Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard

Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
$129.0
RRP:$139.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-2 Days excluding Weekends



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard
  • Model Number:
    PRIME-H310I-PLUS-R2.0
  • Brand:
  • Manufacturer Warranty:
    12 Months
  • Description

    Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard


    • Fan Xpert 2+: Flexible controls for ultimate cooling and quietness, plus GPU-temperature sensing for cooler gaming

    • 5X Protection III: Multiple hardware safeguards for all-round protection.

    • Native M.2 (M key) support delivers lightning-fast storage speeds, and native M.2 (E key) support enables faster wireless communication speeds.


    Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard

    Asus Prime H310I Plus R2 LGA 1151 ITX Motherboard


    • CPU
      Intel® Socket 1151 for 8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
      Supports Intel® 14 nm CPU
      Supports Intel® Turbo Boost Technology 2.0
      * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
      * Refer to www.asus.com for CPU support list
    • Chipset
      Intel® H310
    • Memory
      2 x DIMM, Max. 32GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
      Dual Channel Memory Architecture
      Supports Intel® Extreme Memory Profile (XMP)
      * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
      * The maximum memory frequency supported varies by processor
      ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
    • Graphic
      Integrated Graphics Processor- Intel® HD Graphics support
      Multi-VGA output support : HDMI/DVI-D/D-Sub ports
      - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 25600 x 1600 @ 60 Hz
      - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
      - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
      Maximum shared memory of 1024 MB (for iGPU exclusively)
      Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
    • Expansion Slots
      1 x PCIe 3.0/2.0 x16 (x16 mode)
    • Storage
      Intel® H310 Chipset :
      1 x M.2 Socket 3, , with M Key, type 2260/2280 storage devices support (both SATA & PCIE mode)*1
      4 x SATA 6Gb/s port(s), gray,
    • LAN
      Realtek® RTL8111H, 1 x Gigabit LAN
    • Audio
      Realtek® ALC887 8-Channel High Definition Audio CODEC
      - Supports : Jack-detection, Front Panel Jack-retasking
      Audio Feature :
      - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
      - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
      - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
      * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
    • USB Ports
      Intel® H310 Chipset :
      4 x USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at mid-board)
      Intel® H310 Chipset :
      4 x USB 2.0/1.1 port(s) (2 at back panel, , 2 at mid-board)
    • Special Features
      ASUS 5X Protection III :
      - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
      - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
      - ASUS Overvoltage Protection: World-class circuit-protecting power design
      - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
      - ASUS DIGI+ VRM: 5 Phase digital power design
      ASUS EPU :
      - EPU
      ASUS Exclusive Features :
      - AI Suite 3
      - Ai Charger
      - File Transfer
      ASUS Quiet Thermal Solution :
      - Stylish Fanless Design Heat-sink solution
      - ASUS Fan Xpert 2+
      ASUS EZ DIY :
      - ASUS CrashFree BIOS 3
      - ASUS EZ Flash 3
      - ASUS UEFI BIOS EZ Mode
      ASUS Q-Design :
      - ASUS Q-DIMM
      M.2 Onboard(The latest transfer technologies with up to 20 Gb/s data transfer speeds)
    • Back I/O Ports
      1 x PS/2 keyboard/mouse combo port(s)
      1 x DVI-D
      1 x D-Sub
      1 x HDMI
      1 x LAN (RJ45) port(s)
      2 x USB 3.1 Gen 1 (blue) Type-A up to 5Gbps
      2 x USB 2.0
      3 x Audio jack(s)
    • Internal I/O Ports
      1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
      1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
      1 x M.2 Socket 3 with M key, type 2260/2280 storage devices support (SATA & PCIE x4 mode)
      1 x COM port(s) connector(s)
      4 x SATA 6Gb/s connector(s)
      1 x CPU Fan connector(s) (1 x 4 -pin)
      2 x Chassis Fan connector(s) (2 x 4 -pin)
      1 x S/PDIF out header(s)
      1 x 24-pin EATX Power connector(s)
      1 x 4-pin ATX 12V Power connector(s)
      1 x Front panel audio connector(s) (AAFP)
      1 x Chassis Intrusion connector(s)
      1 x Clear CMOS jumper(s)
      1 x 14-1 pin TPM connector
      1 x System panel connector
      1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices support or PCIE/USB mode
      1 x Speaker connector
    • Accessories
      User's manual
      I/O Shield
      2 x SATA 6Gb/s cable(s)
      2 x M.2 Screw Package
      1 x Supporting DVD
    • BIOS
      128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
    • Manageability
      WOL by PME, PXE
    • Operating System
      Windows® 10 64-bit
    • Form Factor
      Mini ITX Form Factor
      6.7 inch x 6.7 inch ( 17 cm x 17 cm )
    • Note
      *1 When a device in SATA mode is installed on the M.2 socket, SATA_2 port cannot be used.
      Due to the Chipset limitation, when a M.2 device is installed in PCIe mode, the socket is set
      to PCIe 2.0.
    • CPU
      Intel® Socket 1151 for 8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
      Supports Intel® 14 nm CPU
      Supports Intel® Turbo Boost Technology 2.0
      * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
      * Refer to www.asus.com for CPU support list
    • Chipset
      Intel® H310
    • Memory
      2 x DIMM, Max. 32GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
      Dual Channel Memory Architecture
      Supports Intel® Extreme Memory Profile (XMP)
      * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
      * The maximum memory frequency supported varies by processor
      ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
    • Graphic
      Integrated Graphics Processor- Intel® HD Graphics support
      Multi-VGA output support : HDMI/DVI-D/D-Sub ports
      - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 25600 x 1600 @ 60 Hz
      - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
      - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
      Maximum shared memory of 1024 MB (for iGPU exclusively)
      Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
    • Expansion Slots
      1 x PCIe 3.0/2.0 x16 (x16 mode)
    • Storage
      Intel® H310 Chipset :
      1 x M.2 Socket 3, , with M Key, type 2260/2280 storage devices support (both SATA & PCIE mode)*1
      4 x SATA 6Gb/s port(s), gray,
    • LAN
      Realtek® RTL8111H, 1 x Gigabit LAN
    • Audio
      Realtek® ALC887 8-Channel High Definition Audio CODEC
      - Supports : Jack-detection, Front Panel Jack-retasking
      Audio Feature :
      - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
      - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
      - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
      * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
    • USB Ports
      Intel® H310 Chipset :
      4 x USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at mid-board)
      Intel® H310 Chipset :
      4 x USB 2.0/1.1 port(s) (2 at back panel, , 2 at mid-board)
    • Special Features
      ASUS 5X Protection III :
      - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
      - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
      - ASUS Overvoltage Protection: World-class circuit-protecting power design
      - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
      - ASUS DIGI+ VRM: 5 Phase digital power design
      ASUS EPU :
      - EPU
      ASUS Exclusive Features :
      - AI Suite 3
      - Ai Charger
      - File Transfer
      ASUS Quiet Thermal Solution :
      - Stylish Fanless Design Heat-sink solution
      - ASUS Fan Xpert 2+
      ASUS EZ DIY :
      - ASUS CrashFree BIOS 3
      - ASUS EZ Flash 3
      - ASUS UEFI BIOS EZ Mode
      ASUS Q-Design :
      - ASUS Q-DIMM
      M.2 Onboard(The latest transfer technologies with up to 20 Gb/s data transfer speeds)
    • Back I/O Ports
      1 x PS/2 keyboard/mouse combo port(s)
      1 x DVI-D
      1 x D-Sub
      1 x HDMI
      1 x LAN (RJ45) port(s)
      2 x USB 3.1 Gen 1 (blue) Type-A up to 5Gbps
      2 x USB 2.0
      3 x Audio jack(s)
    • Internal I/O Ports
      1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
      1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
      1 x M.2 Socket 3 with M key, type 2260/2280 storage devices support (SATA & PCIE x4 mode)
      1 x COM port(s) connector(s)
      4 x SATA 6Gb/s connector(s)
      1 x CPU Fan connector(s) (1 x 4 -pin)
      2 x Chassis Fan connector(s) (2 x 4 -pin)
      1 x S/PDIF out header(s)
      1 x 24-pin EATX Power connector(s)
      1 x 4-pin ATX 12V Power connector(s)
      1 x Front panel audio connector(s) (AAFP)
      1 x Chassis Intrusion connector(s)
      1 x Clear CMOS jumper(s)
      1 x 14-1 pin TPM connector
      1 x System panel connector
      1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices support or PCIE/USB mode
      1 x Speaker connector
    • Accessories
      User's manual
      I/O Shield
      2 x SATA 6Gb/s cable(s)
      2 x M.2 Screw Package
      1 x Supporting DVD
    • BIOS
      128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
    • Manageability
      WOL by PME, PXE
    • Operating System
      Windows® 10 64-bit
    • Form Factor
      Mini ITX Form Factor
      6.7 inch x 6.7 inch ( 17 cm x 17 cm )
    • Note
      *1 When a device in SATA mode is installed on the M.2 socket, SATA_2 port cannot be used.
      Due to the Chipset limitation, when a M.2 device is installed in PCIe mode, the socket is set
      to PCIe 2.0.
