TECHNICAL INFORMATION |
|
Number of Screens | 1 |
Screen Size Class | 24" |
Viewable Screen Size | 23.8" |
Screen Mode | Full HD |
Display Screen Type | Flat Panel |
Panel Technology | In-plane Switching (IPS) Technology |
Response Time Details | 5 ms GTG (Fast) 8 ms GTG |
Aspect Ratio | 16:9 |
Pixel Pitch | 0.27450 mm x 0.27450 mm |
Horizontal Viewing Angle | 178° |
Vertical Viewing Angle | 178° |
Mount Type | Panel Mount |
HDCP Supported | Yes |
Maximum Adjustable Height | 130 mm |
Tilt Angle | -5° to 21° |
Swivel Angle | -173° to 173° |
Pivot Angle | +/-90° |
Features | Anti-glare Arsenic-free Glass BFR Free Cable Lock Slot Eye Comfort Technology Flicker-free Low Blue Light Mercury-free PVC Free Security Lock |
Adjustable Stand | Yes |
Stand Adjustments | Height Pivot Slant Swivel Tilt |
Stand Included | Yes |
Stand Type | Adjustable |
Pivot | Yes |
Curved Screen | No |
Glass Hardness | 3H |
Surface Treatment | Anti-glare |
Flicker Free | Yes |
VIDEO |
|
Maximum Resolution | 1920 x 1080 |
Standard Refresh Rate | 120 Hz |
Colour Supported | 16.7 Million Colours |
Colour Depth | 8-bit (6-bit + FRC) |
Native Contrast Ratio | 1,000:1 |
Brightness | 300 cd/m² |
Color Gamut | 72% NTSC (CIE 1931) |
Calibration Accuracy | No |
Maximum Preset Resolution | 1920 x 1080 at 120 Hz |
Pixel Per Inch (PPI) | 93 |
Resolution Type | Standard |
AUDIO |
|
Number of Speakers | 2 |
Speakers | Yes |
Speaker Output Power | 2 x 2 W |
INTERFACES/PORTS |
|
Network (RJ-45) | No |
HDMI | Yes |
HDMI Version | 1.4 |
USB | No |
VGA | Yes |
DisplayPort | Yes |
Thunderbolt | No |
USB Type-C | No |
Number of HDMI Inputs | 1 |
Total Number of HDMI Ports | 1 |
Number of DisplayPorts | 1 |
Number of VGA Ports | 1 |
Number of DisplayPort 1.4 (HDCP 1.4) | 1 |
Audio Line In | No |
DVI-D | No |
Audio Line Out | No |
DisplayPort Input | Yes |
DisplayPort Output | No |
Number of HDMI 1.4 (HDCP 1.4) | 1 |
USB Type-B | No |
DisplayPort HDCP Version | HDCP 1.4 |
HDMI HDCP Version | HDCP 1.4 |
RS-232 (Rear) | No |
Thunderbolt Downstream (Rear) | No |
USB Type-A (Front) | No |
USB Type-A (Rear) | No |
USB Type-C (Front) | No |
USB Type-C (Power Delivery) Upstream Supported (Rear) | No |
USB Type-C (Without Power Delivery) Upstream Supported (Rear) | No |
Interface/Port Details | 1 HDMI port (HDCP 1.4) (Supports up to 1920 x 1080, 120 Hz as specified in HDMI 1.4) 1 DisplayPort 1.4 (HDCP 1.4) port 1 VGA port |
BUILT-IN DEVICES |
|
Webcam | No |
Microphone | No |
ENVIRONMENTAL CONDITIONS |
|
Operating Temperature Range | 0°C to 40°C |
Non-operating Temperature Range | -20°C to 60°C |
Operating Humidity Range | 10% to 80% (Non-condensing) |
Non-operating Humidity Range | 5% to 90% (Non-condensing) |
Maximum Operating Altitude | 5 km |
Maximum Non-operating Altitude | 12.19 km |
POWER DESCRIPTION |
|
Input Voltage Range | 100V AC to 240V AC |
Operating Power Consumption | 11.80 W |
Standby Power Consumption | 300 mW |
Off-Mode Power Consumption | 300 mW |
Frequency | 50 Hz 60 Hz |
Maximum Power Consumption | 35 W |
Voltage Current | 700 mA |
Input Voltage Range/Current Details | 100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/0.7 A |
PHYSICAL CHARACTERISTICS |
|
VESA Mount Compatible | Yes |
VESA Mount Standard | 100 x 100 |
Color Family | Black |
Product Color | Black |
Height | 315.6 mm |
Width | 538.6 mm |
Depth | 55.9 mm |
Height with Stand | 485.89 mm |
Width with Stand | 538.64 mm |
Depth with Stand | 211.60 mm |
Compressed Height with Stand | 355.89 mm |
Extended Height with Stand | 485.89 mm |
Bezel Width (Top) | 5.80 mm |
Bezel Width (Bottom) | 13.30 mm |
Bezel Width (Left) | 5.80 mm |
Bezel Width (Right) | 5.80 mm |
Weight (Approximate) | 2.45 kg |
Stand Height | 400.04 mm |
Stand Width | 257.02 mm |
Stand Depth | 211.60 mm |
Weight with Stand & Cables (Approximate) | 4.19 kg |
MISCELLANEOUS |
|
Package Contents | Pro 24 Adjustable Stand Monitor - E2426HS Stand 1 x HDMI cable (1.8 m) for regions outside North America and LATAM 1 x Power cable 1.80 m for other regions QR Card Safety, Environmental, and Regulatory Information |
Certifications & Standards | California CEC BFR/PVC reduce monitor (Circuit boards are made from BFR/PVC-free laminates) Arsenic-Free glass and Mercury-Free for the panel only Meets NFPA 99 leakage current requirements. Dell Regulatory Compliance Homepage Dell and the Environment GS Mark |
Platform Supported | ThinOS Windows |
Energy Star | Yes |
TAA Compliant | No |
TCO Certified | Yes |
Eye Comfort Certification | Yes |
Eye Comfort Rating | 3 Star |
Dell Display and Peripheral Manager Compatibility | Yes |
Remote Asset Management | Dell Display and Peripheral Manager (DDPM) |
Cable Type Included | 1 x HDMI cable (1.8 m) for regions outside North America and LATAM 1 x Power cable: 2.40 m for ANZ; 1.80 m for other regions |
Environmentally Friendly | Yes |
Environmental Certification | China Environmental United Certification Center (CEC) Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) TCO Certified 10.0 TCO Certified Edge |
Energy Efficiency Certification | China Energy Conservation Program (CECP) ENERGY STAR 8.0 |
Energy Efficiency Compliance | Energy-related Products Directive (ErP) Energy-related Products Directive Lot 5 (ErP Lot 5) Korea E-Standby Minimum Energy Performance Standards (MEPS) |
Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) Eurasian Economic Union Restriction of Hazardous Substances (EAEU RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Restriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) |
