Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White

Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White
  • Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White
  • Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White
  • Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White
$169.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Add to Wishlist

   Free Pick Up

Your store is set to:

Loading...

   Fast Delivery

Dispatched in 1-3 Days excluding Weekends

  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!

Specifications

  • Product Name:
    Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White
  • Model Number:
    MCB-D500D-WGNN-S01
  • Brand:
  • Manufacturer Warranty:
    2 Year
  • Description

    Cooler Master MasterBox TD500 Mesh Mid Tower E-ATX Case - White
    SPECIFICATIONS:

    Model   Number

    MCB-D500D-KGNN-S01

    Series

    MasterBox Series

    Size

    Mid Tower

    Available   Colours

    White

    Materials

    Steel, Plastic, Tempered Glass, Mesh

    Dimensions   (L X W X H)

    493 x 217 x 469mm (incl. Protrusions), 429.5 x   205x 447mm (excl. Protrusions)

    Weight

    6.95 kg

    Motherboard   Support

    Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*,   (*support for up to 12" x 10.7", will limit cable management   features)

    Expansion   Slots

    7

    5.25”   Drive Bays

    N/A

    2.5”/3.5”   Drive Bays(Combo)

    2

    2.5”   Drive Bays



    4 (2+2 combo)

    I/O   Panel



    2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm   Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Controller (only for the S01   versions), 1x ARGB 2-to-3 splitter

    Pre-installed   Fans- Top



    N/A

    Pre-installed   Fans—Front



    3x 120mm ARGB Fans

    Pre-installed   Fans- Reat



    N/A

    Fan   support- Top

    3x 120mm, 2x 140mm

    Fan   support- Front



    3x 120mm, 2x 140mm

    Fan   support- rear



    1x 120mm

    Radiator   Support- Top



    120mm, 240mm, 360mm, (44mm max motherboard   component height)

    Radiator   Support- Front



    120mm, 140mm, 240mm, 280mm, 360mm

    Radiator   Support- Rear

    120mm

    Clearance   – CPU Cooler



    165mm/6.49"

    Clearance-   PSU



    180mm/7.08", 295mm/11.61" (w/ HDD cage   removed)

    Clearance-   GFX

    410mm/16.1"

    Cable   Routing



    19mm/0.74"

    Dust Filters



    Top, Bottom, Front

    Power   Supply Support



    Bottom mount, ATX

    Warranty

    2 years
