QNAP TS-463XU-RP-4G 4 Bay Quad Core 4GB 1U Rackmount TurboNAS

CPU ARCHITECTURE

64-bit x86

FLOATING POINT UNIT

Yes

ENCRYPTION ENGINE

(AES-NI)

SYSTEM MEMORY

4 GB SO-DIMM DDR3L (1 x 4 GB)

MAXIMUM MEMORY

16 GB (2 x 8 GB)

MEMORY SLOT

2 x SO-DIMM DDR3L

For dual-DIMM configuration,   you must use a pair of identical DDR3L modules.

FLASH MEMORY

512MB (Dual boot OS protection)

DRIVE BAY

4 x 2.5-inch or 3.5-inch SATA   6Gb/s, 3Gb/s

The system is shipped without   HDD.
  For the HDD compatibility list, please visit https://www.qnap.com/compatibility/

DRIVE COMPATIBILITY

3.5-inch SATA hard disk drives
  2.5-inch SATA hard disk drives
  2.5-inch SATA solid state drives

HOT-SWAPPABLE

Yes

M.2 SSD SLOT

Optional via a PCIe adapter

SSD CACHE ACCELERATION SUPPORT

Yes

GIGABIT ETHERNET PORT (RJ45)

4

Expandable with an optional   PCIe adapter

10 GIGABIT ETHERNET PORT

1 x 10GBASE-T   (10G/5G/2.5G/1G/100M)

Pre-installed QXG-10G1T PCIe   adapter

JUMBO FRAME

Yes

PCIE SLOT

1 x PCIe Gen 2 (x4)

Pre-installed QXG-10G1T PCIe   adapter

USB 2.0 PORT

3

USB 3.0 PORT

2

USB 3.1 GEN 2 (10GBPS) PORT

Optional via a PCIe expansion   adapter

FORM FACTOR

1U Rackmount

LED INDICATORS

HDD 1-4, Status, USB, LAN

BUTTONS

Power, Reset, USB Auto Copy

DIMENSIONS (HXWXD)

44 × 439 × 499 mm

WEIGHT (NET)

7.63 kg

WEIGHT (GROSS)

11.6 kg

OPERATING TEMPERATURE

0 - 40 °C (32°F - 104°F)

RELATIVE HUMIDITY

5~95% RH non-condensing, wet   bulb: 27˚C (80.6˚F)

POWER SUPPLY UNIT

Redundant 250W, Input: 110-240   Vac~, 50-60Hz, 5A

POWER CONSUMPTION: HDD SLEEP MODE

44.9 W

POWER CONSUMPTION: OPERATING MODE, TYPICAL

65.62 W

SOUND LEVEL

36.4 db(A)
