Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard

Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard
  • Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard
  • Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard
  • Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard
$539.0
RRP:$699.0    Save $160.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-3 Days excluding Weekends

  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Click & Collect.

Specifications

  • Product Name:
    Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard
  • Model Number:
    PROART Z490-CREATOR 10G
  • Brand:
  • Manufacturer Warranty:
    3 Year
  • Description

     Asus ProArt Z490 Creator 10G LGA 1200 ATX Motherboard

    Intel® LGA 1200 socket: Ready for 10th Gen Intel® Core™ processors

    Ultrafast connectivity: Two Thunderbolt™ 3 Type-C ports, two M.2, HYPER 10G LAN card and onboard 2.5G Intel® LAN provide power and speed

    Intelligent optimization: AI Overclocking, AI Cooling and CreationFirst automatically optimize CPU frequencies, fan speeds and network traffic for enhanced system performance and work efficiency

    Powerful performance: 12+2 DrMOS power stages, multi-GPU support and improved memory frequency and stability empower creativity

    Trusted stability: Tested for 24/7 dependability, validated for solid compatibility and equipped with SafeSlot for durability

    ProArt Creator Hub: Centralized software for one-stop monitoring and management of ASUS ProArt series products enables efficient content creation workflows



    SPECIFICATIONS

    Chipset



    Intel® Z490

    Memory

    4 x DIMM, Max. 128GB, DDR4   4800(O.C.)/4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)

    /4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)

    /3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/

    2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory   *

    Dual Channel Memory Architecture

    Supports Intel® Extreme Memory Profile (XMP)

    OptiMem II

    * 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133   natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors   Lists).

    Thunderbolt



    2 x Intel® Thunderbolt™ 3 ports(TypeC™) support DisplayPort and   Thunderbolt™ video outputs

    Supports DisplayPort 1.4/ with max. resolution 7680/ x 3840/@ 60 Hz*

    * VGA resolution support depends on VGA cards' resolution.

    Data transfer rate up to 40 Gbps

    Daisy-chain up to 12 Thunderbolt devices

    Up to 5V/3A, 15W charging support

    Graphic

    Integrated Graphics Processor

    1 x DisplayPort 1.4 **

    1 x HDMI 1.4b

    *Graphics specifications may vary between CPU types.

    **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz.   Please refer to www.intel.com for any update.

    Multi-GPU Support



    Supports AMD 3-Way CrossFireX™ Technology

    Exapnsion Slots

    Intel® 10th Gen Processors

    2 x PCIe 3.0 x16 (x16 or dual x8) *1

    Intel® Z490 Chipset

    1 x PCIe 3.0 x16 (x4 mode) *2

    2 x PCIe 3.0 x1

    Storage

    Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

    Intel® Z490 Chipset :

    1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage   devices support (SATA & PCIE 3.0 x 4 mode)*3

    1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage   devices support (PCIE 3.0 x 4 mode)*4

    6 x SATA 6Gb/s port(s)

    Support Raid 0, 1, 5, 10

    Intel® Rapid Storage Technology supports

    Intel® Optane™ Memory Ready

    LAN

    Intel® I225-V 2.5Gb Ethernet

    Audio

    Realtek® ALC S1220A 8-Channel High Definition Audio CODEC

    - Supports : Jack-detection, Multi-streaming, Front Panel   Jack-retasking, Front Panel MIC Jack-retasking, up to 24-Bit/192kHz playback

    - High quality 120 dB SNR stereo playback output and SNR recording   input

    Audio Feature :

    - Optical S/PDIF out port(s) at back panel

    - Audio Shielding

    - Dedicated audio PCB layers

    - Premium Japanese audio capacitors

    - Audio Cover

    - Unique de-pop circuit

    * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported   for 8-Channel audio.

    USB Ports

    Intel® Thunderbolt™ 3 Controller :

    2 x USB 3.2 Gen 2 port(s) (USB Type-C®)

    Rear USB Port ( Total 6 )

    4 x USB 3.2 Gen 2 port(s)(4 x Type-A)

    2 x USB 3.2 Gen 1 port(s)(2 x Type-A)

    Front USB Port ( Total 7 )

    1 x USB 3.1 Gen 1 port(s)(1 x USB Type-C®)

    2 x USB 3.2 Gen 1 port(s)(2 x Type-A)

    4 x USB 2.0 port(s)

    OS Support

    Windows® 10 64-bit

    Software Features

    ASUS Exclusive Software

    Armoury Crate

    - Aura Creator

    - Aura Sync

    - OLED Display

    AI Suite 3

    5-Way Optimization with AI Overclocking

    - TPU

    - EPU

    - Digi+ VRM

    - EZ update

    - Fan Xpert 4

    - Turbo app

    ProArt Creator Hub

    AI Charger

    Optimization tool specially for content creators

    WinRAR

    UEFI BIOS

    AI Optimization Guide

    ASUS EZ DIY

    - ASUS CrashFree BIOS 3

    - ASUS EZ Flash 3

    - ASUS UEFI BIOS EZ Mode

    FlexKey

    - ASUS UEFI BIOS EZ Mode

    ASUS Special features

    ASUS 5X PROTECTION III

    - ASUS DIGI+ VRM (- Digital power design with Dr. MOS)

    - ASUS Enhanced DRAM Overcurrent Protection

    - ASUS ESD Guards

    - ASUS LANGuard

    - ASUS Overvoltage Protection

    - ASUS SafeSlot Core+

    - ASUS Stainless-Steel Back I/O

    ASUS Q-Design

    - ASUS Q-DIMM

    - ASUS Q-LED

    - ASUS Q-Shield

    - ASUS Q-Slot

    ASUS Thermal Solution

    - Aluminum heatsink design

    ASUS EZ DIY

    - Procool

    - SafeSlot

    AURA Sync

    - Standard RGB headers

    - Addressable Gen 2 RGB header(s)

    - Addressable Gen 2 RGB header

    Back I/O Ports

    2 x Thunderbolt 3 ports TypeC™

    2 x DisplayPort IN ports for Thunderbolt™ 3

    1 x HDMI

    1 x LAN (2.5G) port(s)

    4 x USB 3.2 Gen 2 Type-A

    2 x USB 3.2 Gen 1 Type-A

    1 x Optical S/PDIF out

    5 x Audio jack(s)

    Internal I/O Ports

    1 x CPU Fan connector(s)

    1 x CPU OPT Fan connector(s)

    3 x Chassis Fan connector(s)

    1 x AIO_PUMP connector

    2 x Aura RGB Strip Headers

    1 x Addressable Gen 2 header(s)

    1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 1   USB 3.2 Gen 1 port(s) (20-pin, Type-C)

    1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2   USB 3.2 Gen 1 port(s)

    2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)

    1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage   devices support (SATA & PCIE 3.0 x 4 mode)

    1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage   devices support (PCIE 3.0 x 4 mode)

    6 x SATA 6Gb/s connector(s)

    1 x Thunderbolt header(s)

    1 x 24-pin EATX Power connector(s)

    1 x 8-pin EATX 12V Power connectors

    1 x Front panel audio connector(s) (AAFP)

    1 x System panel(s) (Chassis intrusion header is inbuilt) x With   flexkey function

    1 x Thermal sensor connector(s)

    1 x CPU OV

    1 x Clear CMOS jumper(s)

    1 x COM port header

    Accessories



    I/O Shield

    4 x SATA 6Gb/s cable(s)

    1 x M.2 Screw Package

    1 x Supporting DVD

    1 x DisplayPort cable

    User manual

    1 x CPU Fan Holder

    1 x 2-in-1 Rubber pad

    1 x HYPER 10G LAN CARD

    BIOS

    128 Mb Flash ROM, UEFI AMI BIOS

    Manageability

    WOL by PME, PXE

    OS

    Windows® 10 64-bit

    Form Factor

    ATX Form Factor

    12 inch x 9.2 inch ( 30.5 cm x 23.4 cm )
