Specifications

  • Product Name:
    Asrock B460 Phantom Gaming LGA 1200 ATX Motherboard
  • Model Number:
    B460-PHANTOM-GAMING-4
  • Brand:
  • Manufacturer Warranty:
    3 Year
  • Description

     Asrock B460 Phantom Gaming LGA 1200 ATX Motherboard
    SPECIFICATIONS:

    UNIQUE FEATURE

     ASRock Super Alloy

    - Premium 50A Power Choke

    - Sapphire Black PCB

    - High Density Glass Fabric PCB

    ASRock Intel® 4-Layer Memory POOL   (Planes on Outer Layers) Technology

    ASRock Steel Slots

    ASRock Ultra M.2 (PCIe Gen3 x4 &   SATA3)

    ASRock POST Status Checker (PSC)

    ASRock Full Spike Protection (for all   USB, Audio, LAN Ports)

    ASRock Live Update & APP Shop

    CPU

     - Supports 10th Gen Intel®   Core™ Processors (Socket 1200)

    - Digi Power design

    - 9 Power Phase design

    - Supports Intel® Turbo Boost Max 3.0   Technology

    CHIPSET

     - Intel® B460

    MEMORY

     - Dual Channel DDR4 Memory   Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 2933 / 2800 / 2666 /   2400 / 2133 non-ECC, un-buffered memory*

    - Supports ECC UDIMM memory modules   (operate in non-ECC mode)

    - Max. capacity of system memory:   128GB**

    - Supports Intel® Extreme Memory   Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM Slots

    BIOS

     - 128Mb AMI UEFI Legal BIOS   with multilingual GUI support

    - ACPI 6.0 Compliant wake up events

    - SMBIOS 2.7 Support

    - CPU Core/Cache, GT, DRAM, PCH,   VCCIO, VCCST, VCCSA Voltage Multi-adjustment

    GRAPHICS

     - Hardware Accelerated Codecs:   AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG   2, MJPEG, VC-1*

    - Graphics, Media & Compute:   Microsoft® DirectX 12, OpenGL 4.5, Intel® Built In Visuals, Intel® Quick Sync   Video, Hybrid / Switchable Graphics, OpenCL 2.1

    - Display & Content Security:   Rec. 2020 (Wide Color Gamut), Microsoft® PlayReady 3.0, Intel® SGX Content   Protection, UHD Blu-ray Disc

    - Supports HDMI 1.4 with max.   resolution up to 4K x 2K (4096x2160) @ 30Hz

    - Supports Auto Lip Sync, Deep Color   (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant   HDMI monitor is required)

    - Supports HDCP 2.3 with HDMI 1.4   Port

    - Supports 4K Ultra HD (UHD) playback   with HDMI 1.4 Port

    AUDIO

     - 7.1 CH HD Audio with Content   Protection (Realtek ALC1200 Audio Codec)

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - PCB Isolate Shielding

    - Individual PCB Layers for R/L Audio   Channel

    - Nahimic Audio

    LAN

     - Gigabit LAN 10/100/1000 Mb/s

    - Giga PHY Intel® I219V

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet   802.3az

    - Supports PXE

    SLOTS

     - 2 x PCI Express 3.0 x16 Slots   (PCIE1/PCIE3: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3)*

    - 2 x PCI Express 3.0 x1 Slots

    - Supports AMD Quad CrossFireX™ and   CrossFireX™

    - 1 x M.2 Socket (Key E), supports   type 2230 WiFi/BT module

    STORAGE

     - 6 x SATA3 6.0 Gb/s   Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid   Storage Technology 17), NCQ, AHCI and Hot Plug*

    - 1 x Ultra M.2 Socket (M2_2),   supports M Key type 2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express   module up to Gen3 x4 (32 Gb/s)**

    CONNECTOR

     - 1 x COM Port Header

    - 1 x SPI TPM Header

    - 1 x Chassis Intrusion and Speaker   Header

    - 2 x RGB LED Headers*

    - 2 x Addressable LED Headers**

    - 1 x CPU Fan Connector (4-pin)***

    - 1 x CPU/Water Pump Fan Connector   (4-pin) (Smart Fan Speed Control)****

    - 5 x Chassis/Water Pump Fan   Connectors (4-pin) (Smart Fan Speed Control)*****

    - 1 x 24 pin ATX Power Connector

    - 1 x 8 pin 12V Power Connector

    - 1 x Front Panel Audio Connector

    - 1 x Thunderbolt™ AIC Connector   (5-pin) (Supports ASRock Thunderbolt™ 3 AIC R2.0 Card only)

    - 2 x USB 2.0 Headers (Supports 3 USB   2.0 ports) (Supports ESD Protection)

    - 2 x USB 3.2 Gen1 Headers (Support 4   USB 3.2 Gen1 ports) (Supports ESD Protection)

    REAR PANEL I/O

     - 1 x Antenna Bracket

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x HDMI Port

    - 4 x USB 3.2 Gen1 Type-A Ports   (Supports ESD Protection)

    - 2 x USB 2.0 Ports (Supports ESD   Protection)

    - 1 x RJ-45 LAN Port with LED   (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Line in / Front   Speaker / Microphone

    SOFTWARE AND UEFI

     Software

    - ASRock Motherboard Utility (Phantom   Gaming Tuning)

    - ASRock Polychrome SYNC

    - ASRock Key Master

    - ASRock XFast LAN

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer

    SUPPORT CD

     - Drivers, Utilities, AntiVirus   Software (Trial Version), Google Chrome Browser and Toolbar

    ACCESSORIES

     - Quick Installation Guide,   Support CD, I/O Shield

    - 2 x SATA Data Cables

    - 2 x Screws for M.2 Sockets

    HARDWARE MONIOR

     - Temperature Sensing: CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, CPU/Water   Pump, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan   speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - CASE OPEN detection

    - Voltage monitoring: +12V, +5V,   +3.3V, CPU Vcore, DRAM, VPPM, PCH, VCCST

    FORM FACTOR

     - ATX Form Factor: 12.0-in x   8.8-in, 30.5 cm x 22.4 cm

    - Solid Capacitor design

    OS

     - Microsoft® Windows® 10 64-bit
