Display |
|
Projection System | DLP |
Native Resolution | 720p (1280 x 720 pixels) |
Native Aspect Ratio | Native 16:9 (5 aspect ratio selectable) |
Brightness (ANSI luments) | 500 ANSI Lumen (About 1200 LED lumens & 8300 Light Source Lumens) |
DMD type | 0.3" |
Contrast Ratio (FOFO) | 100,000:1 |
Display Colour | 1.07 billion colours |
Light Source | Osram Q8A LED |
Light Source Life | 20,000/30,000 hrs (Normal/ Eco) |
Optical |
|
Throw Ratio | 1.3 (80"@2.3m) |
Zoom Ratio | Fixed |
Lens | Auto Focus |
Projection Offset（Full-Height） | 100% ± 5% |
Keystone Adjustment | 1D, Vertical +/- 40 degrees |
Projection Size (Clear Focus / Maximum) | 30"~100" |
Compatibility |
|
Resolution Support | VGA(640 x 480) to Full HD(1920 x 1080) |
HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
Video Compatibility | NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM / HDTV |
Horizontal Frequency | 15~ 102KHz |
Vertical Scan Rate | 23~85Hz |
Audio |
|
Speaker | 2W x 2 |
OSD |
|
OSD Language | English/ French/ German/ Japanese/ Korean/ Portuguese/ Simplified Chinese/ Spanish/ Traditional Chinese (9 Languages) |
Dimension and Weight |
|
Dimensions (W x H x D) (mm) | 139 x 144 x 139 |
Net Weight (kg) | 1.6 KG |
SoC |
|
IC | MStar 648 |
OS | Android 6.0 |
RAM | 2G LPDDR3 |
Flash | 8G EMMC |
Internet |
|
WLAN | IEEE 802.11 a/b/g/n/ac, 2.4G/5G |
Antenna | Yes |
Interface |
|
HDMI (1.4a) / HDCP (1.4) | X1 |
USB 2.0 (Type A) | X1 |
Audio Out | X1 (3.5mm) |
USB Type-C | X1 |
Light Sensor | Yes |
Wireless |
|
WiFi | IEEE 802.11 a/b/g/n/ac, 2.4G/5G |
Bluetooth | 4.0 |
Special Feature |
|
LumiExpert | Yes |
Feature | IPX2, Parental Timer, LumiExpert, Wireless Projection* (for iOS/macOS, for AndroidTM, for PC), USB-C DisplayPort and Reader, 15∘Tiling Lens, Auto Focus, Auto Keystone, 3 Hours Battery |
Power |
|
Typical Power Consumption | 65W / 42W / 30W (Max / Normal / Eco) |
Standby Power Consumption | 0.5W Max. at 100 ~ 240VAC |
Power Supply | VAC 100 ~ 240 (50/60Hz) |
Operation Condition |
|
Noise Level (Normal/Eco) | 31/29 dBA |
Operating Temperature | 0~40℃ |
