Asus ROG 15.6in FHD 120Hz i7 8750H GTX 1060 512GB SSD Gaming Laptop (FX505GM-AL317T)
Intel® Core™ i7 8750H Processor
Windows 10 Home - ASUS recommends Windows 10 Pro.
Intel® HM370 Express Chipset
2 x SO-DIMM socket for expansion, up to 32 GB SDRAM, Dual-channel
15.6" (16:9) LED-backlit FHD (1920x1080) 60Hz Anti-Glare IPS-level Panel with 45% NTSC
NVIDIA® GeForce® GTX 1060 , with 6GB GDDR5 VRAM
512GB PCIe® Gen3 SSD
HD 720p CMOS module
10/100/1000 Base T
1 x COMBO audio jack
1 x Type-A USB2.0
2 x Type-A USB 3.0 (USB 3.1 Gen 1)
1 x RJ45 LAN jack for LAN insert
1 x HDMI, HDMI support 2.0
Built-in 2 W Stereo Speakers with Array Microphone
DTS® Headphone: X®
Supports Windows 10 Cortana with Voice
4 -Cell 2526
mAh 48 Wh Polymer Battery
Plug type :ø6.0 (mm)
19 V DC, 6.32 A, 120 W
19.5 V DC, 9.23 A, 180 W
100 -240 V AC, 50/60 Hz universal
3/ 2 pin compact power supply system
360.4 x 262.0 x 25.8 ~26.8 mm (WxDxH)
fTPM (Firmware-based Trusted Platform Module)
UL, CE Marking Compliance, FCC Compliance, BSMI, CCC, CB, JATE
Products certified by the Federal Communications Commission and Industry Canada will be distributed in the United States and Canada. Please visit the ASUS USA and ASUS Canada websites for information about locally available products.
All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.
PCB color and bundled software versions are subject to change without notice.
Brand and product names mentioned are trademarks of their respective companies.
Unless otherwise stated, all performance claims are based on theoretical performance. Actual figures may vary in real-world situations.
