QNAP TS-853BU-RP-4G 8 Bay Quad Core 4GB 2U Rackmount NAS
The TS-853BU-RP is a 2U rackmount NAS that easily fits into a standard 19-inch rack, providing an ideal storage solution in the server room for small and medium businesses. The TS-853BU-RP comes with a PCIe slot for boosting potential applications: the QNAP QM2 expansion card can be installed to add an M.2 SSD cache/10GbE connectivity, a compatible wireless card can be installed to use the TS-853BU-RP as a wireless access point, and a USB 3.1 10Gbps card can be added for easier backup to/from multiple external storage. The TS-853BU-RP also provides a wide range of value-added features: 4K video playback and real-time transcoding; deployment of virtual environments through Virtualization Station and Container Station; centralized management of remote Windows®, Linux® and IPMI-compatible devices with QRM+; and web automation services with IFTTT Agent.
PCIe slot supports installing a QNAP QM2 dual-port M.2 SSD/10GbE card, a compatible wireless adapter, or a USB 3.1 10Gbps card.
Supports dual-channel 4K H.264 hardware decoding and on-the-fly or offline transcoding
Qfiling automates file organization and Qsirch provides full-text search for easier file management
QRM+ enables centralized management of remote Windows®, Linux® and IPMI-compatible devices.
A hybrid approach to virtualization in one NAS: Virtualization Station and Container Station
Scalable storage space with VJBOD and UX-1200U-RP/UX-800U-RP expansion enclosures
Intel® Celeron® J3455 quad-core 1.5 GHz processor (burst up to 2.3 GHz)
Intel® HD Graphics 500
FLOATING POINT UNIT
4GB DDR3L (2 x 2 GB)
8 GB (2 x 4GB)
2 x SODIMM DDR3L
When installing two memory modules, please ensure that they are the same size and ideally use the same type of RAM for both memory slots.
4GB (Dual boot OS protection)
8 x 3.5-inch
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
M.2 SSD SLOT
Optional via a PCIe adapter
SSD CACHE ACCELERATION SUPPORT
Drive bays 1 to 2
GIGABIT ETHERNET PORT (RJ45)
1 x PCIe Gen 2 x (2)
USB 3.0 PORT
USB 3.1 GEN 2 (10GBPS) PORT
Optional via a PCIe adapter
1, HDMI 1.4b
2U Rack Mount
HDD 1-8, Status, LAN, Expansion, Power
89 × 482 × 534 mm
0 - 40 °C (32°F - 104°F)
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
POWER SUPPLY UNIT
ATX 250W (x2), Input: 100V-240V ~ / 5A-2.5A, 50Hz-60Hz
POWER CONSUMPTION: HDD SLEEP MODE
POWER CONSUMPTION: OPERATING MODE, TYPICAL
With drives fully populated
2 x 70mm, 12V DC
Ethernet Cable x 2
Quick Installation Guide (QIG)
Flat head screw (for 3.5" HDD)
Flat head screw (for 2.5" HDD)
Power cord x 2
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications. Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
