Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard

Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
  • Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
  • Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
  • Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
  • Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
  • Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
$169.0
RRP:$179.0    Save $10.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard
  • Model Number:
    B365M AORUS ELITE
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    ?Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard

    Supports 9th and 8th Gen Intel® Core™ Processors

    Dual Channel Non-ECC Unbuffered DDR4

    New Hybrid Digital PWM Design

    M.2 Socket 1 slot for WIFI upgradable

    High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting

    Dual Ultra-Fast M.2 with PCIe Gen3 X4/X4 & SATA interface

    RGB FUSION 2.0 with Digital LED Light Show design

    Intel® USB 3.1 Gen1 USB Type-C™

    Intel® GbE LAN with cFosSpeed Internet Accelerator Software

    CEC 2019 Ready, Save the Power as Easy as One Click

    Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP

    Anti-Sulfur Resistors Design

    Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection

    Intel® Optane™ Memory Read

    Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard

    Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard

    Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard

    Gigabyte B365M AORUS ELITE M.2 LGA 1151 mATX Motherboard

    SPECIFICATIONS:

    CPU

    Support for 9th and 8th Generation Intel® Core™   i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel®   Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in   the LGA1151 package

    L3 cache varies with CPU

    (Please refer "CPU Support List" for   more information.)

    CHIPSET

    Intel® B365 Express Chipset

    MEMORY

    4 x DDR4 DIMM sockets   supporting up to 64 GB of system memory

    Dual channel memory   architecture

    Support for DDR4 2666/2400/2133   MHz memory modules

    Support for ECC Un-buffered   DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

    Support for non-ECC Un-buffered   DIMM 1Rx8/2Rx8/1Rx16 memory modules

    Support for Extreme Memory   Profile (XMP) memory modules

    * To support 2666 MHz or XMP   memory, you must install a 9th or 8th Generation Intel® Core™ i9/i7/i5   processor.

    (Please refer "Memory   Support List" for more information.)

    EXPANSION SLOTS

    1 x PCI Express x16 slot, running at x16   (PCIEX16)

    * For optimum performance, if only one PCI   Express graphics card is to be installed, be sure to install it in the   PCIEX16 slot.

    1 x PCI Express x16 slot, running at x4 (PCIEX4)

    1 x PCI Express x1 slot

    (All of the PCI Express slots conform to PCI   Express 3.0 standard.)

    1 x M.2 Socket 1 connector for the wireless   communication module (M2_WIFI)

    ONBOARD GRAPHICS

    Integrated Graphics Processor-Intel® HD Graphics   support:

    1 x DVI-D port, supporting a maximum resolution   of 1920x1200@60 Hz

    * The DVI-D port does not support D-Sub   connection by adapter.

    1 x DisplayPort, supporting a maximum resolution   of 4096x2304@60 Hz

    * Support for DisplayPort 1.2 version, HDCP 2.2,   and HDR.

    1 x HDMI port, supporting a maximum resolution of   4096x2160@30 Hz

    * Support for HDMI 1.4 version and HDCP 2.2.

    Support for up to 3 displays at the same time

    Maximum shared memory of 1 GB

    MULTI GRAPHICS   TECHNOLOGY

    Support for AMD Quad-GPU   CrossFire™ and 2-Way AMD CrossFire™ technologies

    STORAGE INTERFACE

    Chipset:

    1 x M.2 connector (Socket 3, M key, type   2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q)

    1 x M.2 connector (Socket 3, M key, type   2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A)

    6 x SATA 6Gb/s connectors

    Support for RAID 0, RAID 1, RAID 5, and RAID 10

    * Refer to "1-7 Internal Connectors,"   for the installation notices for the M.2 and SATA connectors.

    Intel® Optane™ Memory Ready

    USB PORTS

    Chipset:

    1 x USB Type-C™ port on the   back panel, with USB 3.1 Gen 1 support

    5 x USB 3.1 Gen 1 ports (3   ports on the back panel, 2 ports available through the internal USB header)

    6 x USB 2.0/1.1 ports (2 ports   on the back panel, 4 ports available through the internal USB headers)

    AUDIO

    Realtek® ALC892 codec

    High Definition Audio

    2/4/5.1/7.1-channel

    Support for S/PDIF Out

    LAN

    Intel® GbE LAN chip (10/100/1000   Mbit)

    INTERNAL I/O   CONNECTORS

    1 x 24-pin ATX main power connector

    1 x 8-pin ATX 12V power connector

    1 x CPU fan header

    3 x system fan headers

    2 x addressable LED strip headers

    2 x addressable LED strip power select jumpers

    2 x RGB LED strip headers

    6 x SATA 6Gb/s connectors

    2 x M.2 Socket 3 connectors

    1 x front panel header

    1 x front panel audio header

    1 x S/PDIF Out header

    1 x USB 3.1 Gen 1 header

    2 x USB 2.0/1.1 headers

    1 x Trusted Platform Module (TPM) header (2x6   pin, for the GC-TPM2.0_S module only)

    1 x serial port header

    1 x Clear CMOS jumper

    BACK PANEL PORTS

    1 x PS/2 keyboard/mouse port

    1 x DVI-D port

    1 x DisplayPort

    1 x HDMI port

    1 x USB Type-C™ port, with USB 3.1 Gen 1 support

    3 x USB 3.1 Gen 1 ports

    2 x USB 2.0/1.1 ports

    1 x RJ-45 port

    6 x audio jacks

    I/O CONTROLLER

    iTE® I/O Controller Chip

    H/W MONITORING

    Voltage detection

    Temperature detection

    Fan speed detection

    Overheating warning

    Fan fail warning

    Fan speed control

    * Whether the fan speed control function is supported   will depend on the cooler you install.

    BIOS

    2 x 128 Mbit flash

    Use of licensed AMI UEFI BIOS

    Support for DualBIOS™

    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

    UNIQUE FEATURES

    Support for APP Center

    * Available applications in APP Center may vary   by motherboard model. Supported functions of each application may also vary   depending on motherboard specifications.

    3D OSD

    @BIOS

    AutoGreen

    Cloud Station

    EasyTune

    Easy RAID

    Fast Boot

    Game Boost

    ON/OFF Charge

    Platform Power Management

    RGB Fusion

    Smart Backup

    Smart Keyboard

    Smart TimeLock

    Smart HUD

    Smart Survey

    System Information Viewer

    USB Blocker

    Support for Q-Flash

    Support for Xpress Install

    BUNDLED SOFTWARE

    Norton® Internet Security (OEM version)

    cFosSpeed

    FORM FACTOR

    Micro ATX Form Factor; 610px x 610px

    OPERATING SYSTEM

    Support for Windows 10 64-bit

    REMARK

    Due to different Linux support   condition provided by chipset vendors, please download Linux driver from   chipset vendors' website or 3rd party website.

    Most hardware/software vendors   may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available   from the vendors, we will update them on the GIGABYTE website.
