Display Viewing Area (HxV)

797.22 x 333.72 (mm)

Panel Backlight/ Type

Edge type

Display Surface(non-glare/ glare)

Non-glare type

Color Saturation

90% DCI-P3 / 120% sRGB

True Resolution

3440 x 1440

Pixel Pitch

0.23175*0.23175

Brightness

350 cd/m2 (TYP)

Contrast Ratio

4000:1

Viewing Angle

178°(H)/178°(V)

Display Colors

16.7M

Response Time

1ms (MPRT)

Refresh Rate

180Hz

HDR

VESA Display HDR400

Flicker-free

Yes

Connectivity

2 x HDMI 2.0

2 x Displayport 1.4

1 x Earphone Jack

Speaker

2W x2

Unique Features

OSD Sidekick *

Aim Stabilizer

Black Equalizer

Crosshair

Timer

PiP/PbP

Power Type

Power Board Build-in

Power Consumption

34W **

Power Saving Mode

<0.5W

Power Off Mode

<0.3W

Voltage

AC 100-240V ~ 50/60H

Tilt(angle)

-5°~+20°

Swivel(angle)

N/A

Pivot(angle/direction)

N/A

Height Adjustment (mm)

100mm

VESA Wall Mounting(mm)

100*100mm

Kensington lock

Yes

Phys. Dimension with Stand (WxHxD)

808.9*488.8*234.8 mm

Phys. Dimension w/o stand (WxHxD)

808.9*363.5*115.7 mm

Box Dimension (WxHxD)

995*196*565 mm

Net Weight with stand (Esti.)

8.34 kg

Net Weight without stand (Esti.)

6.22 kg

Gross Weight (Esti.)

11.2 kg

Accessories

Power cable/HDMI cable/DP cable/QSG/Warranty card

Note

*To enable OSD Sidekick (integrated in GCC), it requires connection between PC and monitor with HDMI/DP cable.

**The test condition follows CEC standards.
