ESSENTIALS |
|
Product Collection | Intel® Core™ i9 Processors (14th gen) |
Code Name | Products formerly Raptor Lake |
Vertical Segment | Desktop |
Processor Number | i9-14900F |
Lithography | Intel 7 |
CPU SPECIFICATIONS |
|
Total Cores | 24 |
# of Performance-cores | 8 |
# of Efficient-cores | 16 |
Total Threads | 32 |
Max Turbo Frequency | 5.8 GHz |
Intel® Thermal Velocity Boost Frequency | 5.8 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency | 5.6 GHz |
Performance-core Max Turbo Frequency | 5.4 GHz |
Efficient-core Max Turbo Frequency | 4.3 GHz |
Performance-core Base Frequency | 2 GHz |
Efficient-core Base Frequency | 1.5 GHz |
Cache | 36 MB Intel® Smart Cache |
Total L2 Cache | 32 MB |
Processor Base Power | 65 W |
Maximum Turbo Power | 219 W |
SUPPLEMENTAL INFORMATION |
|
Embedded Options Available | No |
Use Conditions | PC/Client/Tablet |
MEMORY SPECIFICATIONS |
|
Max Memory Size (dependent on memory type) | 192 GB |
Memory Types | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 89.6 GB/s |
EXPANSION OPTIONS |
|
Direct Media Interface (DMI) Revision | 4.0 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations | Up to 1x16+4, 2x8+4 |
Max # of PCI Express Lanes | 20 |
PACKAGE SPECIFICATIONS |
|
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2020C |
TJUNCTION | 100°C |
Package Size | 45.0 mm x 37.5 mm |
Max Operating Temperature | 100 °C |
ADVANCED TECHNOLOGIES |
|
Intel® Gaussian & Neural Accelerator | 3.0 |
Intel® Thread Director | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Adaptive Boost Technology | Yes |
Intel® Thermal Velocity Boost | Yes |
Intel® Turbo Boost Max Technology 3.0 | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Hyper-Threading Technology | Yes |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
SECURITY & RELIABILITY |
|
Intel® Standard Manageability (ISM) | Yes |
Intel® Secure Key | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® AES New Instructions | Yes |
Intel® OS Guard | Yes |
Execute Disable Bit | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
