Sophisticated Routing Features
Advanced Security, Monitoring, and Management
High-Performance Gigabit Ports
Specifications
Dimensions 110 x 75 x 22 mm (4.33 x 2.95 x 0.87")
Weight 175 g (6.17 oz)
Max. Power Consumption 5W
Power Input 12VDC, 0.5A Power Adapter (Included) or 24V Passive PoE
Power Supply External AC/DC Adapter
Supported Voltage Range 9 to 26VDC
Buttons Reset
LEDs Power, Ethernet 0-4
Processor Dual-Core 880 MHz, MIPS1004Kc
Memory 256 MB DDR3 RAM
Code Storage 256 MB NAND
Certifications CE, FCC, IC
Wall Mount Yes
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 to 90% Noncondensing
NETWORKING INTERFACES
Data/PoE Input Port (1) 10/100/1000 RJ45 Port
Data Port (3) 10/100/1000 RJ45 Ports
Data/PoE Passthrough Port (1) 10/100/1000 RJ45 Port
* Specifications are subject to change without notice.
* Specifications may vary.
* The product picture(s) is only for your reference, it may differ from the actual product.
