TECHNICAL INFORMATION |
|
Diagonal Viewing Size | 23.8" |
Preset Display Area (H x V) | 527.04 mm x 296.46 mm (20.75" x 11.67")
Area: 156,246.28 mm2 (242.18 inches2) |
Panel Type | In-Plane Switching (IPS) technology |
Display Screen Coating | Anti-glare with 3H hardness |
Maximum Preset Resolution | 1920 x 1080 |
Refresh rate | 100 Hz |
Viewing Angle | 178° vertical / 178° horizontal |
Pixel Pitch | 0.2745 mm x 0.2745 mm |
Pixel Per Inch (PPI) | 92.53 |
Contrast Ratio | 1,500: 1 (typical) |
Aspect Ratio | 16:9 |
Backlight Technology | LED edgelight system |
Brightness | 250 cd/m2 (typical) |
Response Time | 5ms gray-to-gray (Fast mode) 8ms gray-to-gray (Normal mode) |
Colour Support | Up to 16.7 million colours |
Colour Gamut | 99% sRGB |
TÃœV Eye Comfort | Yes, 4-Star |
Ficker Free | Yes |
Connectivity | 1x HDMI 1.4 (HDCP 1.4) (Supports up to FHD 1920 x 1080 100Hz TMDS as per specified in HDMI 1.4) 1x DP 1.2 (HDCP 1.4) 1x VGA 1x USB 3.2 Gen1 Type-B upstream 3x USB 3.2 Gen1 Type-A downstream 1x USB 3.2 Gen1 Type-C downstream with up to 15W PD (data only) |
Built-in Speaker | No |
USB Power Delivery | Yes, up to 15W via USB-C downstream port |
Adjustability | Height, Tilt, Swivel, Pivot |
Height | Up to 150 mm (5.9") |
Tilt | -5°/+21° |
Swivel | -45°/+45° |
Pivot | -90°/+90° |
Dell Display Manager Compatibility | Yes with Easy Arrange |
Remote Asset Management | Yes |
Voltage Required | 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typ) |
Power Consumption (Operational) (typical) | 0.3 W (Off mode) 0.3 W (Standby mode) 11.7 W (On mode) 65 W (Max) 12.0 W (Pon) 38.4 kWh (TEC) |
Audio Output | Optional soundbar (sold separately) |
Security | Security-lock slot (based on Kensington Security Slotâ„¢) |
Compliant Standards | ENERGY STAR certified monitor EPEAT GOLD EPEAT Climate+ TCO Certified Displays TCO Certified Edge RoHS-compliant BFR / PVC free monitor (excluding external cables) Arsenic-free glass and mercury-free (panel only) |
Flat Panel Mount Interface | VESA (100 mm x 100mm) |
Temperature Range | Operating: 0°C ~ 40°C (32°F ~ 104°F) Non-operating: -20° ~ 60°C (-4° ~ 140°F) |
Humidity Range | Operating: 10% ~ 80% (non-condensing) Non-operating: 5% ~ 90% (non-condensing) |
Altitude | Operating: 5,000 m (16,404 ft) max Non-operating: 12,192 m (40,000 ft) max |
What's Included | 1x Monitor panel 1x Stand riser and base 1x Quick setup guide 1x Safety, Environmental, and Regulatory Information |
Cables Included | 1x Power cord 1x DP-to-DP cable, 1.8m 1x USB 3.2 Gen1 Type A-to-B (upstream) cable, 1.8m |
PHYSICAL CHARACTERISTICS |
|
Height with stand (Compressed ~ Extended) | 364.00 mm ~ 496.53 mm |
Width with stand | 538.64 mm |
Depth with stand | 181.75 mm |
Height without stand | 314.23 mm |
Width without stand | 538.64 mm |
Depth without stand | 50.03 mm |
Weight (panel only - for VESA mount) | 3.12 kg |
Weight (with packaging) | 6.78 kg |
