TECHNICAL INFORMATION |
|
Number of Screens | 1 |
Screen Size Class | 24" |
Viewable Screen Size | 23.8" |
Screen Mode | Full HD |
Panel Technology | In-plane Switching (IPS) Technology |
Response Time Details | 5 ms GTG (Fast) 8 ms GTG |
Aspect Ratio | 16:9 |
Pixel Pitch | 0.27450 mm x 0.27450 mm |
Horizontal Viewing Angle | 178° |
Vertical Viewing Angle | 178° |
Mount Type | Panel Mount |
HDCP Supported | Yes |
Maximum Adjustable Height | 150 mm |
Tilt Angle | -5° to 21° |
Swivel Angle | -45° to 45° |
Pivot Angle | +/-90° |
Features | Anti-glare sRGB Low Blue Light Flicker-free Cable Lock Slot Security Lock BFR Free PVC Free Arsenic-free Glass Mercury-free |
Adjustable Stand | Yes |
Stand Adjustments | Swivel Height Pivot Tilt |
Stand Included | Yes |
Pivot | Yes |
Glass Hardness | 3H |
Flicker Free | Yes |
Surface Treatment | Anti-glare |
VIDEO |
|
Maximum Resolution | 1920 x 1080 at 120 Hz |
Standard Refresh Rate | 120 Hz |
Colour Supported | 16.7 Million Colours |
Colour Depth | 8-bit (6-bit + FRC) |
Native Contrast Ratio | 1,500:1 |
Brightness | 300 cd/m2 |
Colour Gamut | 99% sRGB (CIE 1931) 99% BT.709 (CIE 1931) |
Pixel Per Inch (PPI) | 93 |
INTERFACES/PORTS |
|
Connectivity | 1 HDMI port/s (HDCP 1.4) (Supports up to 1920 x 1080,120 Hz as specified in HDMI 2.1 (TMDS)) 1 DisplayPort 1.4 (HDCP 1.4) port/s 1 DisplayPort Out 1.4 port/s 2 USB Type-A 5Gbps downstream port/s 1 USB-C 5Gbps upstream port/s (DisplayPort 1.4 Alt Mode, Power Delivery up to 100 W) 1 RJ45 Ethernet port/s, 1GbE 2 USB-C 5Gbps downstream port/s, Power Charging up to 15 W |
BUILT-IN DEVICES |
|
Built-in Devices | USB Hub |
ENVIRONMENTAL CONDITIONS |
|
Operating Temperature Range | 0°C to 40°C |
Non-operating Temperature Range | -20°C to 60°C |
Operating Humidity Range | 10% to 80% (Non-condensing) |
Non-operating Humidity Range | 5% to 90% (Non-condensing) |
Maximum Operating Altitude | 5 km |
Maximum Non-operating Altitude | 12.19 km |
POWER DESCRIPTION |
|
Input Voltage Range | 100V AC to 240V AC |
Operating Power Consumption | 13.8 W |
Standby Power Consumption | 0.3 W |
Off-Mode Power Consumption | 0.3 W |
Frequency | 50 Hz 60 Hz |
Maximum Power Consumption | 215 W |
Voltage Current | 2.25 A |
Input Voltage Range/Current Details | 100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/2.25 A |
PHYSICAL CHARACTERISTICS |
|
VESA Mount Compatible | Yes |
VESA Mount Standard | 100 x 100 |
Colour Family | Grey |
Product Colour | Dark Grey |
Height | 314.23 mm |
Width | 538.64 mm |
Depth | 50.03 mm |
Height with Stand | 496.53 mm |
Width with Stand | 538.64 mm |
Depth with Stand | 181.75 mm |
Compressed Height with Stand | 364 mm |
Extended Height with Stand | 496.53 mm |
Bezel Width (Top) | 5.80 mm |
Bezel Width (Bottom) | 12 mm |
Bezel Width (Left) | 5.80 mm |
Bezel Width (Right) | 5.80 mm |
Weight (Approximate) | 3.45 kg |
Stand Height | 410.80 mm |
Stand Width | 249.80 mm |
Stand Depth | 181.75 mm |
Weight (with Packaging) with Stand | 6.96 kg |
Weight (with Packaging) without Stand | 5.45 kg |
Weight with Stand & Cables (Approximate) | 5.20 kg |
MISCELLANEOUS |
|
Package Contents | Monitor Stand QR card Safety, Environmental, and Regulatory Information |
Certifications & Standards | BFR/PVC free monitor (excluding external cables) Arsenic-Free glass and Mercury-Free for the panel only California CEC Meets NFPA 99 leakage current requirements. Dell and the Environment Product Safety, EMC and Environmental Datasheets Dell Regulatory Compliance Home Page GS Mark |
Platform Supported | Windows Mac |
Energy Star | Yes |
TCO Certified | Yes |
Eye Comfort Certification | Yes |
Eye Comfort Rating | 4 Star |
Dell Display and Peripheral Manager Compatibility | Yes |
Remote Asset Management | Dell Display and Peripheral Manager (DDPM) |
Cable Type Included | Power cable 1 x USB Type-C to Type-C 5Gbps 100 W cable - 1.80 m |
Environmentally Friendly | Yes |
Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) TCO Certified 10.0 TCO Certified Edge China Environmental United Certification Center (CEC) Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) |
Energy Efficiency Certification | ENERGY STAR 8.0 |
Energy Efficiency Compliance | Energy-related Products Directive Lot 5 (ErP Lot 5) Korea Minimum Energy Performance Standards (MEPS) Minimum Energy Performance Standards (MEPS) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) China Restriction of Hazardous Substances (China RoHS) Eurasian Economic Union Restriction of Hazardous Substances (EAEU RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Waste Electrical and Electronic Equipment Directive (WEEE) |
