Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard

Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
  • Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
  • Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
  • Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
  • Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
  • Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
$1,049.0
RRP:$1,199.0    Save $150.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard
  • Model Number:
    ROG ZENITH EXTREME ALPHA
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard


    • AMD TR4 socket: Ready for 1st and 2nd Gen AMD Ryzen™ Threadripper™ processor series to maximize connectivity and speed with up to three M.2 drives and USB 3.1 Gen 2.

    • Comprehensive thermal design: Active heatsink with integrated VRM fan, PCIe-zone M.2 aluminum heatsink and dual backplates.

    • High-performance networking: Onboard Aquantia ® 10Gbps LAN, 802.11ac Wi-Fi with MU-MIMO support, and Intel gigabit LAN with ASUS LANGuard and GameFirst V technologies.

    • 5-Way Optimization: Automated system-wide tuning, providing overclocking and cooling profiles that are tailor made for your rig.

    • SafeSlot technology: Firmly-anchored PCIe slots fortified with metal to support heavyweight graphics cards.

    • Unmatched personalization: LiveDash OLED and ASUS-exclusive Aura Sync RGB lighting, including two RGB headers and addressable headers.

    • Industry-leading ROG audio: SupremeFX S1220 and ESS ® SABRE9018Q2C for enthusiast-grade audio performance driven by Japanese capacitors.


    Asus X399 ROG Zenith Extreme Alpha TR4 eATX Motherboard


    Specifications


    CPUAMD SocketTR4 for 1st and 2nd Gen AMD Ryzen™ Threadripper™ Processors

    Supports CPU up to 32 cores

    * Refer to www.asus.com for CPU support list
    Chipset
    AMD X399
    MemoryAMD Ryzen™ Threadripper™ Processors

    8 x DIMM, Max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory *1

    Quad Channel Memory Architecture
    Multi-GPU SupportAMD Ryzen™ 2nd Generation/Ryzen™ 1st Generation Processors

    Supports NVIDIA® 3-Way SLI™ Technology

    Supports AMD 3-Way CrossFireX™ Technology
    Expansion SlotsAMD Ryzen™ Threadripper™ Processors

    4 x PCIe 3.0 x16 (x16, x16/x16, x16/x8/x16, x16/x8/x16/x8)

    AMD X399 chipset

    1 x PCIe 3.0 x4
    StorageAMD Ryzen™ Threadripper™ Processors :

    2 x M.2 Socket 3, with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD)

    1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*2

    AMD X399 chipset :

    8 x SATA 6Gb/s port(s),

    Support Raid 0, 1, 10
    LANAquantia AQC-107 10G

    Intel® I211-AT

    Anti-surge LANGuard

    ROG GameFirst Technology
    Wireless Data NetworkWi-Fi 802.11 a/b/g/n/ac

    Supports dual band frequency 2.4/5 GHz

    Supports MU-MIMO

    Supports channel bandwidth: HT20/HT40/HT80/HT160. Up to 1.73Gbps transfer speed
    BluetoothBluetooth® 5.0
    AudioROG SupremeFX 8-Channel High Definition Audio CODEC S1220

    - Impedance sense for front and rear headphone outputs

    - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

    - High quality 120 dB SNR stereo playback output 113 dB SNR recording input

    - ESS®SABRE9018Q2C DAC/AMP

    - Supports up to 32-Bit/192kHz playback *4

    Audio Feature :

    - Optical S/PDIF out port(s) at back panel

    - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.

    - Sonic Radar III

    - Sonic Studio III + Sonic Studio Link
    USB PortsAMD Ryzen™ Threadripper™ Processors :

    8 x USB 3.1 Gen 1 port(s) (8 at back panel, blue)

    AMD X399 chipset :

    1 x USB 3.1 Gen 2 front panel connector port(s)

    AMD X399 chipset :

    4 x USB 3.1 Gen 1 port(s) (4 at mid-board)

    AMD X399 chipset :

    4 x USB 2.0 port(s)

    ASMedia® USB 3.1 Gen 2 controller :

    2 x USB 3.1 Gen 2 port(s) (2 at back panel, red, Type-A)

    ASMedia® USB 3.1 Gen 2 controller :

    2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A + USB Type-CTM)
    ROG Exclusive FeaturesReTry Button

    Start Button

    LN2 Mode

    Extreme Engine Digi+ :

    - IR3555 PoweIRstage®

    - MicroFine Alloy Chokes

    - 10K Black Metallic Capacitors

    ProbeIt

    ROG Exclusive Software

    - Mem Tweakit

    - RAMCache III

    - CPU-Z

    - GameFirst V

    - Sonic Studio III + Sonic Studio Link

    - Sonic Radar III

    ROG DIMM.2 module with heatsink

    ROG Aluminum heatsink cover
    Special Features5-Way Optimization by Dual Intelligent Processors 5

    - 5-way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ Power control, Fan Xpert 4, and Turbo app

    LiveDash OLED

    AURA :

    - Aura Lighting Control

    - Aura RGB Strip Headers

    - Aura Lighting Effects Synchronization with compatible ASUS ROG devices

    - Aura Addressable Strip Header(s)

    ASUS Exclusive Features :

    - USB BIOS FlashbackTM

    - AI Suite 3

    - Ai Charger

    - ASUS CrashFree BIOS 3

    - Armoury Crate

    - Pre-mounted I/O Shield

    - ASUS NODE: hardware control interface

    - OptiMem II

    - ASUS EZ Flash 3

    - ASUS C.P.R.(CPU Parameter Recall)

    - BUPDATER

    - Clear CMOS Button

    - Reset Button

    ASUS Q-Design :

    - ASUS Q-Code

    - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)

    - ASUS Q-DIMM

    - ASUS Q-Connector
    Back I/O Ports1 x LAN (RJ45) port(s)

    1 x USB 3.1 Gen 2 (black)TypeC™

    3 x USB 3.1 Gen 2 (red)Type-A

    8 x USB 3.1 Gen 1 (blue)

    1 x Optical S/PDIF out

    1 x Clear CMOS button(s)

    1 x USB BIOS FlashbackTM Button(s)

    1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v5.0

    5 x LED-illuminated audio jacks

    1 x Aquantia AQC-107 10G LAN port
    Internal I/O Ports1 x WB_SENSOR

    2 x Aura Addressable Strip Header(s)

    2 x Aura RGB Strip Headers

    2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)

    2 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

    1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)

    8 x SATA 6Gb/s connector(s)

    1 x CPU Fan connector(s)

    1 x CPU OPT Fan connector(s)

    2 x Chassis Fan connector(s)

    1 x H_AMP fan connector

    1 x W_PUMP+ connector

    2 x 8-pin EATX 8 V Power connector

    1 x 24-pin EATX Power connector(s)

    1 x Front panel audio connector(s) (AAFP)

    1 x Slow Mode switch(es)

    7 x ProbeIt Measurement Points

    2 x Thermal sensor connector(s)

    1 x EZ Plug connector(s) (4-pin Molex power connector)

    1 x Reset button(s)

    1 x BIOS Switch button(s)

    1 x Node Connector(s)

    1 x LN2 Mode jumper(s)

    1 x Safe Boot button

    1 x ReTry button

    1 x 14-1 pin TPM connector

    1 x Slow Mode jumper(s)

    1 x System panel connector

    1 x W_IN header

    1 x W_OUT header

    1 x W_FLOW header

    1 x Start button

    1 x USB 3.1 Gen 2 front panel connector

    1 x DIMM.2 Slot supports 2 M.2 drives (2242-22110)

    1 x RSVD Switch

    1 x 4-Pin HS fan connector
    AccessoriesUser's manual

    6 x SATA 6Gb/s cable(s)

    1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)

    1 x Fan Extension Card II (6 x 4-pin Chassis Fan connectors, 3 x RGB headers, 3 x 2-pin Thermal sensor header)

    1 x Fan Extension Card II power cable

    1 x Fan Extension Card II NODE connector cable

    1 x Fan Extension Card II screw package

    1 x SLI HB BRIDGE(2-WAY-M)

    1 x ROG big sticker

    1 x Q-Connector

    1 x M.2 screw kit (long screw and mount)

    2 x M.2 screw kit (short screw and mount)

    1 x DIMM.2 extension card with 2 x M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)

    1 x ROG Logo Sticker(s)

    1 x Extension Cable for RGB strips (80 cm)

    1 x Extension cable for Addressable LED

    3 x Thermistor cable(s)

    1 x USB drive with utilities and drivers

    1 x ROG coaster(s)

    1 x ROG weave SATA 6G cable

    1 x ROG Thank you card
    BIOS2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.1
    ManageabilityWOL , PXE
    Operating SystemWindows® 10 64-bit
    Form FactorExtended ATX Form Factor

    12 inch x 10.9 inch ( 30.5 cm x 27.7 cm )
    Note*1 Please refer to Memory QVL(Qualified Vendors List) for details.

    *2 When the M.2 Socket 3 on board is operating in PCIe mode, PCIe 3.0 x16_4 will runs at x4 mode.

    *3 Supports PCIE RAID configurations via onboard M.2 storages.

    *4 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.

    All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

    Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

    PCB color and bundled software versions are subject to change without notice.

    Brand and product names mentioned are trademarks of their respective companies.
