TECHNICAL INFORMATION |
|
Number of Screens | 1 |
Screen Size Class | 34" |
Viewable Screen Size | 34.1" |
Screen Mode | UW-QHD |
Panel Technology | In-plane Switching (IPS) Technology |
Response Time Details | 5ms GTG (Fast) 8ms GTG |
Aspect Ratio | 21:9 |
Pixel Pitch | 0.2325 x 0.2325 mm |
Horizontal Viewing Angle | 178° |
Vertical Viewing Angle | 178° |
Mount Type | Panel Mount |
Backlight Technology | LED Edgelight System |
HDCP Supported | Yes |
Maximum Adjustable Height | 150 mm |
Tilt Angle | -5° to 21° |
Swivel Angle | -30° to 30° |
Slant Angle | -4°/4° |
Features | sRGB Eye Comfort Technology Anti-glare Picture by Picture Picture in Picture Security Lock Cable Lock Slot Stand Lock BFR Free PVC Free Arsenic-free Glass Mercury-free Narrow Bezel |
Horizontal Frequency | 28 kHz |
Vertical Frequency | 30 Hz to 100 Hz |
Adjustable Stand | Yes |
Stand Adjustments | Swivel Slant Height Tilt |
Stand Included | Yes |
Glass Hardness | 3H |
Curved Screen | Yes |
Curvature | 3800R |
VIDEO |
|
Maximum Resolution | 3440 x 1440 |
Standard Refresh Rate | 100 Hz |
Colour Supported | 1.07 Billion Colours |
Native Contrast Ratio | 1,500:1 |
Brightness | 350 cd/m2 |
Colour Gamut | 99% sRGB (CIE 1931) |
Maximum Preset Resolution | 3440 x 1440 at 100Hz |
Pixel Per Inch (PPI) | 110 |
INTERFACES/PORTS |
|
Connectivity | Video port: 1 HDMI port (HDCP 1.4) (Supports up to WQHD 3440 x 1440 100 Hz, TMDS, as per specified in HDMI 2.1) 1 DisplayPort 1.4 port (HDCP 1.4) (Supports up to WQHD 3440 x 1440 100 Hz) USB port: 3 USB Type-A 5Gbps downstream ports 1 USB Type-B 5Gbps upstream port 1 USB-C 5Gbps downstream port (Power Delivery up to 15 W) 1 USB-C 5Gbps upstream port (DisplayPort 1.4 Alternate Mode, Power Delivery up to 90 W) USB Type-C (Power Delivery) 90 W |
ENVIRONMENTAL CONDITIONS |
|
Operating Temperature Range | 0°C to 40°C |
Non-operating Temperature Range | -20°C to 60°C |
Operating Humidity Range | 10% to 80% (Non-condensing) |
Non-operating Humidity Range | 5% to 90% (Non-condensing) |
Maximum Operating Altitude | 5 km |
Maximum Non-operating Altitude | 12.19 km |
POWER DESCRIPTION |
|
Input Voltage Range | 100V AC to 240V AC |
Operating Power Consumption | 28.70 W |
Standby Power Consumption | 0.3W |
Off-Mode Power Consumption | 0.3W |
Frequency | 50 Hz 60 Hz |
Maximum Power Consumption | 200 W |
Voltage Current | 3A |
PHYSICAL CHARACTERISTICS |
|
VESA Mount Compatible | Yes |
VESA Mount Standard | 100 x 100 |
Height | 358 mm |
Width | 816 mm |
Depth | 83 mm |
Height with Stand | 541.25 mm |
Width with Stand | 815.95 mm |
Depth with Stand | 229.42 mm |
Compressed Height with Stand | 391.25 mm |
Extended Height with Stand | 541.25 mm |
Bezel Width (Top) | 8.85 mm |
Bezel Width (Bottom) | 14.35 mm |
Bezel Width (Left) | 8.85 mm |
Bezel Width (Right) | 8.85 mm |
Weight (Approximate) | 6.90 kg |
Stand Height | 433.30 mm |
Stand Width | 343.20 mm |
Stand Depth | 229.42 mm |
Weight with Stand (Approximate) | 9.91 kg |
MISCELLANEOUS |
|
Package Contents | Pro 34 Plus USB-C Hub Monitor P3425WE Stand QR card Safety, Environmental, and Regulatory Information Cable tie |
Energy Star | Yes |
Country of Origin | China/Taiwan |
TAA Compliant | Yes |
TCO Certified | Yes |
Dell Display Manager Compatibility | Yes |
Remote Asset Management | DDPM |
Environmentally Friendly | Yes |
Environmental Certification | TCO Certified TCO Certified Edge |
Energy Efficiency Certification | ENERGY STAR 8.0 |
Energy Efficiency Compliance | Energy-related Products Directive Lot 5 (ErP Lot 5) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Cables included | Power Cable 1 x DisplayPort-DisplayPort cable - 1.80 m 1 x USB Type C to Type C cable - 1.80 m 1 x USB Type A to Type B upstream cable - 1.80 m |
