Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard

Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
$165.0
RRP:$175.0   Save $10.0
or 4x fortnightly payments of $330 with ZipPay
Learn more

- +

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1 business day



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Products name:
    Asus TUF B360M-PLUS Gaming LGA 1151 mATX Motherboard
  • Model #:
    TUF B360M-PLUS GAMING
  • Brand:
    Asus
  • Warranty:
    36 Months
  • Description


    ASUS TUF B360M-Plus Gaming LGA1151 (300 Series) DDR4 HDMI VGA M.2 mATX Motherboard
  • Designed exclusively for 8th generation Intel® Core processors to maximize connectivity and speed with Dual M.2, Gigabit LAN, USB 3.1 Gen2, and Intel® Optane Memory compatibility
  • Military-grade TUF components like TUF LANGuard, TUF Chokes, TUF Capacitors, and TUF MOSFETs maximize system durability
  • Fan Xpert 2+ provides advanced fan and liquid cooling controls for dynamic system cooling and management
  • Aura Sync RGB lighting with additional 4-pin RGB header features a nearly endless spectrum of colors with the ability to synchronize effects across an ever-expanding ecosystem of Aura Sync enabled products
  • 3-Year Warranty for guaranteed reliability built on military-grade engineering


  • Official Product Link Open Link
    CPU Intel® Socket 1151 for 8th Generation Core Core i7/Core i5/Core i3/Pentium®/Celeron® Processors
    Supports Intel® 14 nm CPU
    Supports Intel® Turbo Boost Technology 2.0
    * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
    * Refer to www.asus.com for CPU support list
    Chipset
    Intel® B360
    Memory Intel® B360 Chipset
    4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
    Dual Channel Memory Architecture
    Supports Intel® Extreme Memory Profile (XMP)
    * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
    * The maximum memory frequency supported varies by processor
    ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
    Graphic Integrated Graphics Processor- Intel® HD Graphics support
    Multi-VGA output support : HDMI/DVI-D ports
    - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
    - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
    Maximum shared memory of 1024 MB (for iGPU exclusively)
    Supports Intel® InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider
    Expansion Slots 1 x PCIe 3.0 x16 (x16 mode)
    2 x PCIe 3.0/2.0 x1
    Storage Intel® B360 Chipset :
    1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
    1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
    6 x SATA 6Gb/s port(s), gray
    LAN Intel® I219V, 1 x Gigabit LAN
    TUF LANGuard
    Wireless Data Network
    -
    Bluetooth
    -
    Audio Realtek® ALC887 8-Channel High Definition Audio CODEC
    - Supports : Jack-detection, Front Panel Jack-retasking
    Audio Feature :
    - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
    - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
    - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
    * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
    USB Ports Intel® B360 Chipset :
    2 x USB 3.1 Gen 2 up to 10Gbps port(s) (2 at back panel, teal blue, Type-A)
    Intel® B360 Chipset :
    3 x USB 3.1 Gen 1 up to 5Gbps port(s) (1 at back panel, , USB Type-CTM, 2 at mid-board)
    Intel® B360 Chipset :
    6 x USB 2.0/1.1 port(s)
    ROG Exclusive Features -
    Special Features ASUS TUF PROTECTION
    - ASUS SafeSlot: Protect your graphics card Investment
    - ASUS ESD Guard: Enhanced ESD protection
    - ASUS Overvoltage Protection: World-class circuit-protecting power design
    - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
    - ASUS DIGI+ VRM: 5 Phase digital power design
    ASUS OptiMem:
    - Optimem (Improved DDR4 stability)
    ASUS EPU :
    - EPU
    ASUS Exclusive Features :
    - AI Suite 3
    - Ai Charger
    - PC Cleaner
    - File Transfer
    ASUS Quiet Thermal Solution :
    - Stylish Fanless Design Heat-sink solution & MOS Heatsink
    - ASUS Fan Xpert 2+
    ASUS EZ DIY :
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    ASUS Q-Design :
    - ASUS Q-Slot
    - ASUS Q-DIMM
    M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)
    Back I/O Ports 1 x PS/2 keyboard (purple)
    1 x PS/2 mouse (green)
    1 x DVI-D
    1 x HDMI
    1 x LAN (RJ45) port(s)
    2 x USB 3.1 Gen 2 (teal blue)Type-A, up to 10Gbps
    1 x USB 3.1 Gen 1 () USB Type-CTM, up to 5Gbps
    2 x USB 2.0
    1 x 8-channel Audio I/O
    Internal I/O Ports 1 x Aura RGB Strip Header
    1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin, moss green)
    2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
    2 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices
    1 x COM port(s) connector(s)
    6 x SATA 6Gb/s connector(s)
    1 x CPU Fan connector(s)
    2 x Chassis Fan connector(s)
    1 x S/PDIF out header(s)
    1 x 24-pin EATX Power connector(s)
    1 x 8-pin EATX 12V Power connectors
    1 x Front panel audio connector(s) (AAFP)
    1 x Clear CMOS jumper(s)
    1 x System panel connector
    Accessories User's manual
    I/O Shield
    2 x SATA 6Gb/s cable(s)
    2 x M.2 screws
    1 x Supporting DVD
    1 x TUF GAMING Sticker
    1 x TUF Certification card(s)
    BIOS 128Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F3 My Favorites, Last Modified log, F4 AURA ON/OFF, F6 Qfan Control, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial
    Presence Detect) memory information
    Manageability -
    Support Disc -
    Operating System Windows® 10 64-bit
    Form Factor mATX Form Factor
    9.6 inch x 9.1 inch ( 24.4 cm x 23.1 cm )
    Note WOL by PME, PXE
