ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard

ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard
  • ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard
  • ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard
  • ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard
$199.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Free Click & Collect  Question Mark

Your store is set to:

Loading...

   Fast Delivery  Question Mark

Order within 18hrs and 28mins
for Next Day Dispatch

Question Mark

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Click & Collect.

Specifications

  • Product Name:
    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard
  • Model Number:
    Z490M Pro4
  • Brand:
  • Manufacturer Warranty:
    2 Year
  • Description

    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard


    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard

    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard

    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard

    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard

    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard

    ASRock Z490M Pro4 Gaming 4 LGA 1200 mATX Motherboard


    SPECIFICATIONS:

    Unique Feature



    ASRock USB 3.2 Gen2

    - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)

    - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s)

    ASRock Super Alloy

    - Premium 50A Power Choke

    - Sapphire Black PCB

    - High Density Glass Fabric PCB

    ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology

    ASRock Steel Slots

    ASRock Full Coverage M.2 Heatsink

    ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3

    ASRock POST Status Checker (PSC)

    ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

    ASRock Live Update & APP Shop

    Chipset



    - Intel® Z490

    Memory



    - Dual Channel DDR4 Memory Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 4500+(OC)* / 4400(OC) / 4333(OC) / 4266(OC) /   4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) /   2933/2800/2666 / 2400 / 2133 non-ECC, un-buffered memory

    - Supports ECC UDIMM memory modules (operate in non-ECC mode)

    - Max. capacity of system memory: 128GB*

    - Supports Intel® Extreme Memory Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM Slots

    BIOS

    - 128Mb AMI UEFI Legal BIOS with multilingual GUI support

    - ACPI 6.0 Compliant wake up events

    - SMBIOS 2.7 Support

    - CPU Core/Cache, GT, DRAM, VPPM,VTTDDR, PCH 1.05V, VCCIO, VCCST,   VCCSA, VCCPLL,VCCPLL_OC, CPU Internal PLL, GT PLL, Ring PLL, System Agent   PLL, Memory Controller PLL Voltage Multi-adjustment

    Graphics



    - Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265   10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1**

    - Graphics, Media & Compute: Microsoft® DirectX 12, OpenGL 4.5,   Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid / Switchable   Graphics, OpenCL 2.1

    - Display & Content Security: Rec. 2020 (Wide Color Gamut),   Microsoft® PlayReady 3.0, Intel® SGX Content Protection, UHD/HDR Blu-ray Disc

    - Three graphics output options: D-Sub, HDMI and DisplayPort 1.4

    - Supports Triple Monitor

    - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @   30Hz

    - Supports DisplayPort 1.4 with max. resolution up to 4K x 2K   (4096x2304) @ 60Hz

    - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

    - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit   Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)

    - Supports HDCP 2.3 with HDMI 1.4 and DisplayPort 1.4 Ports

    - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 and DisplayPort   1.4 Ports

    Audio

    - 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio   Codec)

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - PCB Isolate Shielding

    - Individual PCB Layers for R/L Audio Channel

    - Nahimic Audio

    LAN



    - Gigabit LAN 10/100/1000 Mb/s

    - Giga PHY Intel® I219V

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet 802.3az

    - Supports PXE

    Slots

    - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE4: single at x16 (PCIE1);   dual at x16 (PCIE1) / x4 (PCIE4))*

    - 2 x PCI Express 3.0 x1 Slots

    - Supports AMD Quad CrossFireX™ and CrossFireX™

    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module and   Intel® CNVi (Integrated WiFi/BT)

    Storage



    - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID   5, RAID 10, Intel® Rapid Storage Technology 17), NCQ, AHCI and Hot Plug*

    - 2 x Ultra M.2 Sockets (M2_1 and M2_2), support M Key type 2280 M.2   SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

    Connector

    - 1 x SPI TPM Header

    - 1 x Chassis Intrusion and Speaker Header

    - 2 x RGB LED Headers*

    - 2 x Addressable LED Headers**

    - 1 x CPU Fan Connector (4-pin)***

    - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed   Control)****

    - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed   Control)*****

    - 1 x 24 pin ATX Power Connector

    - 1 x 8 pin 12V Power Connector

    - 1 x 4 pin 12V Power Connector

    - 1 x Front Panel Audio Connector

    - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock   Thunderbolt™ 3 AIC R2.0 Card only)

    Rear Panel I/O

    - 1 x Antenna Bracket

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x D-Sub Port

    - 1 x HDMI Port

    - 1 x DisplayPort 1.4

    - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection)

    - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection)

    - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection)

    - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Line in / Front Speaker / Microphone

    Software and UEFI



    Software

    - ASRock Motherboard Utility (A-Tuning)

    - ASRock Polychrome SYNC

    - ASRock XFast LAN

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer

    Support CD

    - Drivers, Utilities, AntiVirus Software (Trial Version), Google   Chrome Browser and Toolbar

    Accessories



    - Quick Installation Guide, Support CD, I/O Shield

    - 2 x SATA Data Cables

    - 3 x Screws for M.2 Sockets

    Hardware monitor



    - Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump   Fans

    - CASE OPEN detection

    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH   1.05V, VCCSA, VCCST, VCCIO, VCCPLL,VCCPLL_OC

    Form Factor

    - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm

    - Solid Capacitor design

    OS

    - Microsoft® Windows® 10 64-bit
