Asus Prime Z370-P II LGA 1151 ATX Motherboard

Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Asus Prime Z370-P II LGA 1151 ATX Motherboard
$199.0
RRP:$229.0    Save $30.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus Prime Z370-P II LGA 1151 ATX Motherboard
  • Model Number:
    PRIME Z370-P II
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description



    Asus Prime Z370-P II LGA 1151 ATX Motherboard

    • Ready for Socket 1151 for 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors

    • Enhanced power solution: Premium components provide better power efficiency

    • ASUS OptiMem: Careful routing of traces and vias to preserve signal integrity for improved memory overclocking

    • 5X Protection III: Multiple hardware safeguards for all-round protection

    • Fan Xpert 4 Core: Flexible controls for ultimate cooling and quietness

    • Ultrafast connectivity: Dual native M.2 and NVMe PCIe RAID support for lightning-fast storage speeds

    • Intel Optane memory ready: The latest high-speed storage technology.

    Asus Prime Z370-P II LGA 1151 ATX Motherboard

    • CPU
      Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
      Supports Intel® 14 nm CPU
      Supports Intel® Turbo Boost Technology 2.0
      * Refer to www.asus.com for CPU support list
    • Chipset
      Intel® Z370
    • Memory
      4 x DIMM, Max. 64GB, DDR4 4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
      Dual Channel Memory Architecture
      Supports Intel® Extreme Memory Profile (XMP)
      * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
      * The maximum memory frequency supported varies by processor.
    • Graphic
      Integrated Graphics Processor- Intel® HD Graphics support
      Multi-VGA output support : HDMI/DVI-D ports
      - Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz
      - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
      Maximum shared memory of 1024 MB (for iGPU exclusively)
    • Multi-GPU Support
      Supports AMD CrossFireX™ Technology
    • Expansion Slots
      1 x PCIe 3.0/2.0 x16 (x16, x8/x4+x4) *
      1 x PCIe 3.0/2.0 x16 (max at x4 mode)
      4 x PCIe 3.0/2.0 x1
    • Storage
      Intel® Z370 Chipset :
      2 x M.2 Socket 3*1, , with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
      4 x SATA 6Gb/s port(s), gray
      Support Raid 0, 1, 5, 10
      Intel® Optane™ Memory Ready
      Intel® CPU with Intel® Rapid Storage Technology support (RAID 0 & RAID 1)
      PCIEX16_1 slot supports up to 3 Intel® PCIe NVME SSDs via a Hyper M.2 X16 series Card
    • LAN
      Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
      ASUS LAN Guard
    • Audio
      Realtek® ALC887 8-Channel High Definition Audio CODEC
      - Supports : Jack-detection, Front Panel Jack-retasking
      Audio Feature :
      - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
      - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
      - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
      - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
    • USB Ports
      Intel® Z370 Chipset :
      8 x USB 3.1 Gen 1 port(s) (4 at back panel, +blue)
      Intel® Z370 Chipset :
      6 x USB 2.0 port(s) (2 at back panel, )
    • Special Features
      ASUS 5X Protection III :
      - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
      - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
      - ASUS Overvoltage Protection: World-class circuit-protecting power design
      - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
      - ASUS DIGI+ VRM: Premium components provide better power efficiency
      ASUS OptiMem:
      - Optimem (Improved DDR4 stability)
      ASUS EPU :
      - EPU
      ASUS Exclusive Features :
      - AI Suite 3
      - Ai Charger
      ASUS Quiet Thermal Solution :
      - Stylish Fanless Design Heat-sink solution & MOS Heatsink
      - ASUS Fan Xpert 4 Core
      ASUS EZ DIY :
      - ASUS O.C. Tuner
      - ASUS CrashFree BIOS 3
      - ASUS EZ Flash 3
      - ASUS UEFI BIOS EZ Mode
      ASUS Q-Design :
      - ASUS Q-Slot
      - ASUS Q-DIMM
      M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)
    • Back I/O Ports
      1 x PS/2 keyboard/mouse combo port(s)
      1 x DVI-D
      1 x HDMI
      1 x LAN (RJ45) port(s)
      4 x USB 3.1 Gen 1 (blue) Type-A
      2 x USB 2.0
      3 x Audio jack(s)
    • Internal I/O Ports
      2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) (19-pin)
      2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
      2 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
      1 x COM port(s) connector(s)
      4 x SATA 6Gb/s connector(s)
      1 x CPU Fan connector(s) (1 x 4 -pin)
      2 x Chassis Fan connector(s) (2 x 4 -pin)
      1 x S/PDIF out header(s)
      1 x 24-pin EATX Power connector(s)
      1 x 8-pin ATX 12V Power connector(s)
      1 x Front panel audio connector(s) (AAFP)
      1 x Clear CMOS jumper(s)
      1 x System panel connector
      1 x AIO PUMP Header
    • Accessories
      User's manual
      I/O Shield
      2 x SATA 6Gb/s cable(s)
      1 x M.2 Screw Package
      1 x SCD
    • BIOS
      128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.1, WfM2.0, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
    • Manageability
      WfM 2.0, DMI 3.1, WOL by PME, PXE
    • Support Disc
      Drivers
      ASUS Utilities
      ASUS EZ Update
      Anti-virus software (OEM version)
    • Operating System
      Windows® 10 64-bit
    • Form Factor
      ATX Form Factor
      12.0 inch x 9.1 inch ( 30.5 cm x 23.1 cm )
    • Note
      * PCIEX16_1 slot supports up to 3 Intel® PCIe NVME SSDs via a Hyper M.2 X16 series Card.**
      ** Hyper M.2 X16 series card sold separately. Install a Hyper M.2 X16 series card and enable this card under BIOS settings.
      *1 When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot be used.
