Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard

Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard
  • Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard
  • Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard
$599.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard
  • Model Number:
    ROG MAXIMUS XI GENE
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard


    Intel Z390 mATX gaming motherboard with 802.11ac Wi-Fi, double-capacity DIMM support, ROG DIMM.2 dual M.2 expansion card, Aura Sync RGB LED, DDR4 4700MHz, four M.2, SATA 6Gbps, DisplayPort, HDMI and USB 3.1 Gen 2


    • LGA1151 socket: Ready for 9th/8th Generation Intel® Core™ desktop processors.

    • Double-capacity DIMM: Optimized memory trace layout for dual 32GB DIMM support.

    • Perfected cooling: Dedicated water-cooling zones, M.2 heatsink and flexible fan controls.

    • ROG DIMM.2: Vertically-installed dual-M.2 expansion card with heatsink for maximum cooling and performance.

    • Overclocker's toolkit: Hardware-level controls to aid with subzero overclocking.

    • 5-Way Optimization: Automated system-wide tuning, providing AI overclocking and cooling profiles tailor-made for your rig.

    • Gaming connectivity: Intel Gigabit Ethernet, four M.2, USB 3.1 Gen 2, and CNVi 2x2 802.11ac Intel integrated Wi-Fi with MU-MIMO support for lightning-fast data transfers.

    • Gaming audio: High-fidelity sonics that draw you deeper into the action, with SupremeFX and Sonic Studio III.

    • Synchronized RGB lighting technology: Works with a vast portfolio of Aura Sync-capable PC gear and includes support for addressable light strips and Phillip Hue.

    • Gaming durability: ASUS SafeSlot, patented pre-mounted I/O shield and premium components for maximum durability


    Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard

    Asus ROG MAXIMUS XI GENE LGA1151 mATX Motherboard


    Specifications


    CPU

    Build in Intel® 9th / 8th Gen Intel® Core™, Pentium® Gold   and Celeron® Processors
        Supports Intel® Turbo Boost Technology 2.0
        * Refer to
    www.asus.com for CPU     support list

    CHIPSET

    Build     in Intel® Z390

    MEMORY



    Socket   1151 for 9th / 8th Gen Intel® Core™,     Pentium® Gold and Celeron® processors

    2xDIMM,Max.64GB,DDR4         4800(O.C.)/4700(O.C)/4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2133     MHz Memory *

    Dual   Channel Memory Architecture

    Supports   Intel® Extreme Memory Profile   (XMP)

        * Double Capcity DRAM support depends on   the DRAM models



    GRAPHIC

    Integrated   Graphics   Processor- Intel® UHD Graphics support

    -   Supports HDMI 1.4b with max. resolution   4096 x 2160 @ 30 Hz

    EXPANSION SLOTS

    Socket   1151 for 9th /   8th Gen Intel® Core™, Pentium® Gold and Celeron® processors

    1 x   PCIe 3.0 x16

    Intel®   Z390 Chipset

        1 x   PCIe 3.0 x4

    STORAGE

    Socket   1151 for 9th /   8th Gen Intel® Core™, Pentium® Gold and Celeron® processors

    2 x   ROG DIMM.2 Module support(CPU_DIMM.2),   with M key, type 2242/2260/2280/22110     storage devices support (PCIE 3.0 x 4 mode)

    Intel®   Z390 Chipset :

    2 x   M.2 Socket 3, with M   Key, type 2242/2260/2280 storage devices support (x4   PCIE mode)

    Intel®   Z390 Chipset :

    4 x   SATA 6Gb/s port(s),

    Support   Raid 0, 1, 5, 10

    Intel®   Optane™ Memory Ready

    LAN

    Intel®   I219V, 1 x   Gigabit LAN Controller(s)

    Anti-surge   LANGuard

    ROG   GameFirst Technology

    WIRELESS DATA NETWORK

    Intel®   Wireless-AC 9560

    Wi-Fi     802.11 a/b/g/n/ac

    Supports     dual band frequency 2.4/5 GHz

    Supports     MU-MIMO

    Supports     channel bandwidth: HT20/HT40/HT80/HT160. Up to 1.73Gbps transfer speed



    BLUETOOTH

    Bluetooth®     5.0

    AUDIO

    ROG   SupremeFX 8-Channel High Definition Audio CODEC   S1220A

    -     Impedance sense for front and rear headphone outputs

    -     Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

    -     High quality 120 dB SNR stereo playback output 113 dB SNR recording   input

    Audio     Feature :

    -     SupremeFX Shielding™ Technology

    -     Gold-plated jacks

    -     Optical S/PDIF out port(s) at back panel

    -     Sonic Radar III

    -     Sonic Studio III + Sonic Studio Link



    USB PORTS

    Intel®   Z390 Chipset :

    1   x   USB 3.1 Gen 2 front panel connector port(s)

    Intel®     Z390 Chipset :

    4   x   USB 3.1 Gen 2 port(s) (3 x Type-A+1 x Type-C)

    Intel®     Z390 Chipset :

    8   x   USB 3.1 Gen 1 port(s) (2 at mid-board)

    Intel®     Z390 Chipset :

    6   x   USB 2.0 port(s)





    ROG EXCLUSIVE FEATURES

    ROG   CPU-Z

    ROG     CloneDrive

    Pre-mounted     I/O Shield

    Slow     Mode

    CMOS     button

    Overwolf

    ReTry     Button

    Safe     Boot Button

    Start     Button

    Reset     Button

    LN2     Mode

    ROG     Aura

    -     Aura Lighting Control

    -     Aura RGB Strip Headers

    Extreme     Engine Digi+ :

    -     MicroFine Alloy Chokes

    -   10K   Black Metallic Capacitors

    Mem     TweakIt

    Double     Power :

    -     Dual 8 -pin CPU

    USB     BIOS FlashbackTM

    ROG     Exclusive Software

    -     RAMCache III

    -     GameFirst V

    -     Sonic Studio III + Sonic Studio Link

    -     Sonic Radar III



    SPECIAL FEATURES

    AI   Overclocking

    ASUS     5X Protection III :

    -     ASUS SafeSlot Core: Fortified PCIe Slot prevents damage

    -     ASUS LANGuard: Protects against LAN surges, lightning strikes and     static-electricity discharges!

    Gamer's     Guardian:

    -     SafeSlot

    ASUS     Optimem II

    -     Optimem (Improved DDR4 stability)

    -     Improved DDR4 Stability

    ASUS     Exclusive Features :

    -     MemOK! II

    -     Pre-mounted I/O Shield

    -     ASUS NODE : hardware control interface

    -     BIOS FlashbackTM Button

    -     Clear CMOS Button

    -     Reset Button

    ASUS     Quiet Thermal Solution :

    -     ASUS Fan Xpert 4

    ASUS     Q-Design :

    -     ASUS Q-Code

    -     ASUS Q-LED (CPU, VGA, Boot Device LED)

    -     ASUS Q-Slot

    -     ASUS Q-DIMM

    -     ASUS Q-Connector

    AURA:     RGB Lighting Control

    Armoury     Crate



    BACK I/O PORTS

    1 x   PS/2 keyboard/mouse combo port(s)

    1   x   HDMI

    1   x   LAN (RJ45) port(s)

    3   x   USB 3.1 Gen 2 (red)Type-A,

    1   x   USB 3.1 Gen 2 (red)Type-C

    6   x   USB 3.1 Gen 1 (blue)

    2   x   USB 2.0

    1   x   Clear CMOS button(s)

    1   x   Wi-Fi antenna port(s)



    INTERNAL I/O PORTS

    Windows®     10 64-bit

    ACCESSORIES

    1 x     128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,   ACPI 6.0,   Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11   EZ Tuning Wizard,   F6 Qfan Control, F3 My Favorites, Last Modified log,   F12 PrintScreen, F3   Shortcut functions and ASUS DRAM SPD (Serial   Presence Detect) memory   information.

    BIOS

    WfM2.0,     DMI3.0, WOL by PME, PXE

    MANAGEABILITY

    mATX   Form Factor

    9.6     inch x 8.9 inch ( 24.4 cm x 22.6 cm )



    OPERATING SYSTEM

    Overwolf

    1-year     Anti-Virus software

    Daemon     Tools Software

    WinRAR
