Supported Operating Systems

Windows 11, 64-bit*, Windows 10, 64-bit (not included)

Board Number

NUC12EDBi7

Board Form Factor

PCIe

Internal Drive Form Factor

M.2 SSD

# of Internal Drives Supported

3

Lithography

Intel 7

TDP

65 W

Board Chipset

Intel® Z690 Chipset

Processor Included

Intel® Core™ i7-12700 Processor (25M Cache, up to 4.90 GHz)

Intel vPro® Platform Eligibility

No

# of Cores

12

# of Threads

20

Max Turbo Frequency

4.90 GHz

MEMORY & STORAGE

Max Memory Size (dependent on memory type)

64 GB

Memory Types

DDR4 3200MHz 1.2V SO-DIMM

DDR4 3200 MHz 1.35V SO-DIMM - XMP is required to enable 1.35V memory

Max # of Memory Channels

2

Max Memory Bandwidth

51.2 GB/s

Max # of DIMMs

2

ECC Memory Supported

No

PROCESSOR GRAPHICS

Integrated Graphics

Yes

Graphics Output

2x Thunderbolt 4, HDMI 2.0b

# of Displays Supported

3

Discrete Graphics

Via PCIe add-in card

EXPANSION OPTIONS

PCI Express Revision

Gen5, Gen4

PCI Express Configurations

2x M.2 PCIe X4 Gen4 slots (PCH), M.2 PCIe X4 Gen4 slots (CPU);   Double-wide PCIe X16 Gen5 (CPU) slot, 12" max card length

Removable Memory Card Slot

SDXC with UHS-II support

M.2 Card Slot (wireless)

Intel® Wi-Fi 6E AX211

M.2 Card Slot (storage)

2x via PCH + 1x via CPU (NVMe)

CHASSIS FEATURES AND SIZE

Chassis Dimensions

357 x 189 x 120mm

I/O SPECIFICATIONS

# of USB Ports

11

USB Configuration

6x rear USB 3.1g2, 2x Thunderbolt 4 (USB 3.1g2), 2x front USB 3.1g2,   1x USB 2.0 via internal header

USB Revision

3.1 Gen2, 2.0

USB 2.0 Configuration (External + Internal)

2x int.

Total # of SATA Ports

2

Max # of SATA 6.0 Gb/s Ports

2

RAID Configuration

2x M.2 SATA/PCIe SSD (RAID-0 RAID-1)

Audio (back channel + front channel)

7.1 digital; L+R+mic (F)

Integrated LAN

10GbE (AQC113)

Integrated Wireless

Intel® Wi-Fi 6E AX211(Gig+)

Integrated Bluetooth

Yes

Additional Headers

2x USB2.0, FRONT_PANEL

# of Thunderbolt™ Ports

2x Thunderbolt™ 4

ADVANCED TECHNOLOGIES

Intel® Optane™ Memory Supported

Yes

Intel® Virtualization Technology for Directed I/O (VT-d)

Yes

Intel vPro® Platform Eligibility

No

Intel® Rapid Storage Technology

Yes

Intel® Virtualization Technology (VT-x)

Yes

Intel® Platform Trust Technology (Intel® PTT)

Yes

SECURITY & RELIABILITY

Intel® AES New Instructions

Yes
