Asrock H470 Phantom Gaming 4 LGA 1200 ATX Motherboard

Asrock H470 Phantom Gaming 4 LGA 1200 ATX Motherboard
  • Asrock H470 Phantom Gaming 4 LGA 1200 ATX Motherboard
  • Asrock H470 Phantom Gaming 4 LGA 1200 ATX Motherboard
  • Asrock H470 Phantom Gaming 4 LGA 1200 ATX Motherboard
$139.0
Was: $189.0    Save $50.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

Buy Now, Pay Later:
   Free Click & Collect

Your store is set to:

Loading...

   Fast Delivery

Order within 15hrs and 51mins
for Next Day Dispatch

  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Click & Collect.

Specifications

  • Product Name:
    Asrock H470 Phantom Gaming 4 LGA 1200 ATX Motherboard
  • Model Number:
    H470-PHANTOM-GAMING-4
  • Brand:
  • Manufacturer Warranty:
    3 Year
  • Description

    Asrock H370 Phantom Gaming 4 LGA 1200 ATX Motherboard
    SPECIFICATIONS:

    UNIQUE FEATURE

     ASRock USB 3.2 Gen2

    - ASRock USB 3.2 Gen2 Type-A Port (10   Gb/s)

    - ASRock USB 3.2 Gen2 Type-C Port (10   Gb/s)

    ASRock Super Alloy

    - Premium 50A Power Choke

    - Sapphire Black PCB

    - High Density Glass Fabric PCB

    ASRock Intel® 4-Layer Memory POOL   (Planes on Outer Layers) Technology

    ASRock Ultra M.2 (PCIe Gen3 x4 &   SATA3)

    ASRock POST Status Checker (PSC)

    ASRock Full Spike Protection (for all   USB, Audio, LAN Ports)

    ASRock Live Update & APP Shop

    CPU



    - Supports 10th Gen Intel® Core™   Processors (Socket 1200)

    - Digi Power design

    - 10 Power Phase design

    - Supports Intel® Turbo Boost Max 3.0   Technology

    CHIPSET



    - Intel® H470

    MEMORY



    - Dual Channel DDR4 Memory Technology

    - 4 x DDR4 DIMM Slots

    - Supports DDR4 2933 / 2800 / 2666 /   2400 / 2133 non-ECC, un-buffered memory*

    - Supports ECC UDIMM memory modules   (operate in non-ECC mode)

    - Max. capacity of system memory:   128GB**

    - Supports Intel® Extreme Memory   Profile (XMP) 2.0

    - 15μ Gold Contact in DIMM Slots

    BIOS

     - 128Mb AMI UEFI Legal BIOS   with multilingual GUI support

    - ACPI 6.0 Compliant wake up events

    - SMBIOS 2.7 Support

    - CPU Core/Cache, GT, DRAM, PCH,   VCCIO, VCCST, VCCSA Voltage Multi-adjustment

    GRAPHICS



    - Hardware Accelerated Codecs:   AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG   2, MJPEG, VC-1**

    - Graphics, Media & Compute:   Microsoft® DirectX 12, OpenGL 4.5, Intel® Built In Visuals, Intel® Quick Sync   Video, Hybrid / Switchable Graphics, OpenCL 2.1

    - Display & Content Security:   Rec. 2020 (Wide Color Gamut), Microsoft® PlayReady 3.0, Intel® SGX Content   Protection, UHD/HDR Blu-ray Disc

    - Dual graphics output: support HDMI   and DisplayPort 1.4 ports by independent display controllers

    - Supports HDMI 1.4 with max.   resolution up to 4K x 2K (4096x2160) @ 30Hz

    - Supports DisplayPort 1.4 with max.   resolution up to 4K x 2K (4096x2304) @ 60Hz

    - Supports Auto Lip Sync, Deep Color   (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant   HDMI monitor is required)

    - Supports HDCP 2.3 with HDMI 1.4 and   DisplayPort 1.4 Ports

    - Supports 4K Ultra HD (UHD) playback   with HDMI 1.4 and DisplayPort 1.4 Ports

    AUDIO



    - 7.1 CH HD Audio with Content Protection   (Realtek ALC1200 Audio Codec)

    - Premium Blu-ray Audio support

    - Supports Surge Protection

    - PCB Isolate Shielding

    - Individual PCB Layers for R/L Audio   Channel

    - Nahimic Audio

    LAN

     - Gigabit LAN 10/100/1000 Mb/s

    - Giga PHY Intel® I219V

    - Supports Wake-On-LAN

    - Supports Lightning/ESD Protection

    - Supports Energy Efficient Ethernet   802.3az

    - Supports PXE

    SLOTS

     2 x PCI Express 3.0 x16 Slots   (PCIE2/PCIE4: single at x16 (PCIE2); dual at x16 (PCIE2) / x4 (PCIE4)*

    - 3 x PCI Express 3.0 x1 Slots

    - Supports AMD Quad CrossFireX™ and   CrossFireX™

    - 1 x M.2 Socket (Key E), supports   type 2230 WiFi/BT module and Intel® CNVi (Integrated WiFi/BT)

    STORAGE



    - 6 x SATA3 6.0 Gb/s Connectors,   support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage   Technology 17), NCQ, AHCI and Hot Plug*

    - 1 x Ultra M.2 Socket (M2_1),   supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express   module up to Gen3 x4 (32 Gb/s)**

    - 1 x Ultra M.2 Socket (M2_2),   supports M Key type 2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI   Express module up to Gen3 x4 (32 Gb/s)**

    CONNECTOR

     - 1 x SPI TPM Header

    - 1 x Power LED and Speaker Header

    - 2 x RGB LED Headers*

    - 2 x Addressable LED Headers**

    - 1 x CPU Fan Connector (4-pin)***

    - 1 x CPU/Water Pump Fan Connector   (4-pin) (Smart Fan Speed Control)****

    - 4 x Chassis/Water Pump Fan   Connectors (4-pin) (Smart Fan Speed Control)****

    - 1 x 24 pin ATX Power Connector

    - 1 x 8 pin 12V Power Connector

    - 1 x 4 pin 12V Power Connector

    - 1 x Front Panel Audio Connector

    - 1 x Thunderbolt™ AIC Connector   (5-pin) (Supports ASRock Thunderbolt™ 3 AIC R2.0 Card only)

    - 2 x USB 2.0 Headers (Support 4 USB   2.0 ports) (Supports ESD Protection)

    - 2 x USB 3.2 Gen1 Headers (Support 4   USB 3.2 Gen1 ports) (Supports ESD Protection)

    REAR PANEL I/O



    - 1 x Antenna Bracket

    - 1 x PS/2 Mouse/Keyboard Port

    - 1 x HDMI Port

    - 1 x DisplayPort 1.4

    - 1 x USB 3.2 Gen2 Type-A Port (10   Gb/s) (ReDriver) (Supports ESD Protection)

    - 1 x USB 3.2 Gen2 Type-C Port (10   Gb/s) (ReDriver) (Supports ESD Protection)

    - 2 x USB 3.2 Gen1 Ports (Supports   ESD Protection)

    - 2 x USB 2.0 Ports (Supports ESD   Protection)

    - 1 x RJ-45 LAN Port with LED   (ACT/LINK LED and SPEED LED)

    - HD Audio Jacks: Line in / Front   Speaker / Microphone

    SOFTWARE AND UEFI



    Software

    - ASRock Motherboard Utility (Phantom   Gaming Tuning)

    - ASRock Polychrome SYNC

    - ASRock Key Master

    - ASRock XFast LAN

    UEFI

    - ASRock EZ Mode

    - ASRock Full HD UEFI

    - ASRock My Favorites in UEFI

    - ASRock Instant Flash

    - ASRock Internet Flash

    - ASRock Easy RAID Installer

    SUPPORT CD

     - Drivers, Utilities, AntiVirus   Software (Trial Version), Google Chrome Browser and Toolbar

    ACCESSORIES



    - Quick Installation Guide, Support   CD, I/O Shield

    - 2 x SATA Data Cables

    - 3 x Screws for M.2 Sockets

    HARDWARE MONIOR

     - Temperature Sensing: CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Tachometer: CPU, CPU/Water   Pump, Chassis/Water Pump Fans

    - Quiet Fan (Auto adjust chassis fan   speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans

    - Fan Multi-Speed Control: CPU,   CPU/Water Pump, Chassis/Water Pump Fans

    - Voltage monitoring: +12V, +5V,   +3.3V, CPU Vcore, DRAM, VPPM, PCH, VCCSA, VCCST, VCCIO

    FORM FACTOR



    - ATX Form Factor: 12.0-in x 8.8-in,   30.5 cm x 22.4 cm

    - Solid Capacitor design

    OS



    - Microsoft® Windows® 10 64-bit
