Asus B365M-A LGA1151 mATX Motherboard

Asus B365M-A LGA1151 mATX Motherboard
  • Asus B365M-A LGA1151 mATX Motherboard
  • Asus B365M-A LGA1151 mATX Motherboard
  • Asus B365M-A LGA1151 mATX Motherboard
  • Asus B365M-A LGA1151 mATX Motherboard
$129.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus B365M-A LGA1151 mATX Motherboard
  • Model Number:
    Asus B365M-A
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    Asus B365M-A LGA1151 mATX Motherboard


    • ASUS OptiMem: Careful routing of traces and vias to preserve signal integrity for improved memory stability.

    • Fan Xpert 2+: Flexible controls for ultimate cooling and quietness, plus GPU-temperature sensing for cooler gaming.

    • 5X Protection III: Multiple hardware safeguards for all-round protection.

    • ASUS Aura Sync header: Onboard connector for RGB LED strips, easily synced with an ever-growing portfolio of Aura Sync-capable hardware.

    • Ultrafast connectivity: Supreme flexibility with native M.2 support for Lightning-fast storage speeds


    Asus B365M-A LGA1151 mATX Motherboard

    Asus B365M-A LGA1151 mATX Motherboard

    Asus B365M-A LGA1151 mATX Motherboard


    Specifications


    CPU

    Intel® Socket 1151 for 9th /   8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors

    Supports Intel® 14 nm CPU

    Supports Intel® Turbo Boost   Technology 2.0

    * The Intel® Turbo Boost   Technology 2.0 support depends on the CPU types.

    * Refer to www.asus.com for CPU   support list

    CHIPSET

    Intel® B365

    MEMORY

    Intel®   B365 Chipset

    4 x DIMM,   Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory

    Dual   Channel Memory Architecture

    Supports   Intel® Extreme Memory Profile (XMP)

    * Refer to   www.asus.com for the Memory QVL (Qualified Vendors Lists).

    * The   maximum memory frequency supported varies by processor

    ** DDR4   2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen.   6-core or higher processors.

    GRAPHICS

    Integrated   Graphics Processor- Intel® HD Graphics support

    Multi-VGA   output support : HDMI/DVI-D/D-Sub ports

    - Supports   HDMI 1.4b with max. resolution 4096 x 2160 @ 30 Hz

    - Supports   DVI with max. resolution 1920 x 1200 @ 60 Hz

    - Supports   D-sub with max. resolution 1920 x 1200 @ 60 Hz

    Maximum   shared memory of 1024 MB (for iGPU exclusively)

    Supports   Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™

    EXPANSION SLOTS

    1 x PCIe 3.0 x16 (x16 mode)

    2 x PCIe 3.0/2.0 x1

    STORAGE

    Intel®   B365 Chipset :

    1 x M.2   Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA   & PCIE 3.0 x 4 mode)

    1 x M.2   Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0   x 4 mode)

    6 x SATA   6Gb/s port(s), gray

    Support   Raid 0, 1, 5, 10

    Intel®   Rapid Storage Technology supports

    Intel®   Optane™ Memory Ready

    LAN

    Realtek® RTL8111H, 1 x Gigabit   LAN

    ASUS LAN Guard

    AUDIO

    Realtek® ALC887 8-Channel High   Definition Audio CODEC

    - Supports : Jack-detection,   Front Panel Jack-retasking

    Audio Feature :

    - LED-illuminated design -   Brighten up your build with the gorgeous illuminated audio trace path.

    - Audio Shielding: Ensures   precision analog/digital separation and greatly reduced multi-lateral   interference

    - Dedicated audio PCB layers:   Separate layers for left and right channels to guard the quality of the   sensitive audio signals

    - Premium Japanese audio   capacitors: Provide warm, natural and immersive sound with exceptional   clarity and fidelity

    * Choose the chassis with HD   audio module in front panel to support 8-channel audio output.

    USB PORTS

    Intel®   B365 Chipset :

    Intel®   B365 Chipset :

    7 x USB   3.1 Gen 1 up to 5Gbps port(s) (5 at back panel, , 4 x Type-A+1 x Type-C, 2 at   mid-board)

    Intel®   B365 Chipset :

    4 x USB   2.0/1.1 port(s) (4 at mid-board)

    SPECIAL FEATURES

    ASUS 5X   Protection III :

    - ASUS   SafeSlot Core: Fortified PCIe Slot prevents damage

    - ASUS   LANGuard: Protects against LAN surges, lightning strikes and   static-electricity discharges!

    - ASUS   Overvoltage Protection: World-class circuit-protecting power design

    - ASUS   Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!

    - ASUS   DIGI+ VRM: Premium components provide better power efficiency

    ASUS   OptiMem

    - Optimem   (Improved DDR4 stability)

    ASUS EPU :

    - EPU

    ASUS   Exclusive Features :

    - AI Suite   3

    - Ai   Charger

    - PC   Cleaner

    ASUS Quiet   Thermal Solution :

    - Stylish   Fanless Design Heat-sink solution

    - ASUS Fan   Xpert 2+

    ASUS EZ   DIY :

    - ASUS   CrashFree BIOS 3

    - ASUS EZ   Flash 3

    - ASUS   UEFI BIOS EZ Mode

    ASUS   Q-Design :

    - ASUS   Q-DIMM

    M.2   Onboard(The latest transfer technologies with up to 32Gb/s data transfer   speeds)

    BACK I/O PORTS

    1 x PS/2 keyboard (purple)

    1 x PS/2 mouse (green)

    1 x DVI-D

    1 x D-Sub

    1 x HDMI

    1 x LAN (RJ45) port(s)

    1 x USB 3.1 Gen 1 USB Type-CTM   up to 5Gbps

    4 x USB 3.1 Gen 1 Type-A

    1 x 8-channel Audio I/O

    INTERNAL I/O PORTS

    1 x Aura RGB Strip Header

    1 x USB 3.1 Gen 1(up to 5Gbps)   connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)

    2 x USB 2.0 connector(s)   support(s) additional 4 USB 2.0 port(s)

    2 x M.2 Socket 3 for M Key,   type 2242/2260/2280 devices

    1 x TPM header

    1 x LPT header

    1 x COM port(s) connector(s)

    6 x SATA 6Gb/s connector(s)

    1 x CPU Fan connector(s)

    2 x Chassis Fan connector(s)

    1 x S/PDIF out header(s)

    1 x 24-pin EATX Power   connector(s)

    1 x 8-pin EATX 12V Power   connectors

    1 x Front panel audio   connector(s) (AAFP)

    1 x Clear CMOS jumper(s)

    1 x System panel connector

    1 x Chassis intrusion header

    1 x Speaker connector

    ACCESSORIES

    User's manual

    I/O Shield

    2 x SATA 6Gb/s cable(s)

    2 x M.2 screws

    1 x Supporting DVD

    BIOS

    128Mb Flash ROM, UEFI AMI BIOS,   PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree   BIOS 3, F3 My Favorites, Last Modified log, F6 Qfan Control, F12 PrintScreen,   and ASUS DRAM SPD (Serial Presence Detect) memory information

    MANAGEABILITY

    WOL by PME, PXE

    OPERATING   SYSTEM

    Windows® 10 64-bit

    FORM   FACTOR

    mATX Form Factor

    8.9 inch x 7.3 inch ( 22.6 cm x   18.5 cm )

    NOTE

    * When a device in SATA mode is   installed on the M.2_1 socket, SATA6G_1 port cannot be used.

    All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

    Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

    PCB color and bundled software versions are subject to change without notice.

    Brand and product names mentioned are trademarks of their respective companies.
