TP-Link TL-WR940N N450 Wireless N Router

TP-Link TL-WR940N N450 Wireless N Router
  • TP-Link TL-WR940N N450 Wireless N Router
  • TP-Link TL-WR940N N450 Wireless N Router
  • TP-Link TL-WR940N N450 Wireless N Router
  • TP-Link TL-WR940N N450 Wireless N Router
$39.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched within 1-2 business days



  Stock Levels May Vary

If you’re collecting from a Umart Store, don’t forget to choose a Pick Up location to see our live stock levels!

Specifications

  • Product Name:
    TP-Link TL-WR940N N450 Wireless N Router
  • Model Number:
    TL-WR940N
  • Brand:
  • Manufacturer Warranty:
    36 Months
  • Description

    TP-Link TL-WR940N N450 Wireless N Router


    • 450Mbps wireless speed ideal for interruption sensitive applications like HD video streaming*

    • Three antennas increase the wireless robustness and stability

    • Easy wireless security encryption at a push of WPS button

    • IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC

    *450Mbps wireless speed is only for TL-WR940N V3 while the earlier version is 300Mbps.


    TP-Link TL-WR940N N450 Wireless N Router


    Specifications


    HARDWARE FEATURES

    INTERFACE

    4 10/100Mbps LAN PORTS
      1 10/100Mbps WAN PORT

    BUTTON

    Wireless On/Off Button,WPS/Reset Button,
      Power On/Off Button

    EXTERNAL POWER SUPPLY

    12VDC / 1A

    WIRELESS STANDARDS

    IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

    DIMENSIONS ( W X D X H )

    9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)

    ANTENNA

    3*5dBi Fixed Omni Directional Antenna

    WIRELESS FEATURES

    FREQUENCY

    2.4-2.4835GHz

    SIGNAL RATE

    11n: Up to 450Mbps(dynamic)
      11g: Up to 54Mbps(dynamic)
      11b: Up to 11Mbps(dynamic)

    RECEPTION SENSITIVITY

    270M: -68dBm@10% PER
      130M: -68dBm@10% PER
      108M: -68dBm@10% PER
      54M: -68dBm@10% PER
      11M: -85dBm@8% PER
      6M: -88dBm@10% PER
      1M: -90dBm@8% PER

    TRANSMIT POWER

    CE:
      <20dBm(2.4GHz)
      FCC:
      <30dBm

    WIRELESS MODES

    Router Mode,
      Range Extender(for V5 and later),
      Access Point Mode (for V5 and later)

    WIRELESS FUNCTIONS

    Enable/Disable Wireless Radio, WDS Bridge,   WMM, Wireless Statistics

    WIRELESS SECURITY

    64/128/152-bit WEP / WPA / WPA2,WPA-PSK /   WPA2-PSK

    SOFTWARE FEATURES

    QUALITY OF SERVICE

    WMM, Bandwidth Control

    WAN TYPE

    Dynamic IP/Static IP/PPPoE/
      PPTP(Dual Access)/L2TP(Dual Access)/BigPond

    MANAGEMENT

    Access Control
      Local Management
      Remote Management

    DHCP

    Server, Client, DHCP Client List,
      Address Reservation

    PORT FORWARDING

    Virtual Server,Port Triggering, UPnP, DMZ

    DYNAMIC DNS

    DynDns, Comexe, NO-IP

    VPN PASS-THROUGH

    PPTP, L2TP, IPSec (ESP Head)

    ACCESS CONTROL

    Parental Control, Local Management Control, Host   List, Access Schedule, Rule Management

    FIREWALL SECURITY

    DoS, SPI Firewall
      IP Address Filter/MAC Address Filter/Domain Filter
      IP and MAC Address Binding

    PROTOCOLS

    Support IPv4

    GUEST NETWORK

    2.4GHz Guest Network×1

    OTHERS

    CERTIFICATION

    FCC, RoHS

    PACKAGE CONTENTS

    TL-WR940N
      Power supply unit
      Resource CD
      Ethernet Cable
      Quick Installation Guide

    SYSTEM REQUIREMENTS

    Microsoft® Windows® 98SE, NT, 2000, XP,   Vista™ or Windows 7, Windows8/ 8.1/10
      MAC® OS, NetWare®, UNIX® or Linux

    ENVIRONMENT

    Operating Temperature: 0~40   (32~104)
      Storage Temperature: -40
    ~70   (-40~158)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
