Asus ROG Maximus XI Code LGA1151 ATX Motherboard

Asus ROG Maximus XI Code LGA1151 ATX Motherboard
  • Asus ROG Maximus XI Code LGA1151 ATX Motherboard
  • Asus ROG Maximus XI Code LGA1151 ATX Motherboard
  • Asus ROG Maximus XI Code LGA1151 ATX Motherboard
  • Asus ROG Maximus XI Code LGA1151 ATX Motherboard
$599.0
RRP:$635.0    Save $36.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus ROG Maximus XI Code LGA1151 ATX Motherboard
  • Model Number:
    ROG-MAXIMUS-XI-CODE
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    Asus ROG Maximus XI Code Motherboard


    Intel Z390 ATX Gaming motherboard with M.2 heatsink, Aura Sync RGB LED, DDR4 4400MHz, 802.11ac Wi-Fi , dual M.2, SATA 6Gb/s, and USB 3.1 Gen 2


    • LGA1151 socket for 9th/8th -gen Intel® Core™ desktop processors.

    • ROG Eco-System: ASUS-exclusive Aura Sync RGB lighting, including headers for both standard and addressable RGB strips.

    • Perfected cooling with dedicated water header zones, M.2 heatsink and various fan control.

    • Gaming connectivity: Intel Gigabit Ethernet, LANGuard, 2x2 802.11ac Wi-Fi, Dual M.2, USB 3.1 Gen 2 Type-A and Type-C™ connectors.

    • 5-way Optimization: Automated system-wide tuning, providing AI Overclocking and cooling profiles trailor-made for your rig

    • Gaming Audio: SupremeFX and Sonic Studio III – High fidelity audio that draws you deeper into the action.

    • Gaming durability: ROG Armor, pre-mounted I/O shield and premium components throughout.


    Asus ROG Maximus XI Code LGA1151 ATX Motherboard

    Specifications


    CPU

    Intel® Socket 1151 9th / 8th Gen   Intel® Core™, Pentium® Gold and Celeron® Processors

    Supports Intel® 14 nm CPU

    Supports Intel® Turbo Boost   Technology 2.0

    * The Intel® Turbo Boost Technology   2.0 support depends on the CPU types.

    Chipset

    Build in Intel®   Z390

    Memory

    4 x DIMM, Max. 64GB, DDR4   4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133   MHz Non-ECC, Un-buffered Memory

    Dual Channel Memory Architecture

    Supports Intel® Extreme Memory   Profile (XMP)

    * Hyper DIMM support is subject to   the physical characteristics of individual CPUs.

    Graphic

    Integrated Graphics Processor- Intel®   UHD Graphics support

    VGA output support : HDMI port

    - Supports HDMI 1.4b with max.   resolution 4096 x 2160 @ 30 Hz

    Multi-GPU Support

    Supports NVIDIA® 2-Way SLI™   Technology

    Supports AMD 3-Way CrossFireX™ Technology

    Expansion Slots

    Socket 1151 for 9th / 8th Gen Intel®   Core™, Pentium® Gold and Celeron® processors

    2 x PCIe 3.0 x16 (x16, x8/x8, or   x8/x4+x4)

    Intel® Z390 Chipset

    1 x PCIe 3.0 x16 (max at x4 mode) *

    1 x PCIe 3.0 x16

    Storage

    Socket 1151 for 9th / 8th Gen Intel®   Core™, Pentium® Gold and Celeron® processors :

    1 x M.2 Socket 3, with M key, type   2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*2

    1 x M.2 Socket 3, with M key, type   2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)

    6 x SATA 6Gb/s port(s)

    Intel® Optane™ Memory Ready

    LAN

    Intel® I219V

    Anti-surge LANGuard

    ROG GameFirst V Technology

    Wireless Data Network

    Intel® Wireless-AC 9560

    Wi-Fi 802.11 b/g/n/ac

    Supports dual band frequency 2.4/5   GHz

    Supports channel band">

    Bluetooth

    Bluetooth® 5.0

    Audio

    ROG SupremeFX 8-Channel High   Definition Audio CODEC S1220

    - Impedance sense for front and rear   headphone outputs

    - Supports : Jack-detection,   Multi-streaming, Front Panel Jack-retasking

    - High quality 120 dB SNR stereo   playback output and 113 dB SNR recording input

    - SupremeFX Shielding Technology

    - ESS® ES9023P

    - Supports up to 32-Bit/192kHz   playback *3

    Audio Feature :

    - Optical S/PDIF out port(s) at back   panel

    USB Ports

    Intel® Z390 Chipset :

    1 x USB 3.1 Gen 2 front panel   connector port(s)

    Intel® Z390 Chipset :

    4 x USB 3.1 Gen 2 port(s)

    Intel® Z390 Chipset :

    8 x USB 3.1 Gen 1 port(s)

    Intel® Z390 Chipset :

    4 x USB 2.0 port(s)

    ASMedia® USB 3.1 Gen 1 controller :

    2 x USB 3.1 Gen 1 port(s)

    ROG Exclusive Features

    ROG RGB Armor

    ReTry Button

    Start Button

    Extreme Engine Digi+ :

    - MicroFine Alloy Chokes

    - OptiMOS Power Stage

    - 10K Black Metallic Capacitors

    Extreme Tweaker

    ROG Patented Pre-mounted I/O Shield

    ROG Exclusive Software

    - Mem Tweakit

    - RAMCache III

    - RAMDisk

    - CPU-Z

    - GameFirst V

    - Sonic Studio III + Sonic Studio   Link

    - Sonic Radar III

    Special Features

    5-Way Optimization by Dual Intelligent   Processors 5

    - 5-way Optimization tuning key   perfectly consolidates TPU Insight, EPU Guidance,and Turbo app

    AURA :

    - Aura Lighting Control

    - Aura RGB Strip Headers

    - Aura Lighting Effects   Synchronization with compatible ASUS ROG devices

    - Aura Addressable Strip Header(s)

    ASUS Exclusive Features :

    - USB BIOS FlashbackTM

    - MemOK! II

    - AI Suite 3

    - Ai Charger

    - ASUS CrashFree BIOS 3

    - Armoury Crate

    - Pre-mounted I/O Shield

    - ASUS NODE: hardware control   interface

    - OptiMem II

    - ASUS EZ Flash 3

    - ASUS C.P.R.(CPU Parameter Recall)

    - BUPDATER

    - BIOS FlashbackTM Button

    - Clear CMOS Button

    - Reset Button

    ASUS Q-Design :

    - ASUS Q-Code

    - ASUS Q-LED (CPU, VGA, Boot Device   LED)

    - ASUS Q-DIMM

    - ASUS Q-Connector

    Back I/O Ports

    1 x HDMI

    4 x USB 3.1 Gen 2

    6 x USB 3.1 Gen 1

    1 x Optical S/PDIF out

    1 x Clear CMOS button(s)

    1 x USB BIOS FlashbackTM Button(s)

    1 x ASUS Wi-Fi Module

    5 x Gold-plated audio jacks

    Anti-surge LAN (RJ45) port

    Internal I/O Ports

    2 x Aura Addressable Strip Header(s)

    2 x Aura RGB Strip Headers

    2 x USB 2.0 connector(s) support(s)   additional 2 USB 2.0 port(s)

    1 x M.2 Socket 3 with M key, type   2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)

    1 x M.2 Socket 3 with M key, type   2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)

    6 x SATA 6Gb/s connector(s)

    1 x CPU Fan connector(s)

    1 x CPU OPT Fan connector(s)

    1 x Chassis Fan connector(s)

    1 x Optional Fan connector(s)

    1 x AIO_PUMP connector

    1 x H_AMP fan connector

    1 x W_PUMP+ connector

    1 x 4-pin EATX 12 V Power connector

    1 x 24-pin EATX Power connector(s)

    1 x 8-pin EATX 12V Power connectors

    1 x Front panel audio connector(s)   (AAFP)

    1 x 5-pin EXT_FAN(Extension Fan)   connector

    1 x MemOK! II switch(es)

    1 x Thermal sensor connector(s)

    1 x Node Connector(s)

    1 x 5-pin EXT_FAN(Extension Fan)   connector

    1 x ReTry button

    1 x System panel connector

    1 x T_Sensor Connector

    1 x W_IN header

    1 x W_OUT header

    1 x W_FLOW header

    1 x USB 3.1 Gen 2 front panel   connector

    2 x USB 3.1 Gen 1 connector(s)   support(s) additional 2 USB 3.1 Gen 1 port(s)

    1 x USB 2.0 connector(s) support(s)   additional 2 USB 2.0 port(s)

    1 x Start button

    1 x Reset button

    1 x Q-Code

    Accessories

    User's manual

    1 x ROG logo plate sticker

    1 x 2-Way SLI bridge(s)

    3 x SATA 6Gb/s cable(s)

    1 x M.2 Screw Package

    1 x Supporting DVD

    1 x ASUS 2T2R dual band Wi-Fi moving   antennas (Wi-Fi 802.11a/b/g/n/ac compliant)

    1 x Q-Connector

    1 x Extension Cable for RGB strips   (80 cm)

    1 x Extension cable for Addressable   LED

    1 x Thermistor cable(s)

    1 x ROG coaster(s)

    1 x USB 3.1 Gen 1 Header to USB 2.0   adapter cable

    1 x ROG Thank you card

    BIOS

    1 x 128 Mb Flash ROM, UEFI AMI BIOS,   PnP, DMI3.0, SM BIOS 3.1, ACPI 6.1

    Manageability

    WOL , PXE

    Operating System

    Windows® 10 64-bit

    Form Factor

    ATX Form Factor

    12 inch x 9.6 inch ( 30.5 cm x 24.4   cm )

    Note

    * The PCIe x 16_3 slot shares   bandwidth with SATA6G_56 ports. PCIe x 16_3 slot is set at x2 mode by   default.

    *2 When M.2_1 Socket 3 is operating   in SATA mode, SATA port 2 will be disabled.

    When an 22110 M.2 SSD is installed in   M.2_1, M.2_2 will be limited to an 2242 M.2 SSD.

    *3 Due to limitations in HDA   bandwidth, 32-Bit/192 kHz is not supported for 8-Channel audio.

    • All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

    • Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

    • PCB color and bundled software versions are subject to change without notice.

    • Brand and product names mentioned are trademarks of their respective companies.

    • Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

    • *Precise specifications and features vary by model . Please refer to the specification page

    • The product (electrical , electronic equipment, Mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.

    • The use of trademark symbol (TM, ®) appears on this website means that the word text, trademarks, logos or slogans, is being used as trademark under common laws protection and/or registered as Trademark in U.S. and/or other country/region.
