Specifications

  • Product Name:
    be quiet! 850W Pure Power 13 M 80+ Gold PCIe 5.1 ATX 3.1 Power Supply (BP027AU)
  • Model Number:
    BP027AU
  • Brand:
  • Warranty Period:
    10 Year

Description

Power-Supply-PSU-be-quiet-850W-Pure-Power-13-M-80-Gold-PCIe-5-1-ATX-3-1-Power-Supply-BP027AU-1



SPECIFICATIONS:

GENERAL DATA


Model

Pure Power 13 M | 850W

Continuous power (W)

850

Peak power (W)

900

Form factor

Version 3.1

Form factor EPS 12V

Version 2.92

Topology

LLC + SR + DC/DC

Voltage (Vac)

100 - 240

Frequency (Hz)

50 - 60

Input current (A)

12 / 6

Power factor at 100% load

>0.98

Modern standby

✓

Power consumption in standby (W)

<0.1

Average life time (h / 25°C)

>100,000

Operating temperature up to (°C)

40

EFFICIENCY


80 PLUS certification

Gold

Efficiency (%) at 230V, 2% load

70.5

Efficiency (%) at 230V, 10% load

90.0

Efficiency (%) at 230V, 20% load

93.2

Efficiency (%) at 230V, 50% load

94.4

Efficiency (%) at 230V, 100% load

92.8

FAN AND COOLING TECHNOLOGY


Fan

Silence-optimized be quiet! fan

Fan size (mm)

120

Bearing technology

Rifle

Motor technology

4-pole fan motor

Max. fan speed (rpm)

2000

dB(A) at 20% load

12.9

dB(A) at 50% load

13.2

dB(A) at 100% load

30.2

OUTPUT


12V single rail operation

✓

+3.3V (A)

22

+5V (A)

22

+12V1 (A)

70.9

+12V2 (A)

N/A

+12V3 (A)

N/A

+12V4 (A)

N/A

+12V5 (A)

N/A

+12V6 (A)

N/A

-12V (A)

0,3

+5Vsb (A)

3

Max. combined power 12V (W)

850

Max. combined power 12V-2x6 (W)

600

Max. combined power 3.3V + 5V (W)

120

Hold-up time at 100% load (ms)

25.09

Hold-up time at 80% load (ms)

33.38

Power good signal (ms)

100 - 150

CABLES AND CONNECTORS


Modular cables

✓

Sleeved cables

✓

Flat cables

✓

Maximum cable length (cm)

95

Cable length to motherboard (cm)

55

No. of cables

8

ATX-Motherboard (20+4-pin)

1

P4+4 (CPU)

1

P8 (CPU)

1

12V-2x6 cables

1

PCI-e 6+2-pin (GPU)

4

SATA

6

PATA

2

PROTECTION


OTP (over temperature protection)

✓

OCP (over current protection)

✓

OPP (over power protection)

✓

SCP (short circuit protection)

✓

OVP (over Voltage protection)

✓

UVP (under Voltage protection)

✓

SIP (Surge & Inrush   protection)

✓

SAFETY CERTIFICATION


BSMI

✓

CB

✓

CCC

✓

CE

✓

cTUVus

✓

CU

✓

FCC

✓

RCM

✓

TÜV

✓

UKCA

✓

ENVIRONMENTAL DIRECTIVES


Energy Star

8.0

ErP

✓

WEEE

✓

RoHS

✓

SCOPE OF DELIVERY


Screws

✓

Cable ties

✓

User manual languages

CN, DE, EN, ES, FR, JP, PL, RU, TW

CASING


Dimensions without cable (L x W x H), (mm)

160 x 150 x 86

Weight (kg)

2.62

Color

Black
