Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane

Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
$269.0
RRP:$279.0    Save $10.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1 business day



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Products name:
    Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane
  • Model #:
    GA-Z370-AORUS-ULTRA-GAMING-WIFI-OP
  • Brand:
  • Warranty:
    36 Months
  • Description

    Gigabyte Z370 Aorus Ultra Gaming Wifi LGA 1151 ATX Motherboard + Intel Optane


    Ready for Intel® Core™ i7+/i5+ platforms, Intel Z370 Gaming motherboard with Intel Optane Memory accelerated, RGB Fusion, Digital LED support, Dual M.2, 120dB SNR ALC1220, Intel Gaming LAN, Front USB 3.1 Gen 1 Type-C & Rear USB 3.1 Gen 2 Type-C, Smart Fan 5, Anti-Sulfur Resistors


    • Supports 8th Gen Intel® Core™ Processors

    • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs

    • Built-in 32GB Intel® Optane™ Memory, the ultimate storage performance enhancer

    • ASMedia 3142 USB 3.1 Gen 2 with USB Type-C™ and Type-A

    • Front USB 3.1 Gen 1 Type-C™ Header

    • Multi-Way Graphics Support with Dual Armor and Ultra Durable™ Design

    • ALC1220 120dB SNR HD Audio with Smart Headphone AMP and WIMA audio capacitors

    • Intel GbE LAN Gaming Network with cFosSpeed Internet Accelerator Software

    • RGB FUSION with Multi-Zone Digital LED Light Show design, support digital LED & RGB LED strips

    • Swappable Overlay for Accent LED

    • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP

    • Dual Ultra-Fast M.2 with PCIe Gen3 x4 & SATA interface

    • USB DAC-UP 2 with Adjustable Voltage

    • Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection

    • Lightning-Fast Intel® Thunderbolt™ 3 AIC Support


    Specifications

    Full SpecificationClick here
    CPU
    1. Support for 8th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors in the LGA1151 package
    2. L3 cache varies with CPU
    (Please refer "CPU Support List" for more information.)
    Chipset
       Intel® Z370 Express Chipset
    Memory
    1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
    2. Dual channel memory architecture
    3. Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules
    4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    6. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)
    Onboard Graphics
         Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
                 * Support for HDMI 1.4 version and HDCP 2.2.
    Maximum shared memory of 1 GB
    Audio
    1. Realtek® ALC1220 codec
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
    4. Support for S/PDIF Out
    Expansion Slots
    1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
               * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    2. 1 x PCI Express x16 slot, running at x8 (PCIEX8)
               * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
    3. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
               * The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. When the PCIEX1_2 or PCIEX1_3 slot is populated, the PCIEX4 slot operates at up to x1 mode.
    4. 3 x PCI Express x1 slots
               (All of the PCI Express slots conform to PCI Express 3.0 standard.)
    Memory
    1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
    2. Dual channel memory architecture
    3. Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules
    4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    6. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)
    Storage InterfaceChipset:
    1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q_32G)
    2. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A_32G)
    3. 32 GB Intel® Optane™ Memory pre-installed (M2Q_32G)
    4. 6 x SATA 6Gb/s connectors
    5. Support for RAID 0, RAID 1, RAID 5, and RAID 10
                 * Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
    Intel® Optane™ Memory Ready
    Operating System
    1. Support for Windows 10 64-bit

    * The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
     * Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
     * All trademarks and logos are the properties of their respective holders.
    * Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
