Asus Prime A320M-K AM4 mATX Motherboard

Asus Prime A320M-K AM4 mATX Motherboard
  • Asus Prime A320M-K AM4 mATX Motherboard
  • Asus Prime A320M-K AM4 mATX Motherboard
  • Asus Prime A320M-K AM4 mATX Motherboard
$85.0
RRP:$109.0    Save $24.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus Prime A320M-K AM4 mATX Motherboard
  • Model Number:
    PRIME-A320M-K
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    Asus Prime A320M-K AM4 mATX Motherboard


    • 5X Protection III: Multiple hardware safeguards for all-round protection

    • LED illumination: Lighting control for audio trace paths

    • Native M.2: Lightning-fast storage speeds

    • One-stop controls: Media-acclaimed UEFI BIOS with EZ Flash 3


    Asus Prime A320M-K AM4 mATX Motherboard

    Asus Prime A320M-K AM4 mATX Motherboard

    Asus Prime A320M-K AM4 mATX Motherboard

    Asus Prime A320M-K AM4 mATX Motherboard


    Specifications


    CPU

    AMD AM4 Socket Ryzen™ with   Radeon™ Vega Graphics/Ryzen™ 1st Generation/7th Generation A-series/Athlon X4   Processors
      Supports CPU up to 8 cores
      * Refer to www.asus.com for   CPU support list

    CHIPSET

    AMD A320

    MEMORY

    AMD Ryzen™ with Radeon™ Vega   Graphics/ Ryzen™ 1st Generation Processors
      2 x DIMM, Max. 32GB, DDR4 3200(O.C.)/2933(O.C.)/2666/2400/2133 MHz   Un-buffered Memory
      AMD   7th Generation A-Series/Athlon X4 Processors
      2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Un-buffered Memory
      Dual Channel Memory Architecture
      * Hyper DIMM support is subject to the physical characteristics of individual   CPUs.
      * Refer to www.asus.com for   the Memory QVL (Qualified Vendors Lists).

    GRAPHIC

    Integrated Graphics in the AMD   Ryzen™ with Radeon™ Vega Graphics/ 7th Generation A-Series APU
      Multi-VGA output support : HDMI/RGB ports
      - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @   60 Hz
      - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
      Maximum shared memory of 2048 MB (for iGPU exclusively)

    EXPANSION   SLOTS

    AMD Ryzen™ 1st Generation   Processors
      1 x PCIe 3.0/2.0 x16 (x16 or dual x8)
      AMD Ryzen™ with Radeon™ Vega Graphics /7th Generation   A-Series/Athlon X4 Processors
      1 x PCIe 3.0/2.0 x16 (x8 mode)
      AMD A320 chipset
      2 x PCIe 2.0 x1

    STORAGE

    AMD A320 chipset :
      4 x SATA 6Gb/s port(s), gray,
      Support Raid 0, 1, 10
      AMD Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation   Processors :
      1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support   (SATA & PCIE 3.0 x 4 mode)
      AMD 7th Generation A-series/Athlon™ Processors :
      1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support   (SATA & PCIE 3.0 x 2 mode)

    LAN

    Realtek® RTL8111H, 1 x Gigabit   LAN Controller(s)

    AUDIO

    Realtek® ALC887 8-Channel High   Definition Audio CODEC

    USB PORTS

    AMD Ryzen™ 2nd   Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/7th   Generation A-Series/Athlon X4 Processors :
      4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
      AMD A320 chipset :
      2 x USB 3.0 port(s) (2 at mid-board)
      AMD   A320 chipset :
      6 x USB 2.0 port(s) (2 at back panel, , 4 at mid-board)

    SPECIAL FEATURES

    ASUS 5X Protection III :
      - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
      - ASUS LANGuard: Protects against LAN surges, lightning strikes and   static-electricity discharges!
      - ASUS Overvoltage Protection: World-class circuit-protecting power design
      - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater   durability!
      - ASUS DIGI+ VRM: 6 Phase digital power design
      ASUS   Exclusive Features :
      - AI Suite 3
      - Ai Charger
      ASUS   Quiet Thermal Solution :
      - Stylish Fanless Design Heat-sink solution
      - ASUS Fan Xpert
      ASUS   EZ DIY :
      - ASUS CrashFree BIOS 3
      - ASUS EZ Flash 3
      - ASUS UEFI BIOS EZ Mode
      - Multi-language BIOS
      ASUS Q-Design :
      - ASUS Q-Slot
      - ASUS Q-DIMM

    OPERATING   SYSTEM SUPPORT

    Windows® 10 , 64bit

    BACK I/O PORTS

    1 x PS/2 keyboard (purple)
      1 x PS/2 mouse (green)
      1 x D-Sub
      1 x HDMI
      1 x LAN (RJ45) port(s)
      4 x USB 3.1 Gen 1 (blue) ,
      2 x USB 2.0
      3 x Audio jack(s)

    INTERNAL   I/O PORTS

    1 x USB 3.1 Gen 1(up to 5Gbps)   connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
      2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
      1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support   (SATA & PCIE 3.0 x 4 mode)
      1 x COM port(s) connector(s)
      4 x SATA 6Gb/s connector(s)
      1 x CPU Fan connector(s) (1 x 4 -pin)
      1 x Chassis Fan connector(s) (1 x 4 -pin)
      1 x S/PDIF out header(s)
      1 x 24-pin EATX Power connector(s)
      1 x 4-pin ATX 12V Power connector(s)
      1 x Front panel audio connector(s) (AAFP)
      1 x System panel(s)
      1 x Clear CMOS jumper(s)
      1 x Speaker connector

    ACCESSORIES

    User's manual
      I/O Shield
      2 x SATA 6Gb/s cable(s)
      1 x M.2 Screw Package
      1 x Supporting DVD

    BIOS

    128 Mb Flash ROM, UEFI AMI   BIOS, PnP,WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash   3, ASUS CrashFree BIOS 3, My Favorites, Last Modified log, F12 PrintScreen,   ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control

    OPERATING SYSTEM

    Windows®   10 64-bit

    FORM FACTOR

    mATX   Form Factor

    8.9   inch x 8.7 inch ( 22.6 cm x 22.1 cm )

    All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

    Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

    PCB color and bundled software versions are subject to change without notice.

    Brand and product names mentioned are trademarks of their respective companies.
