QNAP TS-932X-8G 9 Bay Quad Core 8GB NAS
The business-class TS-932X is a budget-friendly NAS designed to accommodate five 3.5-inch hard drives and four 2.5-inch SSDs. It is also the first ARM-based NAS that supports Qtier™ technology for efficient auto-tiered storage. As a 9-bay NAS, the compact TS-932X takes up less desktop space compared with other models in the same class, and presents a stylish control panel embellished with brushed-metal aluminum. Featuring dual 10GbE SFP+ ports, the TS-932X provides an excellent blend of speed and affordability to future-proof your IT infrastructure for 10GbE networks.
AnnapurnaLabs Alpine AL-324 ARM® Cortex-A57 quad-core 1.7GHz processor
FLOATING POINT UNIT
8 GB SODIMM DDR4 (1 x 8GB)
16 GB (1 x 16 GB)
1 x SO-DIMM DDR4
512 MB (Dual boot OS protection)
5x 3.5-inch+ 4 x 2.5-inch
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch solid state drives
GIGABIT ETHERNET PORT (RJ45)
10 GIGABIT ETHERNET PORT
2 x 10G SFP+
USB 3.0 PORT
1 x Built-in speaker, 1 x 3.5mm line out jack
You cannot use the speakers and the line-out jack simultaneously.
System Status, LAN, USB, HDD1~5, SSD1-4
Power, Reset, USB Copy
224.7 × 182.7 × 223.6 mm
0 - 40 °C (32°F - 104°F)
5~95% RH non-condensing, wet bulb: 27?C (80.6?F)
POWER SUPPLY UNIT
External, 120 W, AC 100 to 240 V
POWER CONSUMPTION: HDD SLEEP MODE
POWER CONSUMPTION: OPERATING MODE, TYPICAL
With 5 x HDD + 4 x SSD fully populated
1 x 350px smart Fan (12V DC)
Voice prompts or Buzzer
KENSINGTON SECURITY SLOT
Ethernet Cable x 2
Power Cord x 1
Flat head screw (for 3.5" HDD)
Flat head screws (For 2.5" HDD)
Quick Installation Guide (QIG)
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications. Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
