x 8 pin 12V Power   Connector

    - 1 x Front Panel Audio   Connector

    - 1 x Thunderbolt™ AIC   Connector (5-pin)

    - 2 x USB 2.0 Headers   (Support 3 USB 2.0 ports) (Supports ESD Protection)

    - 2 x USB 3.2 Gen1 Headers (Support   4 USB 3.2 Gen1 ports) (Supports ESD Protection)

    *Support in total up to   12V/3A, 36W LED Strip

    **Supports in total up to   5V/3A, 15W LED Strip

    ***The CPU Fan Connector   supports the CPU fan of maximum 1A (12W) fan power.

    ****The CPU/Water Pump Fan   supports the water cooler fan of maximum 2A (24W) fan power.

    *****The Chassis/Water Pump   Fan supports the water cooler fan of maximum 2A (24W) fan power.

    CPU_FAN2/WP, CHA_FAN1/WP,   CHA_FAN2/WP and CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.

    REAR PANEL I/O

    1 x Antenna Bracket

    - 1 x PS/2 Mouse/Keyboard   Port

    - 1 x HDMI Port

    - 1 x DisplayPort 1.2

    - 1 x Optical SPDIF Out Port

    - 2 x USB 2.0 Ports   (Supports ESD Protection)

    - 1 x USB 3.2 Gen2 Type-A   Port (10 Gb/s) (ReDriver) (Supports ESD Protection)

    - 1 x USB 3.2 Gen2 Type-C   Port (10 Gb/s) (ReDriver) (Supports ESD Protection)

    - 2 x USB 3.2 Gen1 Ports   (Intel® Z390) (Supports ESD Protection)

    - 1 x RJ-45 LAN Port with   LED (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Rear   Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio   Jacks)

    SOFTWARE AND UEFI

    Software

    - ASRock A-Tuning

    - ASRock Polychrome SYNC

    - ASRock XFast LAN

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in   UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer

    *These utilities can be   downloaded from ASRock Live Update & APP Shop.

    SUPPORT CD

    - Drivers, Utilities,   AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar

    ACCESSORIES

    - Quick Installation Guide,   Support CD, I/O Shield

    - 2 x SATA Data Cables

    - 3 x Screws for M.2 Sockets

    - 2 x Standoffs for M.2   Sockets

    HARDWARE MONITOR

    Temperature Sensing: CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Tachometer: CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust   chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water   Pump Fans

    - Fan Multi-Speed Control:   CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Voltage monitoring: +12V,   +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V, VCCSA, VCCST

    FORM FACTOR

    - ATX Form Factor: 12.0-in x   9.6-in, 30.5 cm x 24.4 cm

    OS

    - Microsoft® Windows® 10   64-bit

    CERTIFICATIONS

    - FCC, CE

    - ErP/EuP ready (ErP/EuP   ready power supply is required)

    The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

    The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
