BASIC SPECS |
|
Scanning Speed | 40 ppm |
Document Size - Multiple Sheets - Width | 50.8 mm to 215.9 mm |
Document Size - Multiple Sheets - Length | 50.8 mm to 355.6 mm |
Document Size - Single Sheet - Width | 50.8 mm to 215.9 mm |
Colour / Monochrome | Yes / Yes |
2-Sided (Duplex) Scan | Yes |
Colour Depth - Input | 48-bit colour processing |
Colour Depth - Output | 24-bit colour processing |
Resolution - Optical | Up to 600 dpi Ă— 600 dpi |
Resolution - Interpolated | Up to 1,200 dpi Ă— 1,200 dpi |
Document Scanning Width / Length | Up to 215.9 mm |
Product Dimensions (Width X Depth X Height) | 300 mm Ă— 216 mm Ă— 191 mm |
Weight | 2.7 kg |
ADF (Automatic Document Feeder) | Up to 60 sheets (Paper: 20 lb (80 g/m²) A4/Letter size) |
Memory Capacity | 512 MB |
What's in The Box | Scanner, Quick Setup Guide, User's Guide, Network Guide, CD-ROM's, ADF Document Output Support, AC Adaptor, USB Cable |
CONNECTIVITY |
|
Connectivity | Ethernet 10Base-T/100Base-TX, Wireless LAN IEEE 802.11 b/g/n (Infrastructure Mode), IEEE 802.11 g/n (Wi-Fi Direct), Super Speed USB 3.0, IEEE 802.11 g (Wi-Fi Direct) |
NETWORK |
|
Wireless Network Security | WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3 |
Setup Support Utility | WPS WLAN Assistant |
DISPLAY TYPE |
|
Touchscreen LCD | 2.8 in. (71.1mm) TFT colour LCD screen |
OPERATION |
|
Power Source | AC: 100-240 V, 50/60 Hz |
Power Consumption - Scanning | Approx. 25W |
Power Consumption - Ready | Approx. 7.3W |
Power Consumption - Power Saving / Deep Sleep | Approx. 1.7W |
Power Consumption - Power OFF | Approx. 0.1W |
Temperature Operating | 5°C to 35°C |
Humidity - Operating | 20% to 80% |
Humidity - Storage | 10% to 90% |
COMPLIANCE |
|
TWAIN Compliant - Windows® | Windows Server 2016 / Windows Server 2019 / Windows Server 2022 |
TWAIN Compliant - Macintosh | macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x |
WIA Compliant - Windows® | Windows 10 / Windows 11 |
ICA Compliant - Macintosh | macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x |
ISIS™ Compliant - Windows® | Windows 10 / Windows 11 |
