• Supports New Intel® Core i7 Processor Extreme Edition for LGA2011-3 Socket.
     Please refer to CPU Support for compatible CPU; the above description is for reference only.

• Intel® X99 Express Chipset

• Support eight DDR4 DIMMs 2133/2200(OC)/2400(OC)/2600(OC)/2666(OC)/2750(OC)/  3000(OC)/3110(OC)/3333(OC) MHz, up to 128GB Max.
     -Supports Quad-Channel mode
     -Supports non-ECC, un-buffered memory
     -Supports Intel® Extreme Memory Profile (XMP)

• 4 x PCIe 3.0 x16 slots, support up to 3-way mode
     -1-way mode: x16/ x0/ x0/ x0
     -2-way mode: x16/ x16/ x0/ x0*, 16/ x8/ x0/ x0**
     -3-way mode: x16/ x16/ x0/ x8*, x8/ x8/ x8/ x0**


• 2 x PCIe 2.0 x1 slots

* For the CPU that supports 40 PCIe lanes
     ** For the CPU that supports 28 PCIe lanes

• Supports 3-Way NVIDIA® SLI Technology


• Supports 3-Way AMD® CrossFire Technology*
     * Supports Windows 7 and Windows 8/ 8.1

• Intel® X99 Express Chipset

• 10 x SATA 6Gb/s ports (2x ports reserved for SATA Express port)*

-SATA1~6 support RAID 0, RAID 1, RAID 5 and RAID 10

-SATA7~10 ports only support IDE mode and AHCI mode.

-Supports Intel® Smart Response Technology (Windows 7/ 8/ 8.1)

• 1 x SATA Express port*

• 1 x M.2 port, supports M.2 SATA 6Gb/s module* or M.2 PCIe module up to 32Gb/s speed**
       -M.2 port supports 4.2cm/ 6cm/ 8cm length module
       -M.2 PCIe module does not support RAID 0, RAID1, RAID 5 and RAID 10.


* The SATA Express port or SATA5~6 ports will be unavailable when installing the M.2 (Gen2 x2 mode) module in the M.2 port.

** Intel RST does not support PCIe M.2 SSD with Legacy ROM.

• Intel X99 Express Chipset

-6 x USB 3.0 ports (2 ports on the back panel, 4 ports available through the internal USB 3.0 connectors*)

-6 x USB 2.0 ports (2 ports on the back panel, 4 ports available through the internal USB 2.0 connectors)


• ASMedia ASM1142

-2 x USB 3.1 ports on the back panel

• VIA VL805

-4 x USB 3.0 ports on the back panel

* Internal JUSB1 connector supports MSI Super Charger.

• Realtek® ALC892 Codec

-7.1-Channel High Definition Audio

-Supports S/PDIF output

• 1 x Intel I218 Gigabit LAN

1 x 24-pin AT x main power connector

-1 x 8-pin AT x 12V power connector

-10 x SATA 6Gb/s connectors

-1 x SATA E xpress connector

-1 x M.2 connector

-2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

-2 x USB 3.0 connectors (supports additional 4 USB 3.0 ports)

-2 x 4-pin CPU fan connectors

-3 x 4-pin system fan connectors

-1 x Front panel audio connector

-2 x System panel connectors

-1 x TPM module connector

-1 x Chassis Intrusion connector

-1 x Clear CMOS jumper

-1 x Slow mode booting jumper

-1 x Power button

-1 x Reset button

-1 x OC Genie button

-1 x Multi-BIOS switch

1 x PS/2 keyboard/ mouse combo port

-2 x USB 2.0 ports

-1 x Clear CMOS button

-6 x USB 3.0 ports

-2 x USB 3.1 ports

-1 x LAN (RJ45) port

-1 x Optical S/PDIF OUT connector

-5 x OFC audio jacks

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.


• The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.

• 9 mounting holes
