Asus ROG MAXIMUS XI EXTREME LGA 1151 E-ATX Motherboard
Intel Z390 EATX gaming motherboard with 802.11ac W-Fi, ROG DIMM.2 dual M.2 expansion card, Aura Sync RGB LED, DDR4 4400MHz, four M.2, SATA 6Gbps, HDMI and USB 3.1 Gen 2
LGA1151 socket: Ready for 9th/8th Generation Intel® Core™ desktop processors. Synchronized RGB lighting technology: Works with a vast portfolio of Aura Sync-capable PC gear and includes support for addressable light strips and Phillip Hue Perfected cooling: Dedicated water-cooling zones, M.2 heatsink and flexible fan controls. ROG DIMM.2: Vertically-installed dual-M.2 expansion card with heatsink for maximum cooling and performance. 5-Way Optimization: Automated system-wide tuning, providing AI overclocking and cooling profiles tailor-made for your rig. Gaming connectivity: Intel Gigabit Ethernet , onboard 5Gbps Ethernet, four M.2, USB 3.1 Gen 2, CNVi 2x2 802.11ac Intel integrated Wi-Fi with MU-MIMO support for lightning-fast data transfers Gaming audio: High-fidelity sonics that draw you deeper into the action, with SupremeFX and Sonic Studio III. Gaming durability: ASUS SafeSlot, patented pre-mounted I/O shield and premium components for maximum durability

Specifications
CPU | Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list | Chipset | Intel® Z390 | Memory | 4 x DIMM, Max. 64GB, DDR4 4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). | Graphic | Integrated Graphics Processor- Intel® UHD Graphics support VGA output support : HDMI port - Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz | Multi-GPU Support | Supports NVIDIA® 2-Way SLI™ Technology Supports AMD 3-Way CrossFireX™ Technology | Expansion Slots | Socket 1151 for 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors 2 x PCIe 3.0/2.0 x16 (x16 or dual x8) Intel® Z390 Chipset 1 x PCIe 3.0/2.0 x16 (max at x4 mode) *1 1 x PCIe 3.0/2.0 x1 | Storage | Socket 1151 for 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors : 1 x ROG DIMM.2 Module support(CPU_DIMM.2), with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*2 Intel® Z390 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*3 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 6 x SATA 3Gb/s port(s) Support Raid 0, 1, 5, 10 Intel® Optane™ Memory Ready | LAN | Aquantia AQC111C 5G LAN Intel® I219V, Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY) Anti-surge LANGuard ROG GameFirst Technology | Wireless Data Network | Intel® Wireless-AC 9560 Wi-Fi 802.11 a/b/g/n/ac Supports dual band frequency 2.4/5 GHz Supports MU-MIMO Supports channel bandwidth: HT20/HT40/HT80/HT160 | Bluetooth | Bluetooth® 5.0 | Audio | ROG SupremeFX 8-Channel High Definition Audio CODEC S1220 - Impedance sense for front and rear headphone outputs - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - SupremeFX Shielding Technology - ESS® ES9023P - Supports up to 32-Bit/192kHz playback *4 Audio Feature : - Gold-plated jacks - Optical S/PDIF out port(s) at back panel - Sonic Radar III - Sonic Studio III + Sonic Studio Link | USB Ports | Intel® Z390 Chipset : 1 x USB 3.1 Gen 2 front panel connector port(s) Intel® Z390 Chipset : 4 x USB 3.1 Gen 2 port(s) (4 at back panel, ) Intel® Z390 Chipset : 8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board) Intel® Z390 Chipset : 4 x USB 2.0 port(s) (4 at mid-board) ASMedia® USB 3.1 Gen 1 controller : 2 x USB 3.1 Gen 1 port(s) (2 at back panel, ) | ROG Exclusive Features | ReTry Button Safe Boot Button Start Button LN2 Mode Extreme Engine Digi+ : - MicroFine Alloy Chokes - OptiMOS Power Stage - 10K Black Metallic Capacitors Mem TweakIt Extreme Tweaker ROG Exclusive Software - Mem Tweakit - RAMCache III - RAMDisk - CPU-Z - GameFirst V - Sonic Studio III + Sonic Studio Link - Sonic Radar III | Special Features | ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 : - 5-Way Optimization tuning key perfectly consolidates TPU Insight, EPU Guidance, DIGI+ VRM, Fan Expert 4, and Turbo App LiveDash OLED SafeDIMM slot AURA : - Aura Lighting Control - Aura RGB Strip Headers - Aura Lighting Effects Synchronization with compatible ASUS ROG devices - Aura Addressable Strip Header(s) ASUS Exclusive Features : - USB BIOS FlashbackTM - MemOK! II - AI Suite 3 - Ai Charger - Armoury Crate - Pre-mounted I/O Shield - ASUS NODE: hardware control interface - BUPDATER - BIOS FlashbackTM Button - Clear CMOS Button - Reset Button ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 ASUS Q-Design : - ASUS Q-Code - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector Overclocking Protection : - ASUS C.P.R.(CPU Parameter Recall) OptiMem II | Back I/O Ports | 1 x HDMI 1 x LAN (RJ45) port(s) 4 x USB 3.1 Gen 2 (red) (1 x Type-C+3 x Type-A) 6 x USB 3.1 Gen 1 1 x Optical S/PDIF out 1 x Clear CMOS button(s) 1 x USB BIOS FlashbackTM Button(s) 1 x ASUS Wi-Fi Module 5 x LED-illuminated audio jacks 1 x AQC-111C 5G LAN port | Internal I/O Ports | 1 x W_PUMP+ 1 1 x W_PUMP+ 2 1 x WB_SENSOR 2 x Aura Addressable Strip Header(s) 2 x Aura RGB Strip Headers 2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 2 x Chassis Fan connector(s) (2 x 4 -pin) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 2 x 8-pin EATX 12V Power connectors 1 x 4-pin EZ_PLUG Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x 5-pin EXT_FAN(Extension Fan) connector 1 x MemOK! II switch(es) 1 x Slow Mode switch(es) 9 x ProbeIt Measurement Points 1 x Reset button(s) 1 x BIOS Switch button(s) 1 x Node Connector(s) 1 x LN2 Mode jumper(s) 1 x Safe Boot button 1 x ReTry button 1 x System panel connector 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header 1 x Thermal sensor connector 1 x Start button 1 x USB 3.1 Gen 2 front panel connector 1 x DIMM.2 Slot supports 2 M.2 drives (2242-22110) 1 x RSVD Switch 8 x Radiator Fan Headers | Accessories | User's manual 1 x ROG logo plate sticker 4 x SATA 6Gb/s cable(s) 3 x M.2 Screw Package 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x Fan Extension Card (3 x 4-pin fan out) 1 x Fan Extension card screw pack 1 x Fan Extension card cable 1 x SLI HB BRIDGE(2-WAY-M) 1 x ROG big sticker 1 x Q-Connector 1 x Extension Cable for RGB strips (80 cm) 1 x Extension cable for Addressable LED 3 x Thermistor cable(s) 1 x USB drive with utilities and drivers 1 x ROG coaster(s) 2 x ROG weave SATA 6G cable 1 x ROG DIMM.2 with heatsink 1 x M.2 Pad for ROG DIMM.2 | Operating System Support | Windows® 10 64-bit | BIOS | 2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, SM BIOS 3.1, ACPI 6.1 | Manageability | WOL, PXE | Note | *1 When SATA56 is enabled, PCIE x 16_3 will run at x2 mode. *2 The DIMM.2 Slots (M.2_1/2) are disabled by default. Please adjust BIOS settings to enable DIMM.2 Slots. *3 When M.2_1 socket 3 is operating in SATA mode, SATA port 2 will be disabled. *4 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio. |
