Specifications

  • Product Name:
    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard
  • Model Number:
    Z490 Phantom Gaming 4
  • Brand:
  • Manufacturer Warranty:
    2 Year
  • Description

     ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard


    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard

    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard

    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard

    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard

    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard

    ASRock Z490 Phantom Gaming 4 LGA 1200 ATX Motherboard

    SPECIFICATIONS:

    Unique Feature

    ASRock USB 3.2 Gen2

    - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)

    - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s)

    ASRock Super Alloy

    - Premium 50A Power Choke

    - Sapphire Black PCB

    - High Density Glass Fabric PCB

    ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology

    ASRock Steel Slots

    ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)

    ASRock POST Status Checker (PSC)

    ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

    ASRock Live Update & APP Shop

    Gaming Armor



    Memory

    - 15μ Gold Contact in DIMM Slots

    Internet

    - Intel® LAN

    Audio

    - Nahimic Audio

    Chipset



    - Intel® Z490

    Memory

    - Dual Channel DDR4 Memory Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 4400+(OC)* / 4333(OC) / 4266(OC) / 4133(OC) /   4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) / 2933 / 2800   / 2666 / 2400 / 2133 non-ECC, un-buffered memory

    - Supports ECC UDIMM memory modules (operate in non-ECC mode)

    - Max. capacity of system memory: 128GB**

    - Supports Intel® Extreme Memory Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM Slots

    BIOS

    - 128Mb AMI UEFI Legal BIOS with multilingual GUI support

    - ACPI 6.0 Compliant wake up events

    - SMBIOS 2.7 Support

    - CPU Core/Cache, GT, DRAM, PCH, VCCIO, VCCST, VCCSA Voltage   Multi-adjustment

    Graphics



    - Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265   10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1*

    - Graphics, Media & Compute: Microsoft® DirectX 12, OpenGL 4.5,   Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid / Switchable   Graphics, OpenCL 2.1

    - Display & Content Security: Rec. 2020 (Wide Color Gamut),   Microsoft® PlayReady 3.0, Intel® SGX Content Protection, UHD/HDR Blu-ray Disc

    - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @   30Hz

    - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit   Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)

    - Supports HDCP 2.3 with HDMI 1.4 Port

    - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port

    Audio



    - 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio   Codec)

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - PCB Isolate Shielding

    - Individual PCB Layers for R/L Audio Channel

    - Nahimic Audio

    LAN

    - Gigabit LAN 10/100/1000 Mb/s

    - Giga PHY Intel® I219V

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE

    Slots

    - 2 x PCI Express 3.0 x16 Slots (PCIE2/PCIE4: single at x16 (PCIE2);   dual at x16 (PCIE2) / x4 (PCIE4)*

    - 3 x PCI Express 3.0 x1 Slots

    - Supports AMD Quad CrossFireX™ and CrossFireX™

    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module and   Intel® CNVi (Integrated WiFi/BT)

    Storage

    - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID   5, RAID 10, Intel® Rapid Storage Technology 17), NCQ, AHCI and Hot Plug*

    - 1 x Ultra M.2 Socket (M2_2), supports M Key type 2260/2280/22110   M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32   Gb/s)**

    Connector

    - 1 x COM Port Header

    - 1 x SPI TPM Header

    - 1 x Power LED and Speaker Header

    - 2 x RGB LED Headers*

    - 2 x Addressable LED Headers**

    - 1 x CPU Fan Connector (4-pin)***

    - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed   Control)****

    - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed   Control)*****

    - 1 x 24 pin ATX Power Connector

    - 1 x 8 pin 12V Power Connector

    - 1 x 4 pin 12V Power Connector

    - 1 x Front Panel Audio Connector

    - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock   Thunderbolt™ 3 AIC R2.0 Card only)

    - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD   Protection)

    - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports   ESD Protection)

    Rear Panel I/O

    - 2 x Antenna Ports

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x HDMI Port

    - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports ESD   Protection)

    - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports ESD   Protection)

    - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection)

    - 2 x USB 2.0 Ports (Supports ESD Protection)

    - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Line in / Front Speaker / Microphone

    Software and UEFI

    Software

    - ASRock Motherboard Utility (Phantom Gaming Tuning)

    - ASRock Polychrome SYNC

    - ASRock Key Master

    - ASRock XFast LAN

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer

    Support CD

    - Drivers, Utilities, AntiVirus Software (Trial Version), Google   Chrome Browser and Toolbar

    Accessories

    - Quick Installation Guide, Support CD, I/O Shield

    - 2 x SATA Data Cables

    - 2 x Screws for M.2 Sockets

    Hardware monitor

    - Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump   Fans

    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH,   VCCSA, VCCST, VCCIO

    Form Factor

    - ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm

    - Solid Capacitor design

    OS

    - Microsoft® Windows® 10 64-bit
