Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard

Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard
  • Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard
  • Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard
  • Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard
  • Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard
$249.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-2 Days excluding Weekends



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus Prime Q370M-C/CSM LGA 1151 mATX Motherboard
  • Model Number:
    PRIME Q370M-C/CSM
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    Micro-Q370 business motherboard with enhanced security, reliability and manageability

    ASUS-exclusive self-recovering BIOS technology for automatic system BIOS recovery from a verified backup

    Dedicated LPC header and debug card with LCD display for faster troubleshooting

    Event log for capturing and managing detailed system information

    Innovative moisture-resistant coating to protect the motherboard from harsh environments

    Commercial BIOS kit to make customization faster and more efficient


    SPECIFICATIONS:

    CPU



    Intel® for 8th Generation Core™ Core™ i7/Core™   i5/Core™ i3/Pentium®/Celeron® Processors

    Supports Intel® 14 nm CPU

    Supports Intel® Turbo Boost Technology 2.0

    * The Intel® Turbo Boost Technology 2.0 support   depends on the CPU types.

    * Refer to www.asus.com for CPU support list

    Chipset



    Intel® Q370

    Memory



    4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz   Non-ECC, Un-buffered Memory

    Supports Intel® Extreme Memory Profile (XMP)

    * Hyper DIMM support is subject to the physical   characteristics of individual CPUs.

    * Refer to www.asus.com for the Memory QVL   (Qualified Vendors Lists).

    * The maximum memory frequency supported varies   by processor.

    ** DDR4 2666MHz and higher memory modules will   run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.

    Graphic

    Integrated Graphics Processor- Intel® HD Graphics   support

    Multi-VGA output support : HDMI/RGB/DisplayPort   ports

    - Supports HDMI with max. resolution 4096 x 2160   @ 24 Hz / 2560 x 1600 @ 60 Hz

    - Supports RGB with max. resolution 1920 x 1200 @   60 Hz

    - Supports DisplayPort with max. resolution 4096   x 2304 @ 60 Hz

    Maximum shared memory of 1024 MB (for iGPU   exclusively)

    Supports Intel® InTru™ 3D, Quick Sync Video,   Clear Video HD Technology, Insider™

    Supports up to 3 displays simultaneously

    Expansion   slots

    1 x PCIe 3.0/2.0 x16

    2 x PCIe 3.0/2.0 x1

    1 x PCI

    Storage

    Intel® Q370 Chipset :

    1 x M.2 Socket 3, with M key, type 2242/2260/2280   storage devices support (both SATA & PCIE mode)

    1 x M.2 Socket 3, with M Key, type 2242/2260/2280   storage devices support (x4 PCIE mode)

    6 x SATA 6Gb/s port(s)

    Support Raid 0, 1, 5, 10

    Intel® Optane™ Memory Ready

    LAN

    Intel® I219LM, 1 x Gigabit LAN Controller(s)

    Audio



    Realtek® ALC887 8-Channel High Definition Audio   CODEC *1

    - Supports : Jack-detection, Front Panel   Jack-retasking

    USB   Ports

    Intel® Q370 Chipset :

    4 x USB 3.1 Gen 2 port(s) (4 at back panel, ,   Type-A, 0 at mid-board)

    Intel® Q370 Chipset :

    4 x USB 3.1 Gen 1 port(s) (2 at mid-board)

    Intel® Q370 Chipset :

    4 x USB 2.0 port(s) (2 at back panel, , Type-A, 2   at mid-board)

    Special   Features

    TPM IC Onboard

    Bespoke Motherboard Design & Business Focused   Features :

    - ASUS Self Recovering BIOS: Automatically   recover BIOS update once crash happen

    - ASUS Event Log: Record activities of system and   provides information in BIOS

    - ASUS Commercial BIOS kit: Speed up BIOS update   solutionby partial BIOS design

    - Anti-Moisture: Against moisture and corrosion —   prolonging the life of your motherboard

    - 24/7 Reliability: Tested under temperature up   to 45°C and humidity up to 80% to ensure handle diverse environment

    Easy Assembly Design:

    - Fixed-position&Color-coded Connectors:   Enable easy identification and cable-matching, speeding up the production   line

    - Box Headers: USB headers are box style,   enabling fast connector installation and preventing pin damage

    Digi+VRM

    OS   support

    Windows® 10

    Back I/O   Ports



    1 x PS/2 keyboard (purple)

    1 x PS/2 mouse (green)

    1 x D-Sub

    2 x DisplayPort

    1 x HDMI

    1 x LAN (RJ45) port(s)

    4 x USB 3.1 Gen 2 Type-A

    2 x USB 2.0

    3 x Audio jack(s)

    Internal   I/O Ports

    1 x MONO out header *2

    2 x USB 3.1 Gen 1(up to   5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)

    2 x USB 2.0 connector(s)   support(s) additional 4 USB 2.0 port(s)

    1 x M.2 Socket 3 with M   key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4   mode)

    1 x M.2 Socket 3 with M Key,   type 2242/2260/2280 storage devices support (PCIE mode only)

    1 x LPT header

    2 x COM port(s)   connector(s)

    6 x SATA 6Gb/s   connector(s)

    1 x CPU Fan connector(s)   (1 x 4 -pin)

    2 x Chassis Fan   connector(s) (2 x 4 -pin)

    1 x 24-pin EATX Power   connector(s)

    1 x 8-pin ATX 12V Power   connector(s)

    1 x Front panel audio   connector(s) (AAFP)

    1 x Internal speaker   connector(s)

    1 x System panel(s)

    1 x Chassis Intrusion   connector(s)

    1 x M.2 Socket 1 with E   key, type 2230 for Wi-Fi/BT devices support or PCIE/USB mode

    1 x LPC Debug header

    Accessories

    User's manual

    I/O Shield

    2 x SATA 6Gb/s cable(s)

    3 x M.2 Screw Package

    1 x Supporting DVD

    BIOS

    192Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1,   ACPI 6.1, Multi-language BIOS, ASUS smart recovering BIOS, ASUS Event log,   ASUS Commercial Kit

    Manageability

    WOL, PXE

    Support   Disc

    Watch dog timer, Drivers

    Form Factor

    uATX Form Factor

    9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

    Note



    *1: Use a chassis with HD audio module in the   front panel to support an 8-channel audio output.

    *2: Use with amplified speaker is suggested.
