Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard

Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard
  • Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard
  • Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard
  • Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard
  • Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard
$489.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-3 Days excluding Weekends

  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!

Specifications

  • Product Name:
    Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard
  • Model Number:
    ROG STRIX Z490-A GAMING
  • Brand:
  • Manufacturer Warranty:
    3 Year
  • Description

    Asus ROG Strix Z490-A Gaming LGA 1200 ATX Motherboard

    Intel® LGA 1200 socket: Ready for 10th Gen Intel® Core™ processors.

    Optimal Power Solution: 12+2 power stages with ProCool II power connector, high-quality alloy chokes and durable capacitors to support multi-core processors.

    High-performance Networking: M.2 socket with E-key and Intel® 2.5 Gb Ethernet with ASUS LANGuard.

    Best Gaming Connectivity: Supports HDMI 1.4 and DisplayPort 1.4, and featuring USB 3.2 Gen 2 Type-A and Type-C® connectors.

    Intelligent Control: ASUS-exclusive tools including AI Overclocking, AI Cooling and AI Networking, helping you configure your gaming build easily.

    DIY Friendly Design: Pre-mounted I/O shield, BIOS Flashback, Q-LEDS and FlexKey.

    Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting, including RGB headers and Gen 2 addressable headers.

    Industry-leading Gaming Audio: High fidelity audio with SupremeFX S1220A, DTS® Sound Unbound and Sonic Studio III to draw you deeper into the action.


    SPECIFICATIONS:

    Chipset



    Intel® Z490

    Memory

    4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/

    4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/

    3466(O.C.)/3333(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/

    2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

    Dual Channel Memory Architecture

    OptiMem II

    * 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133   natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors   Lists).

    Graphic

    Integrated Graphics Processor

    1 x DisplayPort 1.4 *

    1 x HDMI 1.4b

    *Graphics specifications may vary between CPU types.

    **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz.   Please refer to www.intel.com for any update.

    Multi-GPU Support

    Supports AMD 2-Way CrossFireX Technology

    Exapnsion Slots

    Intel® 10th Gen Processors

    3 x PCIe 3.0 x16 (x16 or x8+x4+x4)

    Intel® Z490 Chipset

    1 x PCIe 3.0 x4 (max at x2 mode)

    1 x PCIe 3.0 x1

    Storage

    Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports

    Intel® Z490 Chipset :

    1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage   devices support (SATA & PCIE 3.0 x 4 mode)

    1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage   devices support (PCIE 3.0 x 4 mode)

    6 x SATA 6Gb/s port(s)

    Support Raid 0, 1, 5, 10

    Intel® Optane™ Memory Ready

    LAN



    Intel® I225-V 2.5Gb Ethernet

    ASUS LANGuard

    WiFi

    M.2 slot only (Key E) (Support CNVI & PCIe interface)*

    *Wi-Fi module is sold separately.

    Audio

    ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A

    - Dual OP Amplifiers

    - Impedance sense for front and rear headphone outputs

    - Supports : Jack-detection, Multi-streaming, Front Panel   Jack-retasking

    - High quality 120 dB SNR stereo playback output and 113 dB SNR   recording input

    - Supports up to 32-Bit/192kHz playback *

    Audio Feature :

    - SupremeFX Shielding™ Technology

    - Gold-plated jacks

    - Optical S/PDIF in port(s) at back panel

    - Premium Japanese audio capacitors

    - Audio Cover

    * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported   for 8-Channel audio.

    USB Ports

    Rear USB Port ( Total 8 )

    2 x USB 3.2 Gen 2 port(s)(1 x Type-A + USB Type-CTM)

    4 x USB 3.2 Gen 1 port(s)(4 x Type-A)

    2 x USB 2.0 port(s)

    Front USB Port ( Total 7 )

    1 x USB3.1 Gen 1 front panel connector port(s)

    2 x USB 3.2 Gen 1 port(s)

    4 x USB 2.0 port(s)

    Special Features



    Aura Feature

    - Standard RGB headers

    - Addressable Gen 2 RGB header

    ASUS Q-Design

    -ASUS Q-DIMM

    -ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device   [yellow green])

    -ASUS Q-Slot

    ASUS Thermal Solution

    - Aluminum M.2 heatsink

    ASUS EZ DIY

    - BIOS FlashBackTM button

    - 1 x BIOS FlashbackTM LED

    - Procool II

    - Pre-mounted I/O Shield

    - SafeSlot

    Software Features



    ROG Exclusive Software

    - RAMCache III

    - ROG CPU-Z

    - GameFirst VI

    - Sonic Studio III + Sonic Studio Virtual Mixer

    - Sonic Radar III

    - DTS® Sound Unbound

    - Overwolf

    - Anti-virus software

    ASUS Exclusive Software

    Armoury Crate

    - Aura Creator

    - Aura Sync

    AI Suite 3

    -5-way Optimization with AI Overclocking.

    TPU

    EPU

    Digi+ VRM

    Fan Xpert 4

    Turbo app

    -EZ update

    WinRAR

    UEFI BIOS

    AI Overclocking Guide

    ASUS EZ DIY

    - ASUS CrashFree BIOS 3

    - ASUS EZ Flash 3

    - ASUS UEFI BIOS EZ Mode

    FlexKey

    Back I/O Ports

    1 x Intel® I225-V 2.5Gb Ethernet

    1 x DisplayPort

    1 x HDMI

    2 x USB 3.2 Gen 2 (1 x Type-A + USB Type-CTM)

    4 x USB 3.2 Gen 1 Type-A

    2 x USB 2.0 (one port can be switched to USB BIOS FlashBack™)

    1 x Optical S/PDIF out

    1 x USB BIOS FlashBack™ Button(s)

    5 x Gold-plated audio jacks

    Internal I/O Ports



    1 x M.2_FAN connector

    1 x CPU Fan connector(s)

    1 x CPU OPT Fan connector(s)

    2 x Chassis Fan connector(s)

    1 x AIO_PUMP connector

    1 x Addressable RGB header

    1 x AAFP connector

    2 x Aura RGB Strip Headers

    1 x USB 3.2 Gen 1 front panel TypeC™ connector

    1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2   USB 3.2 Gen 1 port(s)

    2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)

    1 x M.2 Socket 1 with M Key, type 2242/2260/2280/22110 storage   devices support (SATA mode & PCIE mode)

    1 x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage   devices support (PCIE 3.0 x 4 mode)

    1 x M.2 with E key for Wi-Fi module

    6 x SATA 6Gb/s connector(s)

    1 x Thunderbolt header(s)

    1 x 24-pin EATX Power connector(s)

    1 x 8-pin ATX 12V Power connector(s)

    1 x 4-pin ATX 12V Power connector(s)

    1 x System panel(s) (Chassis intrusion header is inbuilt)

    1 x Thermal sensor connector(s)

    1 x Clear CMOS jumper(s)

    1 x CPU_OV jumper

    1 x VRM_HS_FAN Header

    Accessories

    User's manual

    1 x ASUS Fan Holder

    4 x SATA 6Gb/s cable(s)

    1 x Supporting DVD

    1 x ROG Strix stickers

    1 x Cable ties pack(s)

    1 x Extension Cable for RGB strips (80 cm)

    1 x Extension cable for Addressable LED

    1 x Thermistor cable(s)

    1 x ROG Thank you card

    1 x 2-in-1 Rubber pad

    1 M.2 SSD screw package(s)

    1 M.2 Key E screw package(s)

    1 ROG key chain

    BIOS

    192 (128+64) Mb Flash ROM, UEFI AMI BIOS

    Manageability

    WOL by PME, PXE

    OS

    Windows® 10 64-bit

    Form Factor

    ATX Form Factor

    12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
