Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
  • Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
  • Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
  • Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
  • Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
  • Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
$519.0
RRP:$801.9    Save $282.9
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-3 Days excluding Weekends

  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Click & Collect.

Specifications

  • Product Name:
    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard
  • Model Number:
    GA-X299XAORUS-MASTER
  • Brand:
  • Manufacturer Warranty:
    1 Year
  • Description

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Supports Intel® Core™ X-series Processor Family

    Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs

    Intel® Optane™ Memory Ready

    12 Phases IR Digital VRM Solution with 70A Power Stage

    Onboard Intel® WiFi 6 802.11ax 2T2R & BT 5 with AORUS Antenna

    130dB SNR AMP-UP Audio with High-End ESS SABRE 9218 DAC, ALC1220 and WIMA Audio Capacitors

    Onboard AQUANTIA 5GbE BASE-T LAN and Intel® Gigabit LAN with cFosSpeed

    Triple Ultra-Fast NVMe PCIe 3.0 x4 M.2 with Triple Thermal Guards

    USB TurboCharger for Mobile Device Fast Charge Support

    RGB FUSION 2.0 supported with Multi-Zone Addressable LED Light Show Design, support Addressable LED & RGB LED Strips

    Smart Fan 5 features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP and Noise Detection

    Front USB 3.2 Gen2 Type-C™ Header

    Q-Flash Plus update BIOS without installing CPU, Memory and Graphics card

    Supports 4 Way Dual Wide PCIe Slots

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard

    Gigabyte X299X Aorus Master LGA 2066 E-ATX Motherboard


    SPECIFICATIONS:

    CPU

    Support for Intel® Core™ i7-7800X and above X series   processors/Intel® Core™ i9 X series processors in the LGA2066 package

    L3 cache varies with CPU

    Chipset

    Intel® X299 Express Chipset

    Memory

    Intel® Core™ X series 48-lane processors:

    8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity)   of system memory

    Support for DDR4 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) /   3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) /   3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) /   2933/2666/2400/2133 MHz memory modules

    Intel® Core™ X series 44-lane/28-lane processors:

    8 x DDR4 DIMM sockets supporting up to 128 GB (16 GB single DIMM   capacity) of system memory

    Support for DDR4 4200(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) /   3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) /   3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2666/2400/2133 MHz memory   modules

    4 channel memory architecture

    Support for non-ECC Un-buffered DIMM memory modules

    Support for Extreme Memory Profile (XMP) memory modules

    (Please refer "Memory Support List" for more information.)

    Audio

    Realtek® ALC1220-VB codec

    * The front panel line out jack supports DSD audio.

    ESS SABRE9218 DAC chip

    High Definition Audio

    2/4/5.1/7.1-channel

    Support for S/PDIF Out

    LAN

    1 x Aquantia 5GbE LAN chip (5 Gbit/2.5 Gbit/1000 Mbit/100 Mbit)   (LAN1)

    1 x Intel® GbE LAN chip (10/100/1000 Mbit) (LAN2)

    Wireless Communication module

    Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band

    BLUETOOTH 5.0

    Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data   rate

    Expansion Slots

    Intel® Core™ X series 48-lane processors:

    2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)

    2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)

    * The PCIEX16_2 slot shares bandwidth with the PCIEX8_1 slot. When   the PCIEX8_1 slot is populated, the PCIEX16_2 slot operates at up to x8 mode.

    Intel® Core™ X series 44-lane processors:

    2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)

    1 x PCI Express x16 slot, running at x8 (PCIEX8_1)

    1 x PCI Express x16 slot, running at x4 (PCIEX8_2)

    * The PCIEX16_2 slot shares bandwidth with the PCIEX8_1 slot. When   the PCIEX8_1 slot is populated, the PCIEX16_2 slot operates at up to x8 mode.

    Intel® Core™ X series 28-lane processors:

    1 x PCI Express x16 slot, running at x16 (PCIEX16_1)

    1 x PCI Express x16 slot, running at x8 (PCIEX16_2)

    1 x PCI Express x16 slot, running at x4 (PCIEX8_2)

    * For optimum performance, if only one PCI Express graphics card is   to be installed, be sure to install it in the PCIEX16_1 slot.

    Multi-Graphics Technology

    Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies

    Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™   technologies

    Storage Interface

    CPU:

    1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2   SSD support) (M2M)

    1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe   x4/x2 SSD support) (M2Q)

    * The M2M and M2Q connectors become unavailable when an Intel® Core™   X series 28-lane processor is used.

    Chipset:

    1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA   and PCIe x4/x2 SSD support) (M2P)

    8 x SATA 6Gb/s connectors



    Support for RAID 0, RAID 1, RAID 5, and RAID 10

    The M2M and M2Q connectors must work with an Intel® VROC Upgrade Key   to support RAID configuration. If you want to use VROC, refer to Chapter 3-4,   "Configuring Intel® Virtual RAID on CPU (Intel® VROC)," for setup   instructions.

    * Refer to "1-9 Internal Connectors," for the installation   notices for the M.2 and SATA connectors.

    Intel® Optane™ Memory Ready

    * Only Intel® Core™ X series 48-lane processors support Intel®   Optane™ Memory.

    Intel® VROC Ready

    USB

    Chipset+2 ASMedia® USB 3.2 Gen 2 Controllers:

    1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through   the internal USB header

    1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support

    1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

    Chipset+Realtek® USB 3.2 Gen 1 Hub:

    2 x USB 3.2 Gen 1 ports on the back panel

    2 x USB 2.0/1.1 ports on the back panel

    Chipset+USB 2.0 Hub:

    4 x USB 2.0/1.1 ports available through the internal USB headers

    Chipset:

    8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available   through the internal USB headers)

    2 x USB 2.0/1.1 ports available through the internal USB header

    Internal I/O Connectors

    1 x 24-pin ATX main power connector

    2 x 8-pin ATX 12V power connectors

    1 x CPU fan header

    1 x water cooling CPU fan header

    4 x system fan headers

    2 x system fan/water cooling pump headers

    2 x addressable LED strip headers

    2 x RGB LED strip headers

    3 x M.2 Socket 3 connectors

    8 x SATA 6Gb/s connectors

    1 x Intel® VROC Upgrade Key header

    1 x front panel header

    1 x front panel audio header

    1 x USB Type-C™ port, with USB 3.2 Gen 2 support

    2 x USB 3.2 Gen 1 headers

    3 x USB 2.0/1.1 headers

    1 x noise detection header

    1 x Thunderbolt™ add-in card connector

    1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S   module only)

    1 x power button

    1 x reset button

    2 x temperature sensor headers

    1 x Clear CMOS jumper

    2 x BIOS switches

    Back Panel Connectors

    1 x Q-Flash Plus button

    1 x Clear CMOS button

    1 x USB Type-C™ port, with USB 3.2 Gen 2 support

    1 x USB 3.2 Gen 2 Type-A port (red)

    6 x USB 3.2 Gen 1 ports

    2 x USB 2.0/1.1 ports

    2 x RJ-45 ports

    2 x SMA antenna connectors (2T2R)

    1 x optical S/PDIF Out connector

    5 x audio jacks

    I/O Controller

    iTE® I/O Controller Chip

    H/W Monitoring

    Voltage detection

    Temperature detection

    Fan speed detection

    Water cooling flow rate detection

    Overheating warning

    Fan fail warning

    Fan speed control

    * Whether the fan (pump) speed control function is supported will   depend on the fan (pump) you install.

    Noise Detection

    BIOS

    22 x 128 Mbit flash

    Use of licensed AMI UEFI BIOS

    Support for DualBIOS™

    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

    Unique Features

    Support for APP Center

    * Available applications in APP Center may vary by motherboard model.   Supported functions of each application may also vary depending on   motherboard specifications.

    @BIOS

    AutoGreen

    Cloud Station

    EasyTune

    Easy RAID

    Fast Boot

    Game Boost

    Platform Power Management

    RGB Fusion

    Smart Backup

    Smart Keyboard

    Smart Survey

    System Information Viewer

    USB Blocker

    USB TurboCharger

    Support for Q-Flash Plus

    Support for Q-Flash

    Support for Xpress Install

    Bundled Software

    Norton® Internet Security (OEM version)

    cFosSpeed

    XSplit Gamecaster + Broadcaster (12 months license)

    Operating System

    Support for Windows 10 64-bit

    Form Factor

    E-ATX Form Factor; 30.5cm x 26.9cm
