Product Segment

AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps

WiFi Data Rate

WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps

WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps

Antenna

Internal Antenna x 5

Transmit / Receive

2.4GHz 2x2

5GHz 2x2

Processor

Dual-core 1.3GHz SoC

Memory

RAM 512MB / Flash 128MB

Operating Frequency

2.4 GHz

5 GHz

Operating Mode

Wireless Router Mode

AiMesh Node Mode

Range Extender Mode

Access Point Mode

Media Bridge Mode

Repeater Mode

Public WiFi Mode (WISP)

I/O Ports

1GbE WAN x 1

1GbE LAN x 1

USB-C Power Port

USB 3.2 Gen 1x1

Buttons

Reset

Slide Switch

LED Indicator

RGB x 1

Power Supply

9V / 2A

Package Content

RT-AX57 Go x 1

Power Adapter x 1

1m RJ-45 Cable x 1

Stand x 1

Flannel Bag x 1

Quick Start Guide

Warranty Card

Product Weight (g)

210g

Product Dimensions

120mm x 120mm x 21.5mm

AiMesh

AiMesh

• Primary AiMesh Router

• AiMesh Node

Game

UU Boost (CN only)

Parental Control

Time Scheduling

Safe Browsing

Guest Network

"The Guest Network provides Internet connection for guests but restricts access to your local network."

"You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings."

Support Guest Network Pro

Security

AiProtection

VPN

WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support

WPS

Let's Encrypt

DNS-over-TLS

SSH

Security Scan

Firewall

AiProtection

AiProtection Classic

• Router Security Assessment

• Malicious Site Blocking

• Infected Device Prevention and Blocking

VPN

Instant Guard

VPN Client L2TP

VPN Client Open VPN

VPN Client PPTP

VPN Client WireGuard

VPN Server IPSec

VPN Server Open VPN

VPN Server PPTP

VPN Server WireGuard

VPN Fusion

Support Surfshark

Traffic Control

Traditional QoS

• Real-time Traffic Monitor

WAN

• PPPoE

• PPTP

• L2TP

• Automatic IP

• Static IP

• IPSec

3G / 4G LTE dongle

Port forwarding

Port triggering

DMZ

DDNS

LAN

DHCP Server

IGMP Snooping

IPTV

VLAN

Wireless

MU-MIMO

UTF-8 SSID

WiFi MAC Address Filter

Wireless Scheduler

Airtime Fairness

RADIUS Client

Universal Beamforming

Explicit Beamforming

USB application

HDD Hibernation

AiCloud

Download Master

AiDisk

Media Server

Time Machine

User Interface

WEB: ASUSWRT

APP: ASUS Router APP

Administration

Feedback System

System Log

New Device Connect Notification

Smart Home

Support Google Assistant
