Gigabyte TRX40 Aorus Master E-ATX Motherboard

Gigabyte TRX40 Aorus Master E-ATX Motherboard
  • Gigabyte TRX40 Aorus Master E-ATX Motherboard
  • Gigabyte TRX40 Aorus Master E-ATX Motherboard
  • Gigabyte TRX40 Aorus Master E-ATX Motherboard
  • Gigabyte TRX40 Aorus Master E-ATX Motherboard
$929.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-2 Days excluding Weekends



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Gigabyte TRX40 Aorus Master E-ATX Motherboard
  • Model Number:
    TRX40 AORUS MASTER
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    AMD TRX40 AORUS Motherboard with Direct 16+3 Phases Infineon Digital VRM, Fins-Array Heatsink, NanoCarbon Baseplate, 5GbE+1GbE LAN, 3 PCIe 4.0 M.2 with Thermal Guards, Intel® WiFi 6 802.11ax, ESS SABRE HiFi 9218 DAC, RGB FUSION 2.0


    Supports 3rd Gen AMD Ryzen™ Threadripper™ Processors

    Quad Channel ECC/ Non-ECC Unbuffered DDR4, 8 DIMMs

    16+3 Phases Infineon Digital VRM Solution with 70A Power Stage

    Advanced Thermal Design with Fins-Array Heatsink, Heatpipe with Extended Heatsink and NanoCarbon Baseplate

    AQUANTIA® 5GbE LAN and Intel® GbE LAN with cFosSpeed

    3 Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Thermal Guards

    Onboard Intel® WiFi 6 802.11ax 2T2R & BT 5

    130dB SNR AMP-UP Audio with High-End ESS SABRE 9218 DAC, ALC1220-VB and WIMA Audio Capacitors

    USB TurboCharger for Mobile Device Fast Charge Support

    RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips

    Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP and Noise Detection

    Front & Rear USB 3.2 Gen 2 Type-C™ Header

    Q-Flash Plus Update BIOS Without Installing CPU, Memory and Graphics Card

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    Gigabyte TRX40 Aorus Master E-ATX Motherboard

    SPECIFICATIONS:

    CPU

    AMD Socket sTRX4:

    Support 3rd Generation AMD Ryzen™   Threadripper™ processors

    (Please refer "CPU Support   List" for more information.)

    Chipset



    AMD TRX40

    Memory

    8 x DDR4 DIMM sockets supporting up   to 256 GB (32 GB single DIMM capacity) of system memory

    Quad Channel memory architecture

    Support for DDR4 4400(O.C.) /   4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) /   3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400   / 2133 MHz memory modules

    Support for ECC Un-buffered DIMM   1Rx8/2Rx8 memory modules

    Support for non-ECC Un-buffered   DIMM 1Rx8/2Rx8/1Rx16 memory modules

    Support for Extreme Memory Profile   (XMP) memory modules

    Audio

    1 x Realtek® ALC4050H codec+1 x   Realtek® ALC1220-VB codec (Rear audio)

    1 x Realtek® ALC4050H codec+1 x ESS   SABRE9218 DAC chips (Front audio)

    Support for DTS:X® Ultra

    High Definition Audio

    2/4/5.1/7.1-channel

    Support for S/PDIF Out

    LAN

    1 x Aquantia 5GbE LAN chip (5   Gbit/2.5 Gbit/1 Gbit/100 Mbit) (5GLAN)

    1 x Intel® GbE LAN chip   (10/100/1000 Mbit) (LAN)

    Wireless   Communication module

    Intel® Wi-Fi 6 AX200

    Wi-Fi 802.11a/b/g/n/ac/ax,   supporting 2.4/5 GHz Dual-Band

    BLUETOOTH 5.0

    Support for 11ax 160MHz wireless   standard and up to 2.4 Gbps data rate

    * Actual data rate may vary   depending on environment and equipment.

    Expansion   slots



    2 x PCI Express x16 slots, running   at x16 (PCIEX16_1, PCIEX16_2)

    2 x PCI Express x16 slots, running   at x8 (PCIEX8_1, PCIEX8_2)

    1 x PCI Express x1 slot

    (All of the PCI Express slots   conform to PCI Express 4.0 standard.)

    Multi-Graphics   Technology

    Support for NVIDIA® Quad-GPU SLI™   and 3-Way/2-Way NVIDIA® SLI™ technologies

    Support for AMD Quad-GPU CrossFire™   and 3-Way/2-Way AMD CrossFire™ technologies

    Storage   Interface

    Integrated in the CPU:

    1 x M.2 connector (Socket 3, M key,   type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M)

    1 x M.2 connector (Socket 3, M key,   type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q)

    Integrated in the Chipset:

    1 x M.2 connector (Socket 3, M key,   type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2P)

    8 x SATA 6Gb/s connectors

    Support for RAID 0, RAID 1, and   RAID 10

    USB

    Integrated in the CPU:

    4 x USB 3.2 Gen 2 Type-A ports   (red) on the back panel

    Integrated in the Chipset:

    1 x USB Type-C™ port on the back   panel, with USB 3.2 Gen 2 support

    1 x USB 3.2 Gen 2 Type-A port (red)   on the back panel

    1 x USB Type-C™ port with USB 3.2   Gen 2 support, available through the internal USB header

    4 x USB 3.2 Gen 1 ports available   through the internal USB headers

    Chipset+2 USB 2.0 Hubs:

    6 x USB 2.0/1.1 ports (2 ports on   the back panel, 4 ports available through the internal USB headers)

    I/O Ports

    1 x 24-pin ATX main power connector

    2 x 8-pin ATX 12V power connectors

    1 x CPU fan header

    1 x water cooling CPU fan header

    2 x system fan headers

    4 x system fan/water cooling pump   headers

    2 x addressable LED strip headers

    2 x RGB LED strip headers

    3 x M.2 Socket 3 connectors

    8 x SATA 6Gb/s connectors

    1 x front panel header

    1 x front panel audio header

    1 x USB Type-C™ port, with USB 3.2   Gen 2 support

    2 x USB 3.2 Gen 1 headers

    2 x USB 2.0/1.1 headers

    1 x noise detection header

    1 x GIGABYTE add-in card connector

    1 x Trusted Platform Module (TPM)   header (2x6 pin, for the GC-TPM2.0_S module only)

    1 x power button

    1 x reset button

    2 x BIOS switches

    2 x temperature sensor headers

    1 x Clear CMOS jumper

    Voltage Measurement Points

    Back panel   Connectors

    1 x Q-Flash Plus button

    1 x Clear CMOS button

    2 x SMA antenna connectors (2T2R)

    1 x USB Type-C™ port, with USB 3.1   Gen 2 support

    5 x USB 3.2 Gen 2 Type-A ports   (red)

    2 x USB 2.0/1.1 ports

    2 x RJ-45 ports

    1 x optical S/PDIF Out connector

    5 x audio jacks

    I/O   Controller

    iTE® I/O Controller Chip

    H/W   Monitoring

    Voltage detection

    Temperature detection

    Fan speed detection

    Water cooling flow rate detection

    Overheating warning

    Fan fail warning

    Fan speed control

    * Whether the fan (pump) speed   control function is supported will depend on the fan (pump) you install.

    Noise detection

    BIOS

    2 x 128 Mbit flash

    Use of licensed AMI UEFI BIOS

    Support for DualBIOS™

    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS   2.7, ACPI 5.0

    Unique Features

    Support for APP Center

    * Available applications in APP   Center may vary by motherboard model. Supported functions of each application   may also vary depending on motherboard specifications.

    @BIOS

    AutoGreen

    Cloud Station EasyTune

    Fast Boot

    Game Boost

    RGB Fusion

    Smart Backup

    Smart Keyboard

    Smart Survey

    System Information Viewer

    USB Blocker

    USB TurboCharger

    Support for Q-Flash Plus

    Support for Q-Flash

    Support for Xpress Install

    Bundled Softwares

    Norton® Internet Security (OEM   version)

    cFosSpeed

    XSplit Gamecaster + Broadcaster (12   months license)

    Operating System

    Support for Windows 10 64-bit

    Form Factor

    E-ATX Form Factor; 30.5cm x 26.9cm

    Remark

    Due to different Linux support   condition provided by chipset vendors, please download Linux driver from   chipset vendors' website or 3rd party website.

    Most hardware/software vendors may   no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available   from the vendors, we will update them on the GIGABYTE website.
