TECHNICAL INFORMATION |
|
Number of Screens | 1 |
Screen Size Class | 24" |
Viewable Screen Size | 23.8" |
Screen Mode | Full HD |
Display Screen Type | Flat Panel |
Panel Technology | In-plane Switching (IPS) Technology |
Response Time Details | 5 ms GTG (Fast) 8 ms GTG |
Aspect Ratio | 16:9 |
Pixel Pitch | 0.27450 mm x 0.27450 mm |
Horizontal Viewing Angle | 178° |
Vertical Viewing Angle | 178° |
Mount Type | Panel Mount |
HDCP Supported | Yes |
Tilt Angle | -5° to 21° |
Features | Anti-glare Arsenic-free Glass BFR Free Cable Lock Slot Eye Comfort Technology Flicker-free Low Blue Light Mercury-free PVC Free Security Lock |
Adjustable Stand | Yes |
Stand Adjustments | Tilt |
Stand Included | Yes |
Stand Type | Fixed |
Pivot | No |
Curved Screen | No |
Glass Hardness | 3H |
Surface Treatment | Anti-glare |
Flicker Free | Yes |
VIDEO |
|
Maximum Resolution | 1920 x 1080 |
Standard Refresh Rate | 120 Hz |
Colour Supported | 16.7 Million Colours |
Colour Depth | 8-bit (6-bit + FRC) |
Native Contrast Ratio | 1,000:1 |
Brightness | 300 cd/m² |
Color Gamut | 72% NTSC (CIE 1931) |
Calibration Accuracy | No |
Maximum Preset Resolution | 1920 x 1080 at 120 Hz |
Pixel Per Inch (PPI) | 93 |
INTERFACES/PORTS |
|
Network (RJ-45) | No |
HDMI | Yes |
HDMI Version | 1.4 |
USB | No |
VGA | Yes |
DisplayPort | Yes |
Thunderbolt | No |
USB Type-C | No |
Number of HDMI Inputs | 1 |
Total Number of HDMI Ports | 1 |
Number of DisplayPorts | 1 |
Number of VGA Ports | 1 |
Number of DisplayPort 1.4 (HDCP 1.4) | 1 |
Audio Line In | No |
DVI-D | No |
Audio Line Out | No |
DisplayPort Input | Yes |
DisplayPort Output | No |
Number of HDMI 1.4 (HDCP 1.4) | 1 |
USB Type-B | No |
DisplayPort HDCP Version | HDCP 1.4 |
HDMI HDCP Version | HDCP 1.4 |
RS-232 (Rear) | No |
Thunderbolt Downstream (Rear) | No |
USB Type-A (Front) | No |
USB Type-A (Rear) | No |
USB Type-C (Front) | No |
USB Type-C (Power Delivery) Upstream Supported (Rear) | No |
USB Type-C (Without Power Delivery) Upstream Supported (Rear) | No |
Interface/Port Details | 1 HDMI port (HDCP 1.4) (Supports up to 1920 x 1080, 120 Hz as specified in HDMI 1.4) 1 DisplayPort 1.4 (HDCP 1.4) port 1 VGA port |
BUILT-IN DEVICES |
|
Webcam | No |
Microphone | No |
ENVIRONMENTAL CONDITIONS |
|
Operating Temperature Range | 0°C to 40°C |
Non-operating Temperature Range | -20°C to 60°C |
Operating Humidity Range | 10% to 80% (Non-condensing) |
Non-operating Humidity Range | 5% to 90% (Non-condensing) |
Maximum Operating Altitude | 5 km |
Maximum Non-operating Altitude | 12.19 km |
POWER DESCRIPTION |
|
Input Voltage Range | 100V AC to 240V AC |
Operating Power Consumption | 11.80 W |
Standby Power Consumption | 300 mW |
Off-Mode Power Consumption | 300 mW |
Frequency | 50 Hz 60 Hz |
Maximum Power Consumption | 31 W |
Voltage Current | 700 mA |
Input Voltage Range/Current Details | 100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/0.7 A |
PHYSICAL CHARACTERISTICS |
|
VESA Mount Compatible | Yes |
VESA Mount Standard | 100 x 100 |
Color Family | Black |
Product Color | Black |
Height | 315.6 mm |
Width | 538.6 mm |
Depth | 47.7 mm |
Height with Stand | 412.26 mm |
Width with Stand | 538.64 mm |
Depth with Stand | 171 mm |
Bezel Width (Top) | 5.80 mm |
Bezel Width (Bottom) | 13.30 mm |
Bezel Width (Left) | 5.80 mm |
Bezel Width (Right) | 5.80 mm |
Weight (Approximate) | 2.63 kg |
Stand Height | 174.02 mm |
Stand Width | 222.03 mm |
Stand Depth | 171 mm |
Weight (with Packaging) with Stand | 4.52 kg |
Weight with Stand & Cables (Approximate) | 3.20 kg |
MISCELLANEOUS |
|
Package Contents | Pro E2426H Widescreen LCD Monitor Stand 1 x Power Cable 1.80 m 1 x HDMI cable (1.8 m) for EMEA and APJC QR Card Safety Information |
Certifications & Standards | Arsenic-Free glass and Mercury-Free for the panel only BFR/PVC reduce monitor (Circuit boards are made from BFR/PVC-free laminates) Meets NFPA 99 leakage current requirements. Product Safety, EMC, and Environmental Datasheets California CEC GS Mark |
Platform Supported | ThinOS Windows |
Energy Star | Yes |
Country of Origin | China |
TAA Compliant | No |
TCO Certified | Yes |
Eye Comfort Certification | Yes |
Eye Comfort Rating | 3 Star |
Dell Display and Peripheral Manager Compatibility | Yes |
Remote Asset Management | Dell Display and Peripheral Manager (DDPM) |
Cable Type Included | 1 x Power Cable 1.80 m 1 x HDMI cable (1.8 m) for EMEA and APJC |
Environmentally Friendly | Yes |
Environmental Certification | China Environmental United Certification Center (CEC) Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) TCO Certified 10.0 TCO Certified Edge |
Energy Efficiency Certification | China Energy Conservation Program (CECP) ENERGY STAR 8.0 |
Energy Efficiency Compliance | Energy-related Products Directive (ErP) Energy-related Products Directive Lot 5 (ErP Lot 5) Minimum Energy Performance Standards (MEPS) |
Environmental Compliance | Eurasian Economic Union Restriction of Hazardous Substances (EAEU RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Restriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) |
