Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard

Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard
  • Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard
  • Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard
  • Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard
$269.0
Was: $369.0 WAS Tips   Save $100.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Free Click & Collect  Question Mark

Your store is set to:

Loading...

   Fast Delivery  Question Mark

Order within 19hrs and 53mins
for Monday Dispatch

Question Mark

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Click & Collect.

Specifications

  • Product Name:
    Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard
  • Model Number:
    TUF GAMING Z490-PLUS
  • Brand:
  • Manufacturer Warranty:
    3 Year
  • Description

     Asus TUF Gaming Z490-Plus LGA 1200 ATX Motherboard

    Intel® LGA 1200 socket: Ready for 10th Gen Intel® Core™ processors

    Enhanced power solution: 12+2 DrMOS power stages, 6-layer PCB, ProCool sockets, military-grade TUF components, and Digi+ VRM for maximum durability

    Comprehensive cooling: VRM heatsink, PCH fanless heatsink, M.2 heatsink, hybrid fan headers and Fan Xpert 4 utility

    Next-gen connectivity: Front header for USB 3.2 Gen 2 Type-C and Thunderbolt 3™ support

    Made for online gaming: Intel® Ethernet Connection I219-V, TUF LANGuard and TurboLAN technology

    Realtek S1200A codec: Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in

    Aura Sync RGB: Synchronizable LED effects across a vast portfolio of compatible PC gear, including addressable RGB strips

    SPECIFICATIONS:

    Chipset



    Intel® Z490

    Memory

    4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4500(O.C)/4400(O.C)/

    4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/

    3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200(O.C.)/

    3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered   Memory

    Dual Channel Memory Architecture

    Supports Intel® Extreme Memory Profile (XMP)

    OptiMem II

    * 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133   natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors   Lists).

    Graphic

    Integrated Graphics Processor

    1 x DisplayPort 1.4 **

    1 x HDMI 1.4b

    *Graphics specifications may vary between CPU types.

    **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz.   Please refer to www.intel.com for any update.

    Multi-GPU Support

    Supports AMD 2-Way CrossFireX Technology

    Exapnsion Slots

    Intel® 10th Gen Processors

    1 x PCIe 3.0 x16 (x16 mode)

    Intel® Z490 Chipset

    1 x PCIe 3.0 x16 (x4 mode)

    3 x PCIe x1

    Storage

    Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports

    Intel® Z490 Chipset :

    1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage   devices support (SATA & PCIE 3.0 x 4 mode)*1

    1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices   support (SATA & PCIE 3.0 x 4 mode)*2

    6 x SATA 6Gb/s port(s)

    Support Raid 0, 1, 5, 10

    Intel® Rapid Storage Technology supports

    Intel® Optane™ Memory Ready

    LAN

    Intel® I219-V 1Gb Ethernet

    TUF LANGuard

    Audio

    Realtek® ALC S1200A 7.1 Surround Sound High Definition Audio CODEC

    - Supports : Jack-detection, Multi-streaming, Front Panel   Jack-retasking, up to 24-Bit/192kHz playback

    Audio Feature :

    - Optical S/PDIF out port(s) at back panel

    - Audio cover

    - Audio Shielding

    - Dedicated audio PCB layers

    - Premium Japanese audio capacitors

    * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported   for 8-Channel audio.

    USB Ports

    Rear USB Port ( Total 6 )

    2 x USB 3.2 Gen 2 port(s)(1 + Type-A +1 + USB Type-C®)

    4 x USB 3.2 Gen 1 port(s)(4 x Type-A)

    Front USB Port ( Total 6 )

    1 x USB 3.2 Gen 2 front panel connector port(s)(1 x USB Type-C®)

    1 x USB 3.2 Gen 1 port(s)(2 x Type-A)

    1 x USB 2.0 port(s)(2 x Type-A)

    1 x USB 2.0 port(s)(1 x Type-A)

    Special Features



    ASUS TUF PROTECTION

    - ASUS DIGI+ VRM (- Digital power design with Dr. MOS)

    - ASUS Enhanced DRAM Overcurrent Protection

    - ASUS ESD Guards

    - TUF LANGuard

    - ASUS Overvoltage Protection

    - ASUS SafeSlot

    - ASUS Stainless-Steel Back I/O

    ASUS Q-Design

    - ASUS Q-DIMM

    - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device   [yellow green])

    - ASUS Q-Slot

    ASUS Thermal Solution

    - Stylish heatsink

    ASUS EZ DIY

    - Procool

    AURA Sync

    - Standard RGB headers

    - Addressable Gen 2 RGB header

    Software Features

    ASUS TUF PROTECTION

    - ASUS DIGI+ VRM (- Digital power design with Dr. MOS)

    - ASUS Enhanced DRAM Overcurrent Protection

    - ASUS ESD Guards

    - TUF LANGuard

    - ASUS Overvoltage Protection

    - ASUS SafeSlot

    - ASUS Stainless-Steel Back I/O

    ASUS Q-Design

    - ASUS Q-DIMM

    - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device   [yellow green])

    - ASUS Q-Slot

    ASUS Thermal Solution

    - Stylish heatsink

    ASUS EZ DIY

    - Procool

    AURA Sync

    - Standard RGB headers

    - Addressable Gen 2 RGB header

    Back I/O Ports

    1 x PS/2 keyboard/mouse combo port(s)

    1 x DisplayPort

    1 x HDMI

    1 x LAN (RJ45) port(s)

    2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®)

    4 x USB 3.2 Gen 1 (blue) Type-A

    1 x Optical S/PDIF out

    5 x Audio jack(s)

    Internal I/O Ports

    1 x CPU Fan connector(s)

    1 x CPU OPT Fan connector(s)

    3 x Chassis Fan connector(s)

    1 x AIO_PUMP connector

    2 x Aura RGB Strip Headers

    1 x Addressable Gen 2 header(s)

    1 x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin,   Type-C)

    1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2   USB 3.2 Gen 1 port(s)

    1 x USB 2.0 connector(s) support(s) additional 1 USB 2.0 port(s)

    2 x M.2 Socket 3

    6 x SATA 6Gb/s connector(s)

    1 x Thunderbolt header(s)

    1 x 24-pin EATX Power connector(s)

    1 x 8-pin ATX 12V Power connector(s)

    1 x 4-pin ATX 12V Power connector(s)

    1 x Front panel audio connector(s) (AAFP)

    1 x System panel(s) (Chassis intrusion header is inbuilt)

    1 x Clear CMOS jumper(s)

    1 x COM port header



    Accessories

    User's manual

    1 x ASUS Fan Holder

    I/O Shield

    2 x SATA 6Gb/s cable(s)

    1 x M.2 Screw Package

    1 x Supporting DVD

    1 x TUF GAMING Sticker

    1 x TUF Certification card(s)

    BIOS

    192 (128+64) Mb Flash ROM, UEFI AMI BIOS

    Manageability

    WOL by PME, PXE

    OS

    Windows® 10 64-bit

    Form Factor

    ATX Form Factor

    12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
