Core Clock

Boost Clock* : up to 3320 MHz (Reference card: 3130 MHz)

Game Clock* : up to 2780 MHz (Reference card: 2530 MHz)

Stream Processors

2048

Memory Clock

20 Gbps

Memory Size

16GB

Memory Type

GDDR6

Memory Bus

128 bit

Card Bus

PCI-E 5.0

Digital max resolution

7680 x 4320

Multi-view

3

Card size

L=281 W=118 H=40 mm

PCB Form

ATX

DirectX

DirectX 12 API

OpenGL

OpenGL 4.6

Recommended PSU

450W

Power Connectors

8 pin*1

Output

DisplayPort 2.1a x2

HDMI 2.1b x1

Accessories

VGA manual

Note

* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. GD-151

* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. GD-147
