Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
  • Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
  • Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
  • Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
  • Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
  • Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
$2,834.0
RRP:$2,969.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-2 Days excluding Weekends



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard
  • Model Number:
    GA-X299XAORUS-XTREME-WF
  • Brand:
  • Manufacturer Warranty:
    1 Year
  • Description

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard


    Supports Intel® Core™ X-series Processor Family

    Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs

    Intel® Optane™ Memory Ready

    16 Phases IR Digital VRM Solution with 70A Power Stage

    World's First AORUS All-In-One Monoblock for CPU, VRM, SSD and PCH

    Intel® Thunderbolt™ 3 Onboard

    Onboard Intel® WiFi 6 802.11ax 2T2R & BT 5 with 2X AORUS Antenna

    130dB SNR AMP-UP Audio with High-End ESS SABRE 9218 DAC, ALC1220 and WIMA Audio Capacitors on Front and Rear Audio Output

    AQUANTIA® 10GbE BASE-T LAN and Intel® Gigabit LAN with cFosSpeed

    Exclusive AORUS Gen4 AIC Adaptor for Extra 4x NVMe PCIe 3.0 x4 M.2

    Exclusive RGB FAN COMMANDER for Professional Casemodders

    Watercooled Dual Ultra-Fast NVMe PCIe 3.0 x4 M.2

    USB TurboCharger for Mobile Device Fast Charge Support

    RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, support Addressable LED & RGB LED Strips

    Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP and Noise Detection

    2 x Front USB 3.2 Gen 2 Type-C™ Header

    Q-Flash Plus Update BIOS without Installing CPU, Memory and Graphics card


    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard

    Gigabyte X299X Aorus Xtreme Waterforce LGA 2066 XL-ATX Motherboard


    SPECIFICATIONS:

    CPU

    Support for Intel® Core™ i7-7800X and above X series   processors/Intel® Core™ i9 X series processors in the LGA2066 package

    L3 cache varies with CPU

    Chipset

    Intel® X299 Express Chipset

    Memory

    Intel® Core™ X series 48-lane processors:

    8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM   capacity) of system memory

    Support for DDR4 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) /   3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) /   3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) /   2933/2666/2400/2133 MHz memory modules

    Intel® Core™ X series 44-lane/28-lane processors:

    8 x DDR4 DIMM sockets supporting up to 128 GB (16 GB single DIMM   capacity) of system memory

    Support for DDR4 4200(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) /   3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) /   3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2666/2400/2133 MHz memory   modules

    4 channel memory architecture

    Support for non-ECC Un-buffered DIMM memory modules

    Support for Extreme Memory Profile (XMP) memory modules

    (Please refer "Memory Support List" for more information.)

    Onboard Graphics

    Intel® Thunderbolt™ 3 Controller:

    2 x Intel® Thunderbolt™ 3 connectors (USB Type-C™ ports), supporting   DisplayPort and Thunderbolt™ video outputs and a maximum resolution of   4096x2304@60 Hz

    * Because of the limited I/O resources of the PC architecture, the   number of Thunderbolt™ devices that can be used is dependent on the number of   the PCI Express devices being installed. (Refer to Chapter 1-7, "Back   Panel Connectors," for more information.)

    * Support for DisplayPort 1.4 version.

    Maximum shared memory of 1 GB

    Audio

    2 x Realtek® ALC1220-VB codecs

    2 x ESS SABRE9218 DAC chips

    High Definition Audio

    2/4/5.1/7.1-channel

    Support for S/PDIF Out

    LAN

    1 x Aquantia 10GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1 Gbit/100 Mbit)   (LAN1)

    1 x Intel® GbE LAN chip (10/100/1000 Mbit) (LAN2)

    Wireless Communication module

    Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band

    BLUETOOTH 5.0

    Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data   rate

    Expansion Slots

    Intel® Core™ X series 48-lane processors:

    3 x PCI Express x16 slots, running at x16

    Intel® Core™ X series 44-lane processors:

    2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)

    1 x PCI Express x16 slot, running at x8 (PCIEX16_3)

    Intel® Core™ X series 28-lane processors:

    1 x PCI Express x16 slot, running at x16 (PCIEX16_1)

    1 x PCI Express x16 slot, running at x8 (PCIEX16_2)

    * For optimum performance, if only one PCI Express graphics card is   to be installed, be sure to install it in the PCIEX16_1 slot.

    Multi-Graphics Technology

    Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies

    Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™   technologies

    Storage Interface

    2 x M.2 connectors (Socket 3, M key, type 2242/2260/2280/22110 SATA   and PCIe x4/x2 SSD support)

    8 x SATA 6Gb/s connectors

    Support for RAID 0, RAID 1, RAID 5, and RAID 10

    * The M2P and M2Q connectors must work with an Intel® VROC Upgrade   Key to support RAID configuration.

    * Refer to "1-9 Internal Connectors," for the installation   notices for the M.2 and SATA connectors.

    Intel® Optane™ Memory Ready

    * Only Intel® Core™ X series 48-lane processors support Intel®   Optane™ Memory.

    Intel® VROC Ready

    USB

    Chipset+Intel® Thunderbolt™3 Controller:

    2 x USB Type-C™ ports on the back panel, with USB 3.2 Gen 2 support

    Chipset+2 ASMedia® USB 3.2 Gen 2 Controllers:

    2 x USB Type-C™ ports with USB 3.2 Gen 2 support, available through   the internal USB headers

    2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

    Chipset:

    6 x USB 3.2 Gen 1 ports (2 ports on the back panel, 4 ports available   through the internal USB headers)

    2 x USB 2.0/1.1 ports on the back panel

    Chipset+2 USB 2.0 Hubs:

    6 x USB 2.0/1.1 ports available through the internal USB headers

    Internal I/O Connectors

    1 x 24-pin ATX main power connector

    2 x 8-pin ATX 12V power connectors

    1 x VGA_PW power connector

    1 x CPU fan header

    1 x water cooling CPU fan header

    1 x water cooling kit CPU LED header (LED_CPU)

    1 x water cooling kit Chipset LED header (LED_PCH)

    4 x system fan headers

    2 x system fan/water cooling pump headers

    2 x addressable LED strip headers

    2 x RGB LED strip headers

    2 x M.2 Socket 3 connectors

    8 x SATA 6Gb/s connectors

    1 x Intel® VROC Upgrade Key header

    1 x front panel header

    1 x front panel audio header

    2 x USB Type-C™ ports, with USB 3.2 Gen 2 support

    2 x USB 3.2 Gen 1 headers

    3 x USB 2.0/1.1 headers

    1 x noise detection header

    1 x Trusted Platform Module (TPM) header (2x6 pin, for the   GC-TPM2.0_S module only)

    1 x Clear CMOS jumper

    1 x power button

    1 x OC Ignition button

    1 x OC button

    1 x reset button

    1 x Clear CMOS button

    2 x temperature sensor headers

    2 x BIOS switches

    Back Panel Connectors

    2 x Thunderbolt™ 3 connectors (USB Type-C™ ports, with USB 3.2 Gen 2   support)

    2 x USB 3.2 Gen 2 Type-A ports (red)

    2 x USB 3.2 Gen 1 ports

    2 x USB 2.0/1.1 ports

    2 x DisplayPort In ports

    2 x RJ-45 ports

    2 x SMA antenna connectors (2T2R)

    1 x optical S/PDIF Out connector

    5 x audio jacks

    I/O Controller

    iTE®I/O Controller Chip

    H/W Monitoring

    Voltage detection

    Temperature detection

    Fan speed detection

    Water cooling flow rate detection

    Overheating warning

    Fan fail warning

    Fan speed control

    * Whether the fan (pump) speed control function is supported will   depend on the fan (pump) you install.

    Noise detection

    BIOS

    2 x 128 Mbit flash

    Use of licensed AMI UEFI BIOS

    Support for DualBIOS™

    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

    Unique Features

    Support for APP Center

    * Available applications in APP Center may vary by motherboard model.   Supported functions of each application may also vary depending on   motherboard specifications.

    @BIOS

    AutoGreen

    Cloud Station

    EasyTune

    Easy RAID

    Fast Boot

    Game Boost

    Platform Power Management

    RGB Fusion

    Smart Backup

    Smart Keyboard

    Smart Survey

    System Information Viewer

    USB Blocker

    USB TurboCharger

    Support for Q-Flash Plus

    Support for Q-Flash

    Support for Xpress Install

    Bundled Software

    Norton® Internet Security (OEM version)

    cFosSpeed

    XSplit Gamecaster + Broadcaster (12 months license)

    Operating System

    XL-ATX Form Factor; 32.5cm x 27.5cm

    Form Factor

    E-ATX Form Factor; 30.5cm x 27.5cm
