SPECIFICATIONS: VIDEO AND AUDIO |
| IP Video Input | 16-ch | HDMI Output | 1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | VGA Output | 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | Incoming Bandwidth | 160 Mbps | Outgoing Bandwidth | 80 Mbps | Audio Output | 1-ch, RCA (Linear, 1 KΩ) | Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 k Ω) | DECODING |
| Decoding Format | H.265+,H.265,H.264+,H.264 | Decoding Capability | 4-ch@1080p | Synchronous playback | 16-ch | Recording Resolution | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF | NETWORK |
| Network Protocol | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnPâ„¢, HTTPS | Network Interface | 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface | POE |
| Interface | 16-ch | Power | ≤ 150W | Standard | IEEE 802.3 af/at | RAID |
| RAID Type | No | AUXILIARY INTERFACE |
| SATA | 2 SATA interfaces | Capacity | Up to 8TB capacity for each disk | USB Interface | 2 × USB 2.0 | GENERAL |
| Power Supply | 100-240V～, 50/60Hz, 3.2A MAX | Consumption | ≤ 15W | Working Temperature | -10 to +55º C (+14 to +131º F) | Working Humidity | 10 to 90 % | Chassis | 1U chassis | Dimension (W × D × H) | 385 × 315 × 52 mm (15.2"× 12.4" × 2.0") ≤ 2.6 kg (5.7 lb) |
|
